THE LATEST TREND IN OIL CONDITION MONITORING Standards ASTM E2412, D7412, D7414, D7415, D7418, D7624, DIN 51452, 51453, JOAP Excellent correlation to ASTM D445, D664, D2270, D2896, D4739

eraspec oil – high speed lube oil testing with lab-grade precision . Portable FTIR Analyzer ERASPEC OIL can determine parameters relevant in lubricant ERASPEC OIL is a compact, rugged and lightweight FTIR analysis according to latest infrared standards such as spectrometer that delivers laboratory-grade results in ASTM E2412. It monitors degradation products (oxidation, monitoring lubricant conditions. It is the first truly standalone sulfation, nitration), additive depletion (aminic and phenolic analyzer combining advantages of infrared oil condition antioxidants, antiwear) and contaminants...

On-screen Trending Graphs ERASPEC OIL offers the possibility to monitor temporal changes of lubricant parameters directly on-screen. You can either monitor driven distance for engines or operating hours of gas turbines, for example. Simply select the machinery up for testing and run the measurement. Afterwards the system will take you right to the trending chart. That way, for example, a sudden rise in oxidation or a major drop in base reserve will be noted at first glance directly on-site. ZDDP Antiwear Phenolic Antioxidants Aminic Antioxidants 1 ... The range and repeatability for all determined...

Technical Specifications of eraspec oil Available Test Methods Spectrometer Type Patented mid-FTIR interferometer Laser and temperature controlled design Measurement Cell 100 µm path length sample cell, reference cell Optimized dual position cell design for automated reference measurement without solvent Factory calibrated with a matrix of international lubricants Eralytics' calibrations for soot, water, glycol, … Spectral Libraries Easily expandable libraries to adjust measurements to target applications and user-defined parameters Measurement Principle Direct trending: calculation of results...
