Ensto Cubo polycarbonate enclosures were selected for a particularly demanding application in Prague, where the metro is on the move 20 hours a day in conditions that change continually from hot to cold Җ from hot sunshine to cold tunnels: movement and vibration are continuous. Steel enclosures can be tailor-made to your specific dimensions. The company logo, instructions for use or wiring diagrams can be silk- screen printed on the surface of the enclosure. size="-1">

Open the catalog to page 2

The Ensto Cubo enclosures offer a wide range of OEM enclosures in different materials with dimensions according to the so called European Norm enclosures. The enclosures have plain sides and captive cover screws of stainless steel. Ensto Cubo D IP 66/67 > The Ensto Cubo D range is designed for demanding OEM use. It is manufactured of high quality thermoplastics: polycarbonate and ABS. Standard colour of the enclosures is grey, RAL 7035, cover grey or transparent. Special features are fastening pods inside the cover and slots for printed circuit boards in the base. Ensto Cubo H IP 65 > The...

Open the catalog to page 3

Ensto Cubo general purpose thermoplastic enclosures are made of polycarbonate and ABS. Ensto Cubo S is a series of small to medium size enclosures. Ensto Cubo S IP 66/67 > Ensto Cubo S is a series of small to medium size enclosures, standard colour RAL 7035; cover either grey or transparent. Cubo S is available also with pre-pressed knock-outs (Pg or metric knock-outs). Cubo S forms 136 alternatives in 17 different sizes. Ensto Cubo R IP 65 > Modular enclosures of the Ensto Cubo R series are with a hatch/door in front, facilitating control and service of the devices in the enclosure....

Open the catalog to page 4

5 5 Ensto Cubo O and C Ensto Cubo W IP 66/67 IP 66/67 > Medium size to large general purpose enclosures of polycarbonate and ABS are of Ensto Cubo C and O series. Cubo C is with flange knock-outs according to the SFS standard for flanges. Cubo O is with plain sides; three sizes are also available with pre-pressed metric knock-outs. Standard colour is grey RAL 7035, cover grey or transparent. All O and C series enclosures are available with depth alternatives 130 mm and 185 mm. Ensto Cubo W is a series of wall- mounted cabinets made of poly- carbonate. The series is based on O series general...

Open the catalog to page 5

The range of Ensto Cubo steel enclosures includes terminal enclosures and wall-mounted cabinets. Ensto Cubo E IP 66, with two doors IP 55 > The Ensto Cubo E wall-mounted cabinets are made of polyester painted mild steel or unpainted stainless steel AISI 304. Standard colour for polyester painted enclosures is the traditional RAL 7032. All mild steel enclosures are o . also available in RAL 7035. On request also available in acid-proof steel. Standard models of polyester painted cabinets are with flanges. Stainless steel cabinets have plain sides.800 x 800 x 200800 x 800 x 300800 x 1000 x...

Open the catalog to page 6

7 7 Ensto Cubo F IP 66 > The Ensto Cubo F series terminal enclosures are made of sheet steel. Alternatives are polyester painted steel, colour grey RAL 7032, or unpainted stainless steel AISI 304. Available in acid-proof steel AISI 316 on special request. All models are also available in RAL 7035, whenever you so require. All models are available in depth alternatives of 80 mm and 120 mm. The enclosures have supports for DIN rails/mounting plate as a standard. The standard model has plain sides. Ensto Cubo F enclosures are available in polyester painted mild steel or in stainless steel....

Open the catalog to page 7

8 8 > EC25GB/9/2006/Hmeen Kirjapaino Oy FOR UK ENQUIRIES ONLY PLEASE CONTACT:ENSTO UK LTD REGUS HOUSE, SOUTHAMPTON INTERNATIONAL BUSINESS PARKGEORGE CURL WAY, SOUTHAMPTONHAMPSHIRE SO18 2RZ, GREAT BRITAIN TEL. +44 (0)2380 302015 FAX +44 (0)2380 302215 ENCLOSURES AND COMPONENTSENSTO CONTROL OYENSIO MIETTISEN KATU 2, P.O.BOX 7706101 PORVOO, FINLANDTEL. +358 (0) 204 76 21 FAX +358 (0) 204 76 2516ENSTO@ENSTO.COMWWW.ENSTO.COM size="-1">
