Brief Overview of Phenomena General Insulation plays a great role in electro-technology, as well as electric power gnration, power distribution and loads. Insulation can be stressed by a number of factors. Slowly increasing over voltages can be generated by transmission line switching, turning off heavy loads, switch-ing of capacitive or inductive currents or by lightning strikes on power lines. The disturbance time is in the order of ms. Fast increasing over voltages are generated by switching actions related to failures and lightning in power lines and switch yards. Disturbance times are in...

Applicable Standards International Electrotechnical Committee (IEC) IEC 61000-4-5 Ed2 (2005) Electromagnetic compatibility (EMC) Part 4-5: Testing and measurement techniques - Surge immunity test IEC 61180-1 Ed1 (1992) High-voltage test techniques for low voltage equipment Part 1: Dfinitions, test and procdure requirements IEC 60060-1 Ed2 (1989) High-voltage test techniques. Part 1: General definitions and test requirements IEC60335 IEC 61730-2 Ed1 (2004) Photovoltaic (PV) module safety qualification Part 2: Requirements for testing IEC 60664-1 Ed2 (2007) Insulation coordination for equipment...

User Benefits The technical excellence and many unique features of EMC PARTNERS Insulation testers translate directly into benefits for the user. - Range of voltage / impedance combinations to meet multiple Applications - Standard control unit, reduces user training - Measurement system delivers information about insulation breakdown - Integration into existing test facilities saves engineering costs. - Pass / Fail indication for individual samples, speeds up production - High degree of automation, reduces operator workload - Save operator time with the automated test routines and test report...

Generator Spcifications MIG0603 Impulse Voltage 1.2/50us Voltage range 0.25 up to 6kV Voltage incrment 3 digit plus comma Impulse capacitor 10uF Source Impedance 40 Q Maximum energy 200 Joule Pulse front time 1.2 us Pulse duration 50 us Polarity positive, negative, alternating MIG1203 Impulse Voltage 1.2/50us Voltage range 0.5 up to 12kV Voltage increment 3 digit plus comma Impulse capacitor 5uF Source Impedance 40 Q Maximum energy 420 Joule Pulse front time 1.2 us Pulse duration 50 us Polarity positive, negative, alternating MIG1803 Impulse Voltage 1.2/50us Voltage range 0.75 up to 18kV Voltage...

Impulse Current 8/20us Voltage range 0.2 up to 18kV Voltage incrment 3 digit plus comma Impulse capacitor 1.67mF Source Impedance 12Q Maximum energy 280 Joule Pulse front time 8 us Pulse duration 20 us Polarity positive, negative, alternating MIG2403 Impulse Voltage 1.2/50us Voltage range 1 up to 24kV Voltage increment 3 digit plus comma Impulse capacitor 2.5uF Source Impedance 40 Q Maximum energy 840 Joule Pulse front time 1.2 us Pulse duration 50 us Polarity positive, negative, alternating MIG3603C Impulse Voltage 1.2/50us Voltage range 2 up to 36kV Voltage increment 3 digit plus comma Impulse...

MIG4803 Impulse Voltage 1.2/50us Voltage range 2 up to 48kV Voltage incrment 3 digit plus comma Impulse capacitor 10uF Source Impedance 50 Q Pulse front time 1.2 us Pulse duration 50 us Polarity positive, negative, alternating Combination Wave 1.2/50us (8/20us) Voltage range 0.25 up to 6kV MIG4803 Impulse capacitor 10uF Source Impedance 2 Q Maximum energy 180 Joule Pulse front time 1.2 us Pulse duration 50 us Short circuit waveshape 8/20 us Polarity positive, negative, alternating Impulse Voltage 1.2/50us Voltage range 0.25 up to 6kV Impulse capacitor 10uF Source Impedance 50 Q Maximum energy...

Insulation Testing ITEMA TEST MANAGER! DSO Option control TEK DSO customized solution MIG0603 MIG1203 MIG1803 MIG1803-12 MIG2403 MIG3603C MIG4803 MIG14403 CN-MIG24 TC-MIG24 EUT Insulation Testing Applications ITEMA TEST MANAGER! DSO Option control TEK DSO customized solution MIG1203 MIG2403 MIGOPTION STEP MIGOPTION UIC EUT Power AC & DC NW-IEC60065-1 NW-IEC60065-1A CN-MIG18AMP MIG-COMAT36 EUT Component Tests: Insulation Test System

Accessories and Options TC-MIG24 A test cabinet for EUT with maximum dimensions 12 X 15 x 28cm. Can be used together with MIG 1206, MIG1809 and MIG2412. TC-MIG24 is linked to the MIG 1206, MIG1809 and MIG2412 safety circuit. Opening the test cabinet disables test voltages. Safety circuit status is indicated by red and green lamps in the test cabinet. CN-MIG-24 Accessory to MIG1206SPD insulation circuit ONLY. Two test pistols with integrated red and green warning lamps. CN-MIG4803 Connection box with 2 connection cables to EUT. Cable length 1.5m one red, one yellow, equipped with alligator clips...

oftware For remote control of Insulation Testers, an OPTICAL LINK and one of the following software packages is needed: - GENECS-MIG: This is a relatively simple program that reproduces generator front panel functions on a PC. In addition to remote programming and control of the gen-erators, test report information is available to word processing or other evaluation programs such as EXCEL. - TEMA Software: Comfortable control of EMC PARTNER generators from a PC. Enables up to four generator types to be included in the same test sequence. Generates an enhanced test report. GENECS MIG TEMA software...

EMC PARTNER's Product Range The Largest Range of Impulse Test Equipment up to 100kA and 100kV. Immunity Tests Transient Test System can be used to performs all EMC tests on electronic equipment. ESD, EFT, surge, AC dips, AC magnetic field, surge magnetic field, common mode, damped oscillatory and DC dips tests are available as stand-alone or combined test instruments. A large range of accessories for different applications is available: three phase couplers up to 690V/100A, telecom and data line couplers, verification sets, magnetic field coils. Immunity test systems fulfills IEC and EN 61000-4-2,...

For further information please do not hesitate to contact EMC PARTNER's reprsentative in your r魩gion. You will find a complte list of our reprsentatives and a lot of other useful information on our website: www.emc-pariner.co The Headquarters in Switzerland EMC PARTNER AG Baselstrasse 160 CH - 4242 Laufen Switzerland Phone: +41 61 775 20 30 Fax: +41 61 775 20 59 Email: [email protected] Web-Site: www.emc-partner.com Your local representative Version 3. June 2010. Subject to change without notice.
