leneral Overview Test place automation is a category for equipment that can be used to enhance the four EMC PARTNER product ranges, Immunity, Lightning, Component and Emission. Included is equipment to increase personnel safety, link many instruments into a system and provide adjustable AC and DC power. As instrumentation, a power supply is available for use in all EMC applications. Test laboratories are confronted by a huge range of electrical and electronic products with vastly differing power requirements. Frequency and voltage combinations not available from the mains power outlet. Test...

Power Supply Overview PS3 Overview Electronic power supply requirements can differ between gographie boundaries and applications. Domestic, Telecom and Industrial supplies are generally 230V/50Hz or 115V/60Hz, Avionics 115V/400Hz and Railways in some countries use 16.7Hz. DC is also used for many of these applications. To cover all these frequency / voltage com-binations, a rugged, flexible programmable power source is needed. PS3 delivers 3000W of single phase power in a compact laboratory instrument with the ability to switch quickly between power combinations. Applications - AC & DC...

Test System Features PS3 Power Supply has many unique and outstanding features: - Compact design only 2 units high - Pre-programed voltage / frequency combinations - 3000W capability - Frequency range DC to 400Hz - DC up to 350V - User defined slection button - Fast changing between output voltages. - Interfaces directly with magnetic field loop - Magnetic fields from 16.7Hz to 400Hz > 100A/m - Extendable with PS3-SOFTEXT to full Test system. - Frequency variation tests (with PS3-SOFTEXT) - Voltage variation tests (with PS3-SOFTEXT) - Single phase mains input 90V to 264V User Benefits The...

Railway Equipment Testing Public power supply 115V 60Hz or 230V 50Hz __ PS3 230V 16.66Hz TRA3000 TRA2006 230V 16.66Hz + pulses EUT System Automation: Test Place Automation 5

Harmonies and Flicker Testing PS3 230V 50Hz or 115V 60Hz HAR1000 230V 50Hz or 115V 60Hz + mission or f immunity EUT 6 System Automation: Test Place Automation

ICON3000 Description ICON3000 control and peak measuring system 19" plug-in 4 UH for use with Marx impulse generators, current generators and high voltage d.c. supplies. With rear plate, connector sockets and special interface. Three setting modes are possible for the test voltage: 1. Peak Voltage 2. Charging Voltage 3. Voltage per Stage Applications - Control of Insulation withstand test generators After the design and the production of an equipment, tests must be carried out to verify the insulation voltage withstand capability. - Control of energy impulse test generators (current...

Hardware Accessories TC-MIG24 Test cabinet made of acrylic glass, for EUT with max. dimensions 30x20x20cm. Insulation withstand 1.2/50us up to max. 36kV. With interlock safety switch and warning lamps green/red. Usable with all generators with output on top. TC-MIG24 HL Test cabinet for heavy loads, made of acrylic glass, for EUT with max. dimensions 30x20x20cm. Insulation withstand 1.2/50us up to max. 36kV. With interlock safety switch and warning lamps green/red. Can be stood next to generator. COVER BOX SMALL Cover box for customised connection of generators with output on top....

CN-MIG24 EUT connection box with two test pistols, interlock and warning lamps green/red. Usable with MIG systems with output on top up to Vmax 18kV 1.2/50us, Imax 8/20us 1kA. Application limited to generators listed in the instruction sheet "CN-MIG24". CN-MIG18 AMP Two test pistols for conducted tests. Cable length 1m with AMP plugs. The test pistols can be used together with MIG systems equipped with AMP plug outputs. CN-MIG18 AMP CN-MIG18 SHOE Two test pistols, cable length 1.5m with cable shoes. The test pistols can be used together with MIG systems with TC-MIG24 for insulation tests....

AUX-SYNC-ADAPTER External synchronisation of generators with the AUX-SYNC-ADAPTER for 50/60Hz power supplies e.g. MIG1203CWG AUX-SYNC-APDAPTER RS232CB Serial connection of two generators e.g. MIG and HAR. RS232CB USB-RS232 ADAPTER RS232 / USB adapter for remote control of EMCP generators from PC with USB. USB-RS232 ADAPTER OPTICAL LINK Serial, optical connection between PC and generator, length 20 m. Incl. 1 Gender Changer f.-f. 25pole. OPTICAL LINK OPT- LINK-CTRL3000 Ethernet, optical connection between PC and generator equipped with CTRL300, length 10 m. OPT-LINK-CTRL3000 10 System...

EMC PARTNER's Product Range The Largest Range of Impulse Test Equipment up to 100kA and 100kV. Immunity Tests Transient Test System can be used to performs all EMC tests on electronic equipment. ESD, EFT, surge, AC dips, AC magnetic field, surge magnetic field, common mode, damped oscillatory and DC dips tests are available as stand-alone or combined test instruments. A large range of accessories for different applications is available: three phase couplers up to 690V/100A, telecom and data line couplers, verification sets, magnetic field coils. Immunity test systems fulfills IEC and EN...
