Brief Overview of Phenomena Studies by the Federal Aviation Administration (FAA) reveal that the average civil aircraft is struck by lightning every 1000 flight hours. It is therefore imperative that all aircraft should be tested to withstand the effects of lightning. Lightning events differ mainly in current amplitude, in the transferred charge and in the impulse shape of the lightning current. Two lightning events need to be simulated: - the direct strike (current and voltage) and - the induced currents and voltages within an aircraft resulting from a direct strike. Induced lightning current,...

- Voltage Spike Voltage spikes can appear on the AC or DC power supply interfaces due to platform power supply switching transients. These are transmitted by interconnecting cables and appear at an equipment interface on the power supply pins. Disturbances on AC power lines could be synchronised to particular phase angles of the 400Hz supply. - Induced Signal Susceptibility These transients result from inductive switching and similar events within the installation, that are transmitted through interconnecting cables to an equipment interface. Such transients are mostly derived from the on-board...

Test System Overview Test System Features - Full level 5 capability for all waveforms - Clean reproducible waveforms - Modular construction allows for future expansion - Simple operation - Parameter change during operation (+/-) - Internal program memory - Electronic polarity change - Compact designs - Fulfills ALL transient requirements - Remote control and software upgrade through standard interface - Full range of accessories - 2 year warranty User Benefits The technical excellence and many unique features of EMC PARTNER avionics generators translate directly into benefits for the user: - Cost...

- MIG0618SS Waveforms WF1, WF4 & WF5A. This is a stand-alone generator that delivers single stroke waveforms in excess of the level 5 cable bundle requirement. Extending the single stroke system to achieve test levels of 5 and above, is possible using the MIG0618SS. This stand alone unit generates WF1, WF4 and WF5A as a compliment to the MIG0600SS. - MIG-OS-MB Waveforms WF2 & WF3 (1MHz & 10MHz). Used for WF2 multiple stroke and WF3 multiple burst tests on cable bundles. Unique in it's class, MIG-OS-MB is factory programmed to perform all current multiple stroke and multiple burst patterns. Additionally,...

PIN Injection DATABASE on EMCP Website I jTEMA TEst MAnager : customized solution i DSO Option control TEK DSO ▼ MIG0600SS EUT Power NW-MS-LEVEL 1 I DN-LISN160-32 "-►I EUT System Flowcharts for WF2 and WF3 The following flowcharts illustrate EMC PARTNER equipment configurations neces-sary to perform multiple burst, multiple stroke and PIN injection tests in accordance with DO160 section 22. - PIN Injection Waveform 3 is applied directly from the generator output using the CN-MIG-TT to designated pins on an EUT connector, usually between each pin and case ground. For powered PIN testing the CDN-BDBC...

enerator Spcifications MIG0600SS and MIG0600MS DO160 Waveforms W1, W4, W5A & W5B W1 - 6.4/70js 15A up to 1600A (3200A) W4 - 6.4/70|js 75V up to 1600V W5A - 40/120js 75A up to 2000A (10000A) 1) W5B - 50/500js 75A up to 2000A (5000A) 1) MIG0600MS only Multiple Stroke pulse spacing 10ms up to 500ms Stroke duration 0.01 up to 50s Repetition 60 up to 999s Maximum puises 25 every 10 s First peak A1 160V up to 3200V Subsequent peaks A2 50V up to 400V Multiple stroke pattern user programmable MIG0618SS (Level 4 and 5 Extension) DO160 Waveforms W1, W4 & W5A W1 - 6.4/70js 250A up to 4000A W4 - 6.4/70js...

MIG2000-6 Fx-DO160-S17 DO160 Section 17 waveform Amplitude range Voltage Spikes 100 to 1100V Source Impedance 50ohm Risetime 1 to 2^s Duration 10ms±20% Repetition up to 2Hz Synchronisation 50/60/400Hz Coupling Serial injection using CN-MIG-BT Fx-DO160-S19 DO160 Section 19 waveform Amplitude range Induced Signal Susceptibility 100 to 1000V Spike duration 4ms Burst duration 250ms Coupling Serial using wire coil Fx-AMD24C ABD0100.1.8 waveform Voltage Spikes Test Supply Voltage 115V Risetime < 2ms Source Impedance 50ohm Spike Duration 10ms Amplitude Range 200 to 1200V Source Impedance 5ohm Spike...

iccessories and Options DN-LISN160-32 CDN-BDBC Blocking device (BD) and bypass circuitry (BC). Application: For power pin testing in accordance with DO160 section 22. CDN-BDBC MIG0600SS, -MS and MIG0618SS only CN-GI-CI Current coupling transformer used with WF1, WF5A and WF5B. Application: For cable bundle and ground injection in accordance with DO160 section 22. CN-GI-CI NW-MS-LEVEL1 External attenuation box to reach level 1 voltages and currents. Application: For all single or multiple stroke waveforms in accordance with DO160 section 22. NW-MS-LEVEL1 I-PROBE-MS High bandwidth current transducer....

CN-GI-CI-V Voltage coupling transformer used with WF4, WF5A and WF5B. Application: For cable bundle and ground injection in accordance with DO160 section 22. OPTION-V to CN-GI-CI Extends current coupling transformer CN-GI-CI for voltage testing up to level 3 used with WF4 and WF5A. Application: For cable bundle and ground injection in accordance with DO160 secͭtion 22. CN-CI-CI Coupling Transformer for cable induced tests, applicable for the following waveforms WF1, WF5A, WF5B up to 5000A. EUT cable only one turn, aperture 6 x15 cm CN-CI-VI Voltage coupling transformer for voltage waveform WF4...

CN-CI-VI (2x) Voltage coupling transformer for voltage waveform WF4, WF5A and WF5B. WF4 SS up to L5, MS up to L4 WF5A SS up to L4, MS up to L4 WF5B SS up to L2 EUT cable only one turn Aperture 6 x15 cm 2x CN-CI-V1 CN-CI-VI (2x) + CN-CI-I1 Voltage coupling transformer for voltage waveform WF4, WF5A and WF5B. WF4 MS up to L4 WF5A SS up to L5, MS up to L5 WF5B SS up to L3 EUT cable only one turn Aperture 6 x15 cm 2x CN-CI-V1 + CN-CI-I1 14 Lightning Tests: Avionics Test System

MIG-OS-MB MIG-OS-MB-EXT This extension enhances MIG-OS-MB's capability by increasing test levels and including additional waveforms. The extension is automatically recognised and controlled by the MIG-OS-MB firmware. The following plug-ins are available for the extension: NW-WF2-FS Waveform WF2: 0.1/6.4us extends the MIG-OS-MB to level 5 for single stroke or first stroke testing. NW-WF2-SS Waveform WF2: 0.1/6.4us extends the MIG-OS-MB to level 5 for subsequent stroke testing. MS definition: 1A 100%, 23D/2 50% within 2 seconds randomly distributed from 50ms up to 110ms. Requires NW-WF2-FS. NW-WF3-1M-FS...
