Yarn Break Sensors Yarn Tension Monitors Yarn Tension Control

EYE – Eltex Yarn Expert The EYE-system is designed for yarn break detection and yarn tension monitoring on textile machines. It is a flexible system that can be used on machines ranging from a few yarns to thousands. The event logging function makes it possible to view the process statistics and pinpoint the weak points in the process. All system parameters are set on the operator terminal. System status is displayed on the operator terminal and process information can be displayed on a large screen. The EYE Operator Terminal and Master Control Unit are used for Warping, Winding and Tufting....

Compact EYE -Yarn fault detection for tufting machines EYE for tufting uses the Compact Yarn sensors. The Sensors are normally fitted between the feed rollers and the needles. 100% of yarn breaks and end outs are detected. The sensors use the well proven piezoelectric principle. The special compact design enables the sensors to be installed on machines as dense as 1/10” gauge per side. “100% detection of Tufting Yarn Breaks and End Outs” On machines with limited space, due to puller rollers above the needles, the Compact II sensor is recommended. This sensor can also be installed on machines...

EyETM -Yarn tension monitoring & Yarn tension control Eltex EyETM greatly helps increase the quality of warp beams or yarn packages by monitoring all yarn tension in real time. The result is fewer problems, not only when warping and winding, but also in the next step when weaving or tufting. The yarn tension values from all yarns are continuously updated and displayed on a large screen. Tension values outside the warning level will be indicated both on the sensor’s LEDs and on the large screen. It is possible to expand a selection of the display to have a detailed view including the position...

WEAVING World leader of weft break sensors for more than 60 years! Eltex piezoelectric weft break sensors are optimized for best performance and designed to fit the requirements of each individual machine type. They sense the weft yarn over the entire fabric width detecting all types of weft faults. The Eltex optical weft break sensor is designed to detect the weft insertion arrival on Air Jet weaving machines. It’s precise detection is used to optimize several parameters in the insertion process. Tension Control The ELTEX ACT-R (Automatic Control of Tension for rapier machines) is a stand-alone...

Accred. no. 10585 Calibra on ISO/IEC 17025 Thread Break Sensors ETM – Eltex Tension Monitor Eltex thread break sensors are essential for quality seams on all types of sewing machines. Eltex sensors detect the movement of the sewing thread and immediately stop the machine when a thread break occurs. The sensors are insensitive to dust and dirt and can be used with all thread counts and thread types. The Eltex Tension Monitor for sewing machines monitors the thread tension and also serves as a thread break detector. The ETM enables the operator to maintain thread tension within the desired range,...
