LED Stroboscope HELIO-STROB micro2

Product catalog summary

Overview: The HELIO-STROB micro2 is a high-performance stroboscope designed for industrial and research applications. It features advanced LED technology, offering a brilliant light output of up to 3800 Lux. The device is compact, portable, and suitable for both internal and external triggering, with a flash frequency range of up to 2000 Hz.

Key Specifications:

Power Supply: 2.4 – 3 V using 2 AA batteries or accumulators.
Operating Time: Up to 15 hours.
Dimensions/Weight: 140 x 63 x 38 mm / 175 g.
Light Source: 3 ultra-bright CREE diodes.
Frequency Range: 1 – 2000 Hz / 60 – 99999 min-1.
Display: 5-digit 7-segment, resolution up to 0.01 Hz / 0.1 min-1.
Phase Shifting: 0 – 360°.
Operating Temperature: 0° to +40° C.
Storage Temperature: -20° to +60° C.
Protection Class: IP40.
Certification: CE.

Applications: The stroboscope is ideal for applications requiring automatic synchronization, even with unstable clock pulses and revolution speeds. It is suitable for use in environments where conventional flash tubes are typically used, thanks to its enhanced LED efficiency.

Features:

Phase shifting capability for variable focus adjustment.
Selectable RPM or flash frequency.
Fast search mode for frequency selection.
Frequency divider and multiplier.
Memory for storing up to 4 flash frequencies.
Adjustable flash duration for sharp images and uniform illumination.

Included Accessories: The package includes the HELIO-STROB micro2, a hard shell instrument case, a 1.5 m trigger cable with BNC connector, and a set of AA batteries.

Optional Accessories:

NiMH accumulators (2100 mAh, 2 x AA).
Charger for up to 4 accumulators.
Traceable DKD calibration certificate.

Contact Information: ELMED Dr. Ing. Mense GmbH, Weilenburgstr. 39, D-42579 Heiligenhaus, Tel.: +49(0)2056/9329-0, Fax: +49(0)2056/9329-33, Email: [email protected], Website: www.elmedgmbh.de

Catalog excerpts

HIGH-PERFORMANCE STROBOSCOPES FOR INDUSTRY AND RESEARCH HELIO-STROB micro2 ... highlighting benefits QQ brilliant light output up to 3800 Lux QQ high power LEDs with lens and reflector system QQ internal and external triggering QQ flash frequency up to 2000 Hz / 99999 min-1 QQ broad functionality – related to practice QQ pocket-sized and handy QQ accumulator and battery operation QQ rugged industrial grade QQ maintenance-free

Open the catalog to page 1

The HELIO-STROB micro2 comes with the latest LED generation. Concentrated brightness – pocket-sized. The interface for external trigger expands the range of application by “automatic synchronisation“ – even with instable clock pulse and revolution speed. The legendary handiness remains the same, given the fact that simply by using intelligent electronics, LED and reflector technology the light intensity has been multiplied. HELIO-STROB micro2: For the first time ever, the light efficiency of a LED stroboscope gets comparable to the one of conventional flash tubes! Q Q Q Q Q Q external trigger...

Open the catalog to page 2

LED Stroboscope HELIO-STROB micro2

LED Stroboscope HELIO-STROB micro2
