PRODUCT CATALOG 2026 Innovative, High-Quality Coating Solutions Tailored to Your Needs www.elektrosprey.com

Box-TypePowder Coating Oven The box-type powder coating oven is a high-efficiency heating system designed for the uniform and controlled curing of electrostatically powder-coated parts. Thanks to its thermoblock-based closed air circulation system, uniform heat distribution is achieved throughout the oven, maximizing surface quality. Manufactured for industrial use, the SM-BF series ovens offer tailored solutions to meet production needs with various size and capacity options. General Features • The heating unit is made of AISI 310 grade stainless steel. • Ovens are heated by a burner mounted...

TECHNICAL SPECIFICATIONS GSELEKTRO 5PREY Material Structure

Tunnel-type powder coating systems are designed for high efficiency and continuous production, making them one of the most ideal solutions for mass production facilities. Integrated with conveyor systems, these structures ensure uninterrupted product flow along the line, saving both time and labor. All stages—including surface preparation, drying, powder coating application, and curing (baking)—are optimized within a single line. This enables easier process control and ensures a uniform, high-quality coating finish. • Continuous and high-speed production • Uniform and high-quality coating • Energy-efficient...

Material Structure Note: These values are for the initial warm-up phase. Fuel consumption decreases by 50% in the steady-state regime. Conveyor speed varies depending on the thickness and weight of the material being painted.

Overhead conveyor powder coating ovens are designed for high efficiency and continuous production. Integrated with an overhead conveyor system, they ensure stable and uninterrupted transport of parts along the line, improving production continuity and reducing labor requirements. Uniform heat distribution inside the oven ensures consistent curing across all surfaces, resulting in high-quality and durable coating performance. • Continuous and efficient production flow • Uniform and high-quality curing • Energy-efficient system design • Low maintenance and operating costs • Flexible structure suitable...

SM-PF SERIES TOP-PALLET OVEN TECHNICAL SPECIFICATIONS AND DIMENSIONS Inner Sheet Outer Sheet Heating Method Control Panel Heating unit: 150 mm rock wool Body: 3 layers 50 mm rock wool Closed air circulation with thermoblock Pallet Consumable Material: V chain, 6204 bearing C3 clearance, 6-corner 24 mm carrier shaft, M-type front-shaft gearmotor, custom manufactured from NPU 80 and 50 x 50 angle iron.

Filtered Electrostatic Powder Coating Booth Filtered electrostatic powder coating booths are designed to provide high efficiency and a clean working environment in powder coating applications. Powder particles adhering to the surface through the electrostatic charging principle enable a uniform and high-quality coating finish. The multi-stage filtration system effectively captures excess powder generated during application, preventing environmental dispersion while allowing for powder recovery. Balanced air suction maintains clear visibility inside the booth and enhances operator comfort. With...

• Clean working environment with high suction power • Powder recovery with an efficient filtration system • High-quality coating with uniform airflow • Low maintenance and long filter life

Water Curtain Wet Paint Booth Water curtain wet paint booths are designed to effectively control overspray (excess paint particles) and harmful solvent vapors generated during painting processes. The water curtain formed at the rear of the booth captures paint particles, ensuring cleaner air and a safer working environment. Supported by a high-suction fan system, the booth provides balanced airflow, contributing to a uniform paint application. The water circulation system traps paint residues, maintaining long-term performance with regular cleaning. With a durable structure, low maintenance requirements,...

U-Type Electrostatic Powder Coating System U-type electrostatic powder coating systems are compact production solutions designed to deliver maximum efficiency in limited spaces. By positioning the line entry and exit points in the same direction, production space is utilized efficiently and operator control is simplified. Integrated with a conveyor system, the structure ensures balanced and uninterrupted movement of parts along the line. Surface preparation, drying, powder coating, and curing processes are optimized within a single line, resulting in uniform coating quality and high production...

Note: Oven width can be manufactured as 1800 mm, 2000 mm and above depending on product dimensions, Conveyor speed varies according to the thickness and weight of the material being painted.

Electrostatic Robot Equipment Set The electrostatic robot equipment set is a compact powder coating solution designed for industrial applications, offering high efficiency and repeatable coating quality. Automatic robot units and a multi-gun system ensure uniform paint application, while manual coating units provide flexibility for detailed operations. Thanks to its integrated recovery system, paint loss is minimized, and the entire process can be managed from a centralized control cabinet. Its modular structure allows easy adaptation to various production requirements and can be expanded when...

• 2 Single-Axis Automatic Robot Units • 6 Automatic Powder Coating Guns • 2 Manual Powder Coating Machines • 1 Automatic Control Panel • 1 Cyclone Recovery System

Manual Electrostatic Powder Coating Machine Set The manual electrostatic powder coating machine set is a practical solution designed to provide precision and flexibility in operator-controlled applications. Thanks to electrostatic charging technology, the powder adheres efficiently to the surface, ensuring a uniform and high-quality coating finish. With its compact structure, ease of use, and low maintenance requirements, the system is ideal for workshops and small-scale production, delivering an efficient and cost-effective coating process.
