Features and Benefits ElectroCraft G240 Series > Dynamically balanced armatures insure smooth performance at any speedՕRugged TENV construction for long life and reliabilityNon-contact sealed ball bearings for improved efficiency and smooth operation ՕReplaceable brushes extend product life cycle2 Pole construction to support high speed applicationsՕLow ripple tachometer options for speed regulation The 240 series offers reliable performance in a small package for your low voltage,lowertorque range applications.This series utilizes mechanically aligned electromagnetics to provide consistent...

Features and Benefits ElectroCraft G360 Series > Dynamically balanced armatures insure smooth performance at any speedՕRugged TENV construction for long life and reliabilityNon-contact sealed ball bearings for improved efficiency and smooth operation ՕReplacable brushes extend product life cycle2 Pole construction to support high speed applications The 360 series offers high performance in a small package for your low voltage,hightorque applications.This series utilizes high energy rare earth magnets to achieve high torque to size ratios.When space is at a premium the 360 series is the...

(0.1969)(0.1965)5h62.03(0.08)362 = 62.2 (2.45)363 = 87.6 (3.45)15.0(0.59)(0.70)17.78 MOTOR ONLY OPTIONS SHOWN: METRIC MOUNTING, TERMINALS MOTOR TACHOMETER OPTIONS SHOWN: METRIC MOUNTING, FLYING LEADS (70" STD) (0.1966)5h6(0.1963)DIA 45 20.0DIA(0.7874) (4) M3 X 0.5-6H THRUEQ SP ON 30.0 (1.181) DIA > INTERMITTENTOPERATING REGIONCONTINUOUSOPERATING REGION10 2030 4050 102030 102030 405060 7080 INTERMITTENTOPERATING REGION1020 30 40 CONTINUOUSOPERATING REGION 50 010002000300040005000 TORQUE (Nm)TORQUE (OZ-IN) SPEED (RPM) 010002000300040005000 TORQUE (Nm)TORQUE (OZ-IN) SPEED (RPM)

Features and Benefits ElectroCraft G640 Series > Dynamically balanced armatures insure smooth performance at any speedՕRugged TENV and optional sealedconstruction for reliability in mostenvironmentsNon-contact sealed ball bearings for improved efficiency and smooth operation ՕReplaceable brushes extend product life cycleLow ripple tachometer options for speed regulation The 640 servo series offers smooth performance for your mid to low voltage,mid-level torque applications.This series features four pole construction for reduced torque ripple and optional sealed design for more aggressive...

Features and Benefits ElectroCraft G680 Series > Dynamically balanced armatures insure smooth performance at any speedՕRugged TENV Construction for reliability and long lifeNon-contact sealed ball bearings for improved efficiency and smooth operation ՕReplaceable brushes extend product life cycle2 Pole construction to support high speed applicationsՕHigh efficiency to maximize battery life The 680 series offers high output in a highly efficient package for mid to low voltage,mid-level to high torque applications.This series combines the newest winding technology with premium materials to...

Features and Benefits ElectroCraft G700 Series > Dynamically balanced armatures insure smooth performance at any speedՕRugged TENV Construction for reliability and long lifeNon-contact sealed ball bearings for improved efficiency and smooth operation ՕReplaceable brushes extend product life cycleLow ripple tachometer options for speed regulation The 700 series offers high output for low to mid voltages,high torque applications.This series features robust four-pole construction and premium materials to provide a reliable solution. Typical Applications > Օ Electric Wheelchairs Packaging...

Features and Benefits ElectroCraft G720 Series > Dynamically balanced armatures insure smooth performance at any speedՕRugged TENV Construction and optional sealed construction for reliability in most environmentsNon-contact sealed ball bearings for improved efficiency and smooth operation ՕReplaceable brushes extend product life cycleLow ripple tachometer options for speed regulation The 720 servo series offers smooth performance for high voltage,high torque applications.This series features premium construction and materials providing smooth and highly accurate performance across the...

Lead Designator F = Flying leads- see catalog if applicable C = Standard connector- see catalog if applicable T = Terminals on motor- see catalog if applicable Z = Custom Environmental Designator (omit if not applicable) S= Sealed 640, 700 and 720 only Z= Custom > Brake Designator (omit if not applicable) Feedback Designator (omit if not applicable) 1 = 12VDC 2 = 24 VDC 3 = 90 VDC Z = custom L = 500 line count F = 1000 line count H = 2000 line count Z = custom (standard offering: TTL logic with complements and un-gated index) > Series- Brush Type Servo Motors Length Designator 0 ֖ 9 see...

Series- Brush Type Servo MotorsFrame Designator Length Designator Tachometer Designator (omit if not applicable)Winding Designator Mounting DesignatorLead DesignatorEnvironmental Designator (omit if not applicable) Feedback Designator (omit if not applicable) Brake Designator (omit if not applicable) Please explain any custom (Z) designators: Please indicate any special features not covered in the model number:ElectroCraft specializes in assisting you with an engineered solutions to meet your application needs. We alsospecialize in sourcing and assembling value added components to your...
