Product Information Electric strike 11805RR Product description Model with bipolar protective diode for access control systems. Monitoring contact as potentialfree changeover contact, actuated by the latch bolt. Overview of Advantages Radius keep, FaFix®, adjustable by 3 mm Voltage range Compatible with current mortise locks Compatible with available striking plates Symmetrical design. DIN left/right as well as horizontal applicable Technical data Adjustable keeper (FF, FaFix®) Monitoring contact (RR) Fail-locked Bi-directional diode Break-in resistance Height Width Depth FaFix® adjustment range Latch bolt engaging depth Operating temperature range Installation position Load cycles for in-plant test Suitable for fire doors Variants that can be ordered Order number 11805RR-----A71 11805RR-----B71 ASSA ABLOY Sicherheitstechnik GmbH Bildstockstraße 20 72458 Albstadt albstadt@assaabloy.com Tel. + 497431 123-0 / www.effeff.de Powered by TCPDF (www.tcpdf.org) Description Without striking plate, 12-24V AC/DC Without striking plate, 22-42 V AC/DC Fail-locked 118® Product sheet 1 Page of 1 timestamp: 31.10.
