High-speed spiral doors


Catalog excerpts

High-speed spiral doors - 1

High-Speed Spiral Doors safe high-speed doors

Open the catalog to page 1
High-speed spiral doors - 2

If speed is what you need, then EFAFLEX HighSpeed Spiral Doors will give you the superior advantage. Thanks to their unique construction – the patented spiral – they achieve peak speeds of up to 4 m/s. Accelerate your work processes enormously! EFAFLEX High-Speed Spiral Doors impress customers all over the world, for their outstanding quality, greatest safety and extreme load capacity. You select the best – and unique – door system for your application. The fastest door in the world, combined with the best heat insulation – the S Series will provide this.

Open the catalog to page 2
High-speed spiral doors - 4

Everything revolves around the patented spiral technology Copied a thousand times, yet still unequalled. The tried and tested fundamental principle of EFAFLEX High-Speed Spiral Doors remains unbeatable! The door blade is not rolled up on a shaft, but is guided into the patented EFAFLEX spiral instead, saving space and keeping it in distance. Perfection of the door blade guidance Oval spiral and low-header design EFAFLEX has patented this principle of opera- EFAFLEX provides High-Speed Spiral Doors of tion internationally. It guarantees you a series of various different designs. The circular...

Open the catalog to page 4
High-speed spiral doors - 5

Minimum mechanical load = Maximum service life High-speed doors of the EFAFLEX S Series run quietly and with no wear, thanks to the spiral system. Your door will look new for years and years. No other mechanical principle comes even close to handling the hard challenges of daily operation so smoothly. The laths are screwed together with large strap hinges. The laths are guided by especially smooth-running, quiet rollers. That means there are no driving or transmitted forces acting within the door blade.

Open the catalog to page 5
High-speed spiral doors - 6

EFA-SST® The energy-saving door for closing large halls The EFA-SST® at a glance Unrivalled noise and heat insulation The original spiral door Fitted with EFA-THERM® laths by standard Maximum speeds of up to 2.5 m/s Class 2 – 4 wind resistance Doors, and our most successful series. We have de- Completely weatherproof veloped three different variants to meet all different Up to 250,000 load cycles per year Your door to a better environment Responsible use of valuable resources is indispensable – for the sake of an intact environment today and a better future for coming generations. By...

Open the catalog to page 6
High-speed spiral doors - 7

EFA-SST® PREMIUM EFA-SST® BASIC Designed for permanent industrial appli- Capable of up to 200,000 cycles per year, This variant focuses not on speed but cation, this variant will execute easily up on high quality and extreme capacity. to 250,000 load cycles per year. Opening pacity. The most signicant features of The EFA-SST® BASIC variant fulls all speeds are in excess of 2.5 m/s. Each door this variant of EFA-SST® are robust qual- demands on a modern High-speed door. comes with its own burglar-proof lock and ity and the usual EFAFLEX reliability, Top quality, up to 100,000 cycles per year...

Open the catalog to page 7
High-speed spiral doors - 8

The latest generation of EFA-SST® In light of rising energy prices, energy saving is right at the top of everyone’s agenda – which naturally also goes for EFAFLEX. That is why we have now completely redesigned our High-Speed Spiral doors for you. Revolutionary and advanced: the new EFA-THERM® laths We are the world’s rst manufacturer to provide a series of thermally insulated EFA-THERM® insulation laths for EFA-SST®. These achieve outstanding heat insulation between 0.66 and 1.52 W/m²K depending on door size. The latest door blade is extraordinarily robust, long-lasting, tight and...

Open the catalog to page 8
High-speed spiral doors - 9

All rubber seals between the EFA-THERM ® laths are built in using elaborate “clip” technology. The EFA-SST ® can continue to be operated even with one or more laths missing.

Open the catalog to page 9
High-speed spiral doors - 10

Special models The new EFA-SST® generation fulls highest expec- EFAFLEX offers the EFA-SST® in a model that ful- tations even under heaviest continuous operation. ls all standards for explosion-protected rooms. The EFA-SST® is extremely stable and weather- All electrical components are certied according proof. It boasts outstanding heat and noise insu- to the applicable EU directives. The mechanical lation, and surpassing wind resistance. The new protection consists of brushes for electrostatically high-speed spiral doors “undyingly” withstand discharging the door blade, full grounding of...

Open the catalog to page 10
High-speed spiral doors - 11

World innovation: EFA-SST® with EFA-ACS self-repairing door blade Top in all respects As the leading specialist manufacturer of high speed doors worldwide, EFAFLEX offers a combiA milestone in economy and safety: The EFA-ACS active crash system prevents expensive damages, unnecessary downtimes and a lot of hassle! nation between a rigid door blade and active crash system. Customers can specify this unique mechanical and electronic safety system for the Premium model of the EFA-SST®. EFA-ACS not only protects the door against damage and therefore downtimes and repairs – the EFA-ACS fully...

Open the catalog to page 11
High-speed spiral doors - 12

EFA-SST®: unbeatable in materials handling In automated logistics, doors are often under In materials handling, a high-quality High-Speed Spi- very heavy goods trafc. This is where the ral Doors such as the EFA-SST® offers yet further advantages of EFA-SST® come in most clearly. advantages: in particular, unrivalled heat insulation Our High-Speed Spiral Doors ensure extreme pays off when storing fresh goods, for example. speed for rapid material ow, and can with- The EFA-SST® also seals tightly against dust. Highstand extraordinary numbers of load cycles. The Speed Spiral Doors also make an...

Open the catalog to page 12
High-speed spiral doors - 13

EFA-SST® Low-header model We create individual low-header door solutions for washing bays, re brigades, underground parking, banks and insurance companies, cooling zones and many other applications. Optimized door solutions in limited space The EFA-SST® is available in a special model for The latest safety precautions combined with high low headroom situations. It reaches opening closing speeds offer effective protection. With speeds of up to 1.0 m/s, and guarantees great- state of the art technology, the low-header model est safety for people and vehicles. System solu- measures up to the...

Open the catalog to page 13
