Rotary vane datasheet
Product catalog summary
Overview: This document provides technical specifications and data for BOC Edwards vacuum pumps, specifically models RV3, RV5, RV8, and RV12. It includes information on electrical configurations, dimensions, performance metrics, and other relevant technical details.
Specifications:
- Electrical Configurations: The pumps are available in various voltage and frequency settings, including 115/230V, 50/60Hz, and 200-230/460V, 60Hz, 3 phase.
- Dimensions: The dimensions for each model are provided in both inches and millimeters, with consistent width and height across models but varying lengths.
Performance Metrics:
- Pumping Speed: The pumps have different capacities measured in cubic feet per minute (cfm) and cubic meters per hour (m³/h), with RV3 at 2.3 cfm and RV12 at 8.4 cfm.
- Ultimate Pressure: The ultimate pressure is specified in Torr and mbar, with consistent values across models.
- Power Consumption: Power consumption is listed for both 50Hz and 60Hz operations, with higher consumption for larger models.
Additional Features:
- Noise Level: All models operate at a noise level of 48 dBA.
- Weight: The weight of the pumps ranges from 21.5 kg for the RV3 to 26.3 kg for the RV12.
- Connections: All models use NW25 connections.
