ECD2600 ECD2800

ECD2600 ECD2800

Product catalog summary
Overview: The ECD2600 and ECD2800 are UV detectors designed for analytical applications, offering a continuously variable wavelength range of 190-600 nm and 190-800 nm, respectively. They feature a noise level of ± 5·10-6 AU and are equipped with a high-standard deuterium lamp for easy exchange.
Specifications:
  • Wavelength Range: ECD2600: 190-600 nm, ECD2800: 190-800 nm
  • Spectral Half-width: 6 nm
  • Accuracy of Adjustment: ± 1 nm
  • Reproducibility: ± 0.5 nm
  • Light Source: ECD2600: Deuterium lamp, ECD2800: Deuterium + Halogen lamps
  • Noise: ± 5·10-6 AU
  • Drift: 1·10-4 AU/hr
  • Time Constant: 20 – 10,000 ms
  • Sampling Speed: Up to 100 Hz
  • Output: Digital: 1 V/AU, Analog: 1x configurable
  • Wetted Materials: Fused silica, PTFE, stainless steel, PEEK
  • Communication: RS232, Ethernet (LAN)
  • Display and Keypad: VFD 140x32 pixels, 10 pushbuttons
  • Power Supply: 100-240V 50/60Hz 100VA
  • Dimensions: 280 x 135 x 498 mm (11.02 x 5.12 x 18.23 in)
  • Weight: 9 kg (19.8 lb)
Features: The detectors are easy to operate with diagnostics available for light intensities and lamp operating hours. They perform automatic wavelength calibration and can be controlled via Clarity or ECOMAC software through RS232 or Ethernet interfaces. The cell is easily removable, with three selectable flow cells (AC02, AC05, AC10) offering different optical path lengths.
See more

Catalog excerpts

ECD2600 ECD2800-1

These detectors have continuously variable wavelength in the range of 190-600 nm respective 190 - 800 nm and noise level is ± 5-10-6 AU. The units are suited for analytical applications. It is easy to operate; light intensities for reference and sample channels are available for detector diagnostics as well as information on lamp operating hours. The detector performs automatic wavelength calibration after the lamp has been switched on. High standard deuterium lamp in a special socket enables easy exchange. Output signal is available in both digital and analogue form. Detector could be controlled, programmed and used together with Clarity or ECOMAC software via RS232 or Ethernet interface. Cell could be easily removed from the front of the unit. Three selectable flow cells AC02, AC05 and AC10 with optical path length 2.4, 5 and 10 mm. AC05 cell is included as component of the detector Trebonicka 239, CZ252 19 Chrastany u Prahy, Czech Republic
