This catalog from Eberhard Manufacturing Company, a division of The Eastern Company, provides an extensive range of high-quality hardware products for industrial, vehicular, and specialty applications. It highlights over 2,400 products, including locks, latches, and related equipment, and emphasizes the company's capability to custom-design products to meet unique requirements.
The catalog is organized into sections covering various types of hardware, such as passenger restraint latches, sliding door locks, deadbolt latches, compression latches, draw latches, handles, cam type door locks, hinges, tie-downs, gas springs, bus hardware, miscellaneous items, power locking systems, and flange gaskets.
Eberhard Manufacturing offers a limited warranty for one year from the date of sale, ensuring products are free from defects in materials and workmanship, provided they have not been subjected to abuse or improper use. The warranty excludes incidental costs and is in lieu of all other warranties.
The catalog details the Eberhard Safety Slam Lock System, which meets Federal Motor Vehicle Safety Standard No. 206 for passenger restraint applications. The system includes various lock assemblies and strikers, designed for both direct and remote operation. The locks are serialized for lot control and feature outside and inside locking mechanisms.
The Series 206 and 207 lock systems offer various configurations, including automatic unlocking features and different actuator options. These systems are designed to prevent lockouts and are serialized for lot control.
The catalog describes the 400 Series rotary latches, which provide primary and secondary latching capabilities. These latches meet FMVSS 206 standards and are available with various actuator options and finishes for improved durability.
Only the products in Section 1 are designed to meet FMVSS 206 standards for passenger restraint systems. Other products in the catalog are not recommended for passenger applications.
- No. 9D 400-UR&L Dovetail Rotary Latch: Features a unique wedge design for improved door alignment, two-stage latching, and multiple actuator options. It is zinc-plated with black-coated pawls for corrosion resistance.
- No. 450-R&L Series Rotary Latches: Designed for installations where lever arm actuator position is a constraint. These latches meet FMVSS 206 standards and require specific striker assemblies for compliance.
- No. 1-475-R&L Low Profile Rotary Latch: Suitable for thinner door applications, featuring a dual-stage latch and Everlube finish for corrosion protection.
- No. 10-5690-X Sliding Door Lock: A heavy-duty lock with a firm spring action, suitable for right or left-hand doors, and allows locking from the inside.
- Installation of latches requires specific striker assemblies and bolts to ensure compliance with FMVSS 206 standards.
- Some latches offer options for actuator positions and finishes, allowing customization based on installation needs.
- Various latches are available in different materials and finishes, including zinc-plated carbon steel and stainless steel, with options for key-locking and non-key-locking mechanisms.
- Some latches offer additional features such as inside release mechanisms, long-angle slam bolts, and different mounting options.
The document provides detailed specifications for various mechanical components, including black tapped parts, footman loops, and gas springs. It includes dimensions, temperature ranges, and material finishes such as zinc-plated steel.
These are designed to hold straps or webbing and are available in carbon or stainless steel. They accept No. 10 screws and are zinc-plated for durability.
The Powerise™ Pneu-Spring® is highlighted as a pneumatic device with self-lubricating and self-dampening features. It offers consistent force and is suitable for various applications, including machine tool cabinets and utility truck enclosures. Specifications include stroke lengths, force ranges, and installation guidelines to avoid side loads and temperature extremes.
This section details gas struts used for controlled lifting and lowering of hoods and doors. They offer speed-controlled dampening and are available in various force ranges and dimensions.
The document describes door control systems for buses, including single and double latch options, rod assemblies, and door handles. These components are designed for durability and ease of use in the school and transit bus markets.
Guidelines for the installation of Pneu-Springs are provided, emphasizing the need for engineering drawings and specific measurements to ensure proper application and performance.
Catalog excerpts
For more than 100 years, Eberhard has been an industry leader, providing companies like yours with high-quality hardware for a variety of applications.Today, we offer one of the most extensive selections of locks, latches and related equipment for industrial, vehicular and specialty use.There are over 2,400 products available in our line, many of which appear in this catalog. Besides the most popular styles and sizes, we offer a wide choice of variations and options, some not available anywhere else. Whether you need standards or specials, no one offers a broader selection than Eberhard.We also...
Open the catalog to page 4
EBERHARD Pages section 1 > Passenger Restraint Latches: Rotaries, Slam Latch, Strikers, Sliding Door Locks 112Slam Latches: Strikers, Rotaries, Paddle Latches, Push Buttons, Handles, Finger Pulls, section 2 > Sliding Door Locks, Paddle Rotary Latches, Rod Adapters, Multipoint Latches13֖96 Dead Bolt Latches; Quarter Turns, T-Handles, D-rings, Paddle Latches, section 3 > Rod Guides, 2- and 3-point Systems, Center Cases 97140 Compression Latches: T-Handles, D-Rings, Quarter Turns, Trigger Latches, section 4 > Lift-n-Turn, Center Cases 141֖160 section 5 > Draw Latches161166 section 6 > Grab/Pull...
Open the catalog to page 5
EBERHARD Safety Notice: The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. No other products shown in any other section of our catalog are recommendedfor passenger applications. No. 206-XR No. 206-15 Striker The Eberhard Safety Slam Lock System is one of the highest quality, thinnest profile vehicle locks we manufacture. The lock measures only 3/4" in thickness.Meets the Federal Motor Vehicle Safety Standard No. 206 for personnel restraint applications. To comply with...
Open the catalog to page 7
EBERHARD Safety Notice: The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. No other products shown in any other section of our catalog are recommendedfor passenger applications. No. 1-400-R&L Right-hand shown.Has two holes in actuatorarm for attaching remote latching points.NOTE: Rotary Latch is available with 1/4" x 20 UNC threaded inserts. Specify when ordering (i.e. IT-400 R) . No. 400-R&LRotary Latch These are two-stage latches, with both primary and secondary latching...
Open the catalog to page 9
Safety Notice: The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. > EBERHARD No other products shown in any other section of our catalog are recommendedfor passenger applications. Various 400 Series Actuator Options Note: Antirattle feature is standard with all actuators. Other options available. Consult factory. Note: All versions available with threaded inserts. Note: All versions available in Dovetail. No. 400-R No. 20-400-R No. 15-400-R No. 8-400-R (Independent lever...
Open the catalog to page 10
EBERHARD Safety Notice: The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. No other products shown in any other section of our catalog are recommendedfor passenger applications. > No.Similar to:Variations 400 R&LOne hole in actuator 1/4" dia.1-400 R&L400 R&LModified actuator with two 1/4" dia. holes 1T-400 R&L1-400 R&LWith three 1/4"-20 UNC lock mounting spacers 2-400 R&L400 R&LOne hole in actuator 17/64" dia. 3-400 R&L1-400 R&LModified actuator with one 17/64" dia. hole...
Open the catalog to page 11
Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.90pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:14.00pt "Arial", sans-serif; } .font4 { font:5.00pt "Tahoma", sans-serif; } .font5 { font:7.00pt "Tahoma", sans-serif; } section1 SafetyNotice: Theproducts shown in Section 1 of ourcatalogare the only products designed by Eberhard to meet Federal Motor Safety Standard #206 (FMVSS 206) for passenger restraint systems. No other products shown in any other section of our catalog...
Open the catalog to page 12
Safety Notice: Options: The 450 rotary latch series is available with 1/4" x 20UNC threaded inserts. Specify when ordering ( > EBERHARD The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. No. T-450-R ). No. 2T-400-52 , and .312dia. grade 8 bolts for installa- tion. Latch pawls have an Everlube finish for corrosion pro- tection and lubricity; the outside housing is zinc-plated. Weight: .57 lbs. (Left-hand shown.) No other products shown in any other section of our catalog...
Open the catalog to page 13
Safety Notice: The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. > EBERHARD No.16619-15PK ) for multipoint systems.Recommended striker ( No other products shown in any other section of our catalog are recommendedfor passenger applications. No. 475-52U ).* Three Grade 8 1/4-20 mounting boltsrequired to meet FMVSS 206 strength requirements in conjunction with Eberhard 475-52U striker and acertified FMVSS door system. No. 1-475-R&L No. 1-475-R No. 1T-475-R&L Low profile...
Open the catalog to page 14
EBERHARD Safety Notice: No. 7-5690-50 The products shown in Section 1 of our catalog are the only products designed by Eberhard to meet Federal Motor Safety Standard#206 (FMVSS 206) for passenger restraint systems. Center case less the inside handle.Weight: 2.25 lbs. Finish: Zinc-plated with chrome handle No other products shown in any other section of our catalog are recommendedfor passenger applications. No. 10-5690-X No. 4-5696-ZR No. 10-5690-X This heavy-duty sliding door lock has a firm spring action which latches the door securely; requires but a slight turn of the handle to release it...
