Hydro-Line® HM Series Metric Cylinders
52Pages

{{requestButtons}}

Catalog excerpts

Hydro-Line® HM Series Metric Cylinders - 2

Piston Rod: Case hardened, hard chrome plated piston rod in a variety of diametersbetween 12 and 140 millimetersprovides maximum durability andextends seal life. Several different rodend types are available. Global Design: Engineered for ISO 6020-2/DIN 24554 interchangeability with the durabilityrequired for heavy-duty applications. > Bore Size Range: Cylinder bores available between 25 and 200 millimeters. Rod Cartridge Assembly: Quick Change design requires no other cylinder disassembly for rod sealmaintenance. SureSeal Sealing System: Carefully selected wiper and seal combinations are...

Open the catalog to page 2
Hydro-Line® HM Series Metric Cylinders - 3

Product Features 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications. . . . . . . . . . . . . . 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . How to Order. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ....

Open the catalog to page 3
Hydro-Line® HM Series Metric Cylinders - 4

Bore sizes: 25mm through 200mmPressure rating: 210 bar (3000 PSI) hydraulic Temperature: -20F to 400аF optional ISO 6020-2 interchangeable mountingsIHM: Hydraulic cylinders incorporate exclusive SureSeal > TM sealing system, which provides long life and superior leakage control. Black enamel paint is standard. Optional adjustable cushions feature retained adj. screws. > INTOCUSHIONOUT OFCUSHION As the cylinder enters cushion, the newfloating elastomeric cushion seal aligns itselfon the cushion spear or collar. Sealing takes place on the spear or collar diameter and theback of the cushion...

Open the catalog to page 4
Hydro-Line® HM Series Metric Cylinders - 5

Eaton has created an easy system forordering Series > IHM Cylinders. Thissystem has been developed to improveour service to you. The model code consists of sixteen alpha-numeric digitswhich fully describe the most commonstandard options offered on Series Although the model code has beenarranged to cover the vast majority ofavailable options, there will beoccasions when you require an optionwhich cannot be coded. Whenspecifying such an option, enter an XӔfor the appropriate item in the IHM cylinders.To specify your Series IHM cylinder,review the following pages for a fulldescription of each...

Open the catalog to page 5
Hydro-Line® HM Series Metric Cylinders - 8

IHMAK IHMG Keyed side lug Head rectangular ISO ME5 IHMA Side lug ISO MS2 IHMC IHMCS IHMP Cap clevisISO MP1 Spherical bearingISO MP5 Cap rectangular ISO ME6 IHMU Head trunnion ISO MT1 IHMW Cap trunnion ISO MT2 IHMTT Intermediate trunnion ISO MT4 IHML Both ends extended tie rod ISO MX1 IHMM Head extended tie rod ISO MX3 IHMN Cap extended tie rod ISO MX2 IHMAD IHMCE Double rod, side lug Cap fixed eye ISO MP3 8 >

Open the catalog to page 8
Hydro-Line® HM Series Metric Cylinders - 9

B EH LH SBBolt hole SY SU Ңȅ SY E STROKE + SS XSVCMM TS STROKE + ZB USST RodMM (f9) > (h10) Max Bore B C E G1 H J V Y LH PJ+ SB SS+ ST SU SY TS US XS ZB+ 25 >

Open the catalog to page 9
Hydro-Line® HM Series Metric Cylinders - 11

STROKE + PJ Y RD GFH G1 B R E FBBolt hole J FWF Ԣȅ > E TO UO STROKE + ZBVCMM RodMM (f9) Max (f8) Max Max Bore B C E F G1 GF H J R V Y FB PJ+ RD TO UO WF ZB+ 25 >

Open the catalog to page 11
Hydro-Line® HM Series Metric Cylinders - 12

RD GH STROKE + PJ Y B R EFWF FBBolt hole Ԣȅ > J E G1 TO UO STROKE + ZBVCMM RodMM (f9) Max (f8) Max Max Bore B C E F G G1 H J R V Y FB PJ+ RD TO UO WF ZB+ 25 >

Open the catalog to page 12
Hydro-Line® HM Series Metric Cylinders - 13

LRMR J E L CBCW CW G1 STROKE + XCVCMMB RodMM (f9) Min > (A16) (f8) Max Min Max Bore B C E G1 H J L V Y CB CD CW LR MR PJ+ XC+ 25 >

Open the catalog to page 13
Hydro-Line® HM Series Metric Cylinders - 15

STROKE + PJ Y H R E FBBolt hole Ңȅ > G1 E STROKE + ZJVCMMB TO UOJ RodMM (f9) Max Bore B C E G1 H J R V Y FB PJ+ TO UO ZJ+ 25 >

Open the catalog to page 15
Hydro-Line® HM Series Metric Cylinders - 17

STROKE + PJ VCMMB Y H TDTLTL R E > J G1 TC STROKE + XJ UT STROKE + ZB RodMM (f9) Max (h14) (f8) (h15) Max Bore B C E G1 H J R V Y PJ+ TC TD TL UT XJ+ ZB+ 25 >

Open the catalog to page 17
Hydro-Line® HM Series Metric Cylinders - 18

STROKE + PJ VCMMB Y TDTLTL R E > J G1 TC XG H UT STROKE + ZB RodMM (f9) Max (h14) (f8) (h15) Max Bore B C E G1 H J R V Y PJ+ TC TD TL UT XG ZB+ 25 >

Open the catalog to page 18
Hydro-Line® HM Series Metric Cylinders - 20

STROKE + PJ VCMMB Y H TGAA BBDD(TYP. 4)WH E >

Open the catalog to page 20
Hydro-Line® HM Series Metric Cylinders - 21

STROKE + PJ VCMMB Y H TGAABBDD(TYP. 8) E >

Open the catalog to page 21
Hydro-Line® HM Series Metric Cylinders - 22

SUSY SY SB BOLTHOLE E ∅ STROKE + XS STROKE + SS > 1 XSVCMMBY TS TWICE STROKE + ZM USST RodMM (f9) > (h10) Bore B C E G1 H V Y LH PJ1+ SB SS1+ ST SU SY TS US XS ZM++ 25 >

Open the catalog to page 22
Hydro-Line® HM Series Metric Cylinders - 23

STROKE + PJ Y H EL EW CDHOLE ∅ LRMR > J E G1 STROKE + XCVCMMB RodMM (f9) > (h9) Min Max Bore B C E G1 H J L V Y CD EW LR MR PJ+ XC+ 25 >

Open the catalog to page 23
Hydro-Line® HM Series Metric Cylinders - 24

All rod accessories must be torquedagainst the rod shoulder. Mounting brackets, rod clevises, and rodeyes for all IHM cylinders are availablefrom Eaton . These accessories aredetailed below showing part numbersand all pertinent dimensional data.When ordering, please specify the partname and part number. >

Open the catalog to page 24
Hydro-Line® HM Series Metric Cylinders - 32

IHM cylinders. Rod ends on rigid mount cylinders should be supported. Longerstrokes are allowable for pull only > Hydro-Line applications. Contact your local Hydro-Line sales engineer, and define your requirements.The table on page sales engineer for applicationassistance if necessary. In addition to selecting the correct bore,you must specify the appropriate rodsize and rod end configuration for yourapplication.Five different rod end configurations areavailable. If a custom design isrequired, contact your local 39 givesmaximum allowable push strokes atvarious operating pressures...

Open the catalog to page 32
Hydro-Line® HM Series Metric Cylinders - 34

Port locations are identified by viewingthe cylinder from the head end (or from the mounting end of double rodcylinders). The location numbers areshown below. 3 124Certain port locations cannot bespecified with some mounting styles.The table below indicates which of thehead and cap port locations are available for each Series IHM mounting style. Ports in location 1 only for 25-32mm bores. MountingHead LocationsCap LocationsStyle CodeDescription12341234 A Side lug A W A W A W A W AK Keyed side lug A W A W A W A W DHMG Head rectangular A A A A A A A A G Head rectangular A A A A A A A A C...

Open the catalog to page 34
Hydro-Line® HM Series Metric Cylinders - 35

Three different sealing systems areavailable in Series IHM cylinders.Determine the correct seal code s for your application, then enter them in themodel code. TemperatureMax. SpeedCodeFluid ( C)(m/s) Application H, B Mineral oil, petroleum base Ж35 to 80 0,7 Normal, typical industrialAutomotive transmission fluid F Mineral oil 35 to 120 5 Low friction servoWater glycol (HFC)10 to 701Fire retardant fluidsOil-in-water emulsions (HFA)Water-in-oil emulsions (HFB) T Mineral oil֖25 to 2005High temperaturePhosphate esters, petroleum oil blends0 to 2005Fire retardant fluidsFyrquel 220, 550,...

Open the catalog to page 35
