Eaton is a global leader in the hydraulic industry, offering a comprehensive line of reliable and high-efficiency hydraulic systems and components. This brochure introduces Eaton's mobile valve products designed for various applications in agriculture, construction, material handling, forestry, utilities, and lawn and garden sectors.

1. Inline Load Sensing Priority Valves: VLC/VLE/VLH
These valves provide dependable flow on demand for load sensing steering, braking, or other priority functions. They are compatible with systems using fixed or variable displacement pumps and can be used with open or closed center valves. Applications include agricultural tractors, motor graders, lift trucks, and backhoe/loaders.

2. Hydraulic Remote Controls (HRC)
HRCs offer operator-selectable pilot pressure for remote control of larger valves or pumps, reducing operator effort and fatigue. They are available in various modules with input options like hand lever, foot pedal, joystick, and ergonomic handles. Applications include mini-excavators, skid steer loaders, wheel loaders, and rough terrain lift trucks.

3. Proportional Flow Controls: EPV
EPV cartridges provide infinitely variable flow control proportional to the electrical input to the solenoid, with compensation for pressure differential variations and low internal leakage. Applications include agricultural planters, lift trucks, harvesters, and forestry equipment.

4. Load Sensing Directional Valve: CMX Sectional
The CMX sectional valve is a stackable, load sensing, proportional directional control valve operable by hydraulic or electric remote control signals. Applications include forestry equipment, wheel loaders, rough terrain lift trucks, and boom man lifts.

5. Open Center Priority Flow Dividers
These dividers operate within an open center circuit, routing a fixed flow amount to a priority port, typically for steering circuits. Applications include golf course maintenance equipment and lift trucks.

6. Single & Dual Self Level Valves
These valves are line-mounted flow dividing units that automatically adjust bucket function in response to boom cylinder movement, maintaining constant bucket attitude. They are used in skid steer loaders and agricultural tractor loaders.

7. Manual Directional Control Valve: CM11 30 GPM Sectional
This manual control valve allows operators to manually control hydraulic flow direction. Its stackable design and high flow rate make it suitable for applications like lift trucks and sugar cane harvesters.

8. Manual Directional Control Valves: 5 and 15 GPM Monoblock
Available in one, two, and three spool configurations, these valves offer options like system relief valves and pilot-operated work port checks. They are used in lift trucks, sweepers, scrubbers, trenchers, lawn and garden equipment, and golf course maintenance equipment.

Catalog excerpts

2 EATON Mobile Valves Marketing Brochure E-VLOV-MR001-E September 2002 >

Open the catalog to page 2

2.Hydraulic Remote Controls A hydraulic remote control(HRC) provides operator selectable pilot pressure for use in remotely controlling alarger valve or a pump. Itreduces operator effort andfatigue, as compared to a manual control. HRCs are available in various modules, and with numerous inputoptions such as hand lever, footpedal, joystick, ergonomic han-dle with switches, and others.Applications include mini-excava-tors, skid steer loaders, wheelloaders, and rough terrain lifttrucks. 3.Proportional Flow Controls:EPV EPV proportional flow controlcartridges provide infinitely variable control...

Open the catalog to page 3

4.Load Sensing DirectionalValve:CMX Sectional The CMX sectional valve is astackable, load sensing, propor- tional directional control valve. Itcan be operated by eitherhydraulic remote control (HRC)or electric remote control (ERC)signals. Applications for theCMX section valve includeforestry equipment, wheel load- ers, rough terrain lift trucks, andboom man lifts. 5.Open Center Priority FlowDividers Operating within an open centercircuit, a priority flow dividerroutes a fixed amount of theavailable flow to a priority port, usually a steering circuit.Applications include golf coursemaintenance...

Open the catalog to page 4

6.Single & Dual Self LevelValves Eaton self leveling valves areline mounted flow dividing unitsthat provide automatic move- ment of a bucket function inresponse to movement of theboom cylinder to keep the buck-et attitude constant as the boomis re-positioned. In a typical application, the sin-gle self level valve levels in theupward movement and the dualself level valve levels both the upward and downward move-ments. Self level valves arecommonly used in skid steerloaders and ag tractor loaders. > Dual Self Level Valve 7.Manual Directional Control Valve:CM11 30 GPM Sectional A manual control...

Open the catalog to page 5

6 EATON Mobile Valves Marketing Brochure E-VLOV-MR001-E September 2002 >

Open the catalog to page 6

Eaton 46 New Lane, Havant Hampshire PO9 2NB England Tel: (44) 23 92 486 451 Fax: (44) 23 92 487 110 Eaton 20 Rosamond Road Footscray Victoria 3011 Australia Tel: (61) 3 9319 8222 Fax: (61) 3 9318 5714 Eaton 14615 Lone Oak Road Eden Prairie, MN 55344 USA Telephone: 952 937-7254 Fax: 952 974-7130 www.hydraulics.eaton.com > 2002 Eaton CorporationAll Rights Reserved Printed in USADocument No. E-VLOV-MR001-ESeptember 2002

Open the catalog to page 8
