HDPE/PP SPIRAL WOUND PIPE PRODUCTION LINE QINGDAO YONGKE MACHINERY CO.,LTD

Eagle is professional manufacturer to produce large diameter HDPE/PP spiral wound pipe production line. We are successful to supply all the world with spiral profile wound pipe production line from DN300mm to DN4500mm and have more than 12 years' experience. We focus on developing and manufacturing the technology and equipment to produce HDPE/PP spiral wound pipe, HDPE/PP spiral wound tank, fittings, manhole, etc. Our product includes HDPE/PP spiral pipes, HDPE or PP spiral wound pipe production line, HDPE/PP spiral tank winding machine, mandrel (production tooling), single wall corrugated pipe...

We supply HDPE/PP spiral wound pipe production line to produce the HDPE/PP spiral pipe and fittings, HDPE spiral manhole from DN/ID300mm to DN/ID 4500mm. The big advantage of HDPE/ PP spiral wound pipe production line is that production is very flexible. One machine can produce the pipe from DN300 to DN4500 and changing time is very short with variety of wall structure. The pipe length can be from 1 meter to 9 meters according to requirement with any international standards. The main applications for the spiral wound pipe products are low, non -pressure applications like for sewer, drainage,...

Pipe Wall Structure(PR, OP, CPR, SQ, VW, SP) Electrical Fusion Connection Rubber Ring Connection

The extrusion system consists high efficiency extruders, computer control system, dual color inner wall die and outer coating layer die, melt distribution valve, pressing and guiding unit, co-tube feeding unit, gas heating system and infrared heating system Movable Winding System This system can move the mandrel forward and revert driven by servo motor under control program. The mandrel rotation speed is driven by servo motor and controlled by control program synchronized with extrusion system. Automatic Socket and Spigot Milling system The pipe will be cooled on the cooling station along with...

High speed PP corrugated pipe extrusion line This machine is to produce the co tube for spiral wound pipe as the forming support. It is equipped high speed corrugator with aluminum block, vacuum forming and water cooling. Pipe diameter is from OD21mm to OD130mm. Speed is up to 15m/min. Welding Wire Forming Machine This machine is produce the welding wire for HDPE spiral wound pipe as the electrical fusion connection. Software Pipefinder for pipe calculation This software can calculated the pipe ring stiffness according to raw material, and customer’s requirements.

YONGKE MACHINERY CO.,LTD ADD: Shuangtun Lu, Madian, Jiaozhou, Qingdao, China TEL:+86-532-81168513 FAX: +86-532-82268603 MOB : + 86-13583232887(WH ATSAPP) EMAIL: [email protected]
