DF-PK1000 Material data sheet
1 / 1 PageView full catalog
DF-PK1000 Material data sheet
Product catalog summary
General Information
Material: 10% PEEK Filled PTFE
Features: Increased thermal resistance, improved sliding properties, enhanced surface hardness, and superior performance in dynamic applications.
Material: 10% PEEK Filled PTFE
Features: Increased thermal resistance, improved sliding properties, enhanced surface hardness, and superior performance in dynamic applications.
Typical Physical Properties
- Color: Beige
- Density (Specific Gravity): 2.00 g/cm3 (ASTM D-792)
- Water Absorption (Max): <0.01% (ASTM D-570)
- Flammability: V-0
- Tensile Strength: ≥20 MPa (ASTM D-4894)
- Elongation at Break: ≥250% (ASTM D-638)
- Hardness: Shore D 61 - 66 (ASTM D-2240)
- Ball Hardness: 26 MPa
- Service Temperature (Long Term): -200°C to +280°C (ASTM D-648)
- Surface Resistivity: >1016 ohm (ASTM D-258)
- Volume Resistivity: >1017 ohm cm (ASTM D-257)
Notes
- The data provided are typical values for reference and comparison purposes only.
- These values should not be used as design specifications or for quality control.
- Information is provided as a guide without obligation or liability.
- Testing under specific application circumstances is recommended.
