Sensors and Analytical Instrumentsfor the Plastics Industry >

Polymer Testing Products Pressure and Temperature Sensors and Instrumentation 2 >

The Industry Standard > Page 4PT460 Series MRTSeries Melt Monitor Pressure Gauges > Page 5 Mechanical Pressure Gauges DYN-XSeries Digital Series Process Products > Page 6PT420 Series SPXSeries SPX-HASeries Food and Medical Products > Page 7NaK Filled Series Oil Filled Series Push-Rod Series The Dynipak Series > Page 8Classic Dynipaks MRTDynipaks Pressure/Temperature Dynipaks Differential Dynipaks Accessories > Page 8Thermocouples, Mounting Hole Kits and Burst Plugs Instrumentation > Page 91/8 DIN Pressure/Process Indicators 1/16 DIN (TCS) and 1/8 DIN (TCE) Temperature Controllers 1/4 DIN...

These transducers and transmitters represent the top of the line in melt pressure and temperature measurement andcontrol. With combined errors as accurate as 0.15% including temperature effects, you can bring the ultimate in controlto the extrusion process. Hazardous area approved transmitters are available. ModelsFeatures & Benefits PT420 Series ( 0.25% Combined Error)PT420Aѕ3.33mV/V output provides industry standard low level outputPT422A500 to 30,000psi versions for range-specific extrusion processesTPT432AՕExcellent thermal stability and repeatability provide ideal high temperature...

Dynisco now offers a complete family of pressure transducers and transmitters designed for the food and medical applications of the extrusion market. All of these pressure sensors meet the requirements set forth by the FDAand USDA. ModelsFeatures & Benefits NaK Filled Series ( 0.25% or ѱ 0.5% Combined Error, model specific)PT410Special fill material for processes up to 1,000 պ Fdesigned for high temperature applicationsPT412Meets FDAand USDArequirements for food and medical applicationsTPT412ՕInconel 718 diaphragm for rugged, long-lasting transducer lifePT415DExcellent thermal stability and...

Dynisco offers a fast way to get started with our Dynipak kits. These kits contain everything you need to install our transducers and start using them to maximum advantage. Kits come with pressure transducers or transmitters, an indicator or controller, easy start instructions, anti-seize compound, a screwdriver and tips on use. ModelsFeatures & Benefits Classic Dynipaks ( 0.5% or ѱ 1.o% Kits)PT460ERanges from 500 to 10,000psi available to meet pressure measurement requirementsPT462EՕ6" stem and 6/18 stem/flex configurations provide industry standard lengthsDYN-X1390-2-3 indicator for local...

Dynisco offers a wide range of instruments to complement our pressure and temperature transducers, making it easyto select the combination that will perfectly match your application. ModelsFeatures & Benefits 1/8 DIN Pressure/ mA, Vdc and strain gage inputs provide versatile process monitoring Process Indicators ՕmAand Vdc linear retransmission enables the user to log process trends1390Field-scalable display and dual configurable alarms to meet measurement indication requirements1391ՕULand CE approved to meet US and European requirements1392Peak and valley detection allows for recall of...

HDV3 HDT/VICAT System This advanced HDV System offers sophisticated control and simple operation. The Windows > ֙ control and analysis software offers easysetup, operation, analysis and calibration. Display and plot distortion vs. temperature and temperature rise rate curves.Insulated stainless steel bathՕUp to 6 (universal) test stationsDigital gauges with LVDTtransducersՕMaximum temperature 300C, up to 400аC (optional)Temperature rise rates 50հC/hour or 2C/minuteЕInvar specimen frames for low linear expansionPC-controlled frame calibrationՕIndividual specimen thermocouplesHigh temperature...

0.1ѰC using a unique PID control algorithm. Four melt indexer models are offered in the advanced Dynisco LMI 4000 series, each with features designed to meet specific application requirements.Advanced microprocessor designՕASTM D1238 and ISO 1133-2005 standards Self-diagnostics capability ՕComprehensive statistical capability Simple push-button RTD calibration ՕSmart keys for easy programming Bright, 4-line by 20-character vacuum fluorescent display ՕWindows software for test database and analysis LMI 4000 ٖ Melt Flow Indexer The most precise instrument for the measurement of Melt Flow Rate...

LCR 7000 Capillary Rheometer Designed to meet the demands of a 24-hour-a-day shop floor operation while maintaining the highest possible level of accuracy, repeatability and sensitivity. The LCR series rheometers are versatile and easy to use yet they offer the most sophisticated materials characterization, data analysis and reporting capabilities. The LCR 7001 can be used with a standard load cell and a barrel-mounted pressure transducer. Many years of service ensured through the use of tungsten carbide dies and a hardened and honed tool steel barrel. LAB KARS advanced rheology software...

ViscoSensor Online Rheometer The world֒s smallest in-line polymer melt rheology instrument, measuring only 25 inches in length by 10 inches in width. The ViscoSensor is extremely easy to install, calibrate and operate making it the most cost-effective in-line sensor on the market. The ViscoSensors zero discharge system returns the polymer back to the process, eliminating material waste. The ViscoSensor can be used to generate shear rate vs. viscosity data or continuous ASTM melt control tool that can be used for product quality and consistencyҕAttaches to the process using a standard M18...

LME Laboratory Mixing Extruder The LME is a versatile laboratory tool for evaluating the processability of a variety of plastics, rubbers and additives prior to production. The unique, Maxwell screwless design enables the LME to mix, compound and extrude materials that vary widely in both physical form and characteristics.֕Able to process very small quantities of material (1 gram)Residence time less than a minuteՕVariable speed rotor control 5260 rpm֕Separate header and rotor heater for temperature controlsMaximum temperature 400հCVarious Headers and Orifices: ribbon, spinnerette, tube and...
