Dynabrade 1.3 hp Right Angle Tool Series

Dynabrade 1.3 hp Right Angle Tool Series

Product catalog summary

Overview: The document provides detailed information about the Dynabrade 1.3 hp Right Angle Tool Series, which includes grinders and sanders designed for various material removal applications. These tools are suitable for industries such as metal fabrication, masonry, and welding.

Key Features:

Ergonomic Design: Offers operator comfort with an insulated throttle handle and a vibration dampening side handle.
Rotational Exhaust System: Allows 360º rotation to direct exhaust away from the operator.
Robust Air Motor: The 1.3 hp air motor provides powerful performance with governor control.
Safety Features: Includes a safety-lock throttle lever to prevent accidental start-up.
Durability: Cast aluminum construction and a "Wick Lube" system for longer gear life.

Models and Specifications:

Model 52630: 13,500 RPM, accepts 4" Type 27 wheels, includes wheel guard and flanges.
Model 52632: 12,000 RPM, accepts 4-1/2" Type 27 wheels and flap discs, includes wheel guard and flanges.
Model 52633: 12,000 RPM, accepts 5" Type 27 wheels and flap discs, includes wheel guard and flanges.
Model 52631: 12,000 RPM, includes a locking-type backing pad for 4" abrasive discs.
Model 52634: 12,000 RPM, includes backing pad for 4-1/2" abrasive discs.
Model 52635: 12,000 RPM, includes backing pad for 5" abrasive discs.

Applications: The tools are ideal for grinding welds, heavy deburring, rust and scale removal, and surface conditioning. They can also be used for sanding, deburring metal parts, and preparing welds.

Accessories:

Coupler and Plug Assembly: Provides maximum air flow and quick-connect features.
Dynaswivel® Air Line Connector: Enhances tool maneuverability and reduces operator fatigue.
Backing Pads: Available in various sizes and densities for different applications.
Gear Oil and Gun: Included for tool lubrication.

Safety and Maintenance: Always use the required wheel guard, ensure the tool speed does not exceed the accessory's maximum speed, and wear appropriate protective gear.

Contact Information: The document provides contact details for Dynabrade's offices in the USA, Europe, Brazil, and India, along with a toll-free number for US consumers.

Catalog excerpts

Dynabrade 1.3 hp Right Angle Tool Series-1

• Ideal for Grinding Welds and Countless Material Removal Applications • Ergonomic Design Offers the Best in Operator Comfort • Models to Accept Type 27 Grinding Wheels or Abrasive Flap Discs Reorder No. EUR08.08 Dynabrade 1.3 hp Right Angle Tool Series Small Tools Deliver Big Power and Performance

Open the catalog to page 1

Dynabrade 1.3 hp Right Angle Tool Series-2

Type 27 Wheel Sold Separately 2 NEW 1.3 hp Right Angle Tool Series Dynabrade’s 1.3 hp (970 W) Right Angle Grinders and Sanders offer countless grinding and material removal solutions to industries such as metal/stainless steel fabrication, composites, masonry, ironwork and general welding. Designed to the Dynabrade standard of excellence, these tools offer a wide array of features to increase efficiency and maximize operator comfort! Insulated Throttle Handle Reduces cold air transmission to operator’s hand. Handle position is adjustable, increasing comfort and efficiency. Rotational Exhaust...

Open the catalog to page 2

Dynabrade 1.3 hp Right Angle Tool Series-3

3 Model 52630 13,500 RPM, 3/8"-24 Spindle Thread • Tool accepts optional 4" (102 mm) diameter Type 27 Depressed Center Wheels with 5/8" (16 mm) center hole. • Includes 25214 Wheel Guard and two 50359 Universal Flanges. Model 52632 12,000 RPM, 5/8"-11 Spindle Thread • Tool accepts optional 4-1/2" (114 mm) diameter Type 27 Depressed Center Wheels with 7/8" (22 mm) center hole. • Includes 25212 Wheel Guard, 25262 Backup Flange and 53696 Locking Flange. • Tool also accepts optional 4-1/2" (114 mm) diameter Abrasive Flap Discs (flanging sold separately). Model 52633 12,000 RPM, 5/8"-11 Spindle Thread...

Open the catalog to page 3

Dynabrade 1.3 hp Right Angle Tool Series-4

1.3 hp Tool Accessories Coupler and Plug Assembly For Maximum Air Flow to Tool! Part No. 98265 • Provides up to TWICE the standard air flow – tool won’t be “starved.” • Offers convenient quick-connect and disconnect feature. • Recommended for use with all Dynabrade 1.3 hp tools. • Includes one 3/8" NPT female coupler and one 3/8" NPT male plug (also sold separately). Dynaswivel® Air Line Connector Never Fight an Air Hose Again! Part No. 95461 Aluminum, 3/8" NPT • Swivels 360° AT TWO PIVOT POINTS, allowing the air hose to drop directly to the floor while providing superb tool handling. • Improves...

Open the catalog to page 4
