D-EMS 2020

Product catalog summary

Overview: The D-EMS 2020 is a modular system designed for the continuous acquisition, long-term storage, evaluation, and visualization of environmental and process data. It ensures compliance with legal limit values and facilitates data transmission to authorities.

System Configuration: The system is highly configurable to meet plant-specific needs and operator requirements. It is modular, adaptable to future guidelines, and can be expanded with additional software and hardware components.

Core Components: The system's core is an industrial design Server PC equipped with D-EMS 2020 software. It uses server hard disks in a RAID array network to ensure reliability and compliance with a 99% availability requirement.

Data Communication: Communication occurs via the D-MS 500 KE/FC data logger or direct communication with measurement systems.

Features:

Modular system for data acquisition, storage, evaluation, and visualization.
Monitors legal limit values and reports compliance.
Certified by TÜV Rheinland according to EN 15267-2.
Evaluates data based on German, European, and US-EPA regulations.
Adaptable for plants of any size, monitoring up to 1024 components per server.

Data Acquisition and Export:

Supports analog/digital inputs and outputs, with various data transmission interfaces like Modbus, PROFIBUS, and TCP/IP.
Data sources include emission, ambient air, meteorological, water, and process data.
Data can be exported to MS-Excel and transmitted to authorities via the internet.

Data Security: Features include up to 128 days buffer for raw input values, RAID array for increased security, and external backup options.

Internet and Intranet Connectivity: Provides HTML-based presentation of data and reports with password-protected access.

Reporting and Visualization:

Generates daily, monthly, and annual reports, as well as statistics and parameter reports.
Offers flexible visualization options, including alarms and event systems.

Service and Support: DURAG DATA SYSTEMS offers worldwide service, 24/7 support, comprehensive training, and expert consulting.

Company Background: DURAG DATA SYSTEMS has over 40 years of experience in emission and process data evaluation, providing tailored solutions to customer requirements.

Catalog excerpts

DURAG GROUP

Open the catalog to page 1

D-EMS 2020 Environmental + Process Data Management System Modular and up-to-date acquisition and evaluation D-EMS 2020 is a modular system for continuous acquisition, long-term storage, evaluation and visualization of environmental and process data. It monitors the legally given limit values and records their compliance. The collected data are optionally transmitted in parallel to the authorities. The D-EMS 2020 system can be freely configured according to the needs of the plant and the requirements of the operator. The system is modular structured, fulfills the current requirements, is prepared...

Open the catalog to page 2

Data + Facts  Features  Modular system for continuous acquisition, long-term storage, evaluation and visualization of environmental and process data  Monitoring of legally given limit values as well as the reporting of compliance  Emission compliance monitoring and remote data transmission to the authorities  QAL1 certified according to EN 15267-2 by TÜV Rheinland  Evaluation according to German, European and US-EPA based regulations – TI Air, 1., 2., 13., 17., 27., 30. and 31. BImSchV – 2010/75/EU (IED) and 2003/87/EG (GHG) – US-EPA 40 CFR part 60, 63 and 75 – and more…  Monitoring according...

Open the catalog to page 3

Features + Benefits  Data security  Up to 128 days buﬀer of the raw input values in the D-MS 500 KE/FC data loggers on 1s basis  Increased data security and availability through hard disks as RAID array  Storage of raw values (components and status information) on 1s basis  Backup on external medium e. g.: Server / NAS  Internet and Intranet connection  HTML-based presentation of selected values and reports on a web server in the Inter- / Intranet  Password protected access to the stored data and reports Left picture: Display of evaluated values as bar chart incl. limit value comparison...

Open the catalog to page 4

Data management Tailored to customer requirements DURAG DATA SYSTEMS has more than 40 years of experience in supplying soft- and hardware products and solutions for emission and process data evaluation. Our dedicated team of experts will support you in designing your PEMS solution including full-fledged data acquisition and handling systems (DAHS). Support 24/7 Quick, comprehensive + competent Consulting Expert consulting Application know-how Service Qualified service technicians worldwide Training Comprehensive training for maintenance personnel Commissioning Worldwide commissioning by highly...

Open the catalog to page 5

Open the catalog to page 6
