TORQUE AND ANGLE CONTROL SCREWDRIVERS MD Series

As an industrial process expert, we help you meet your challenges. Productivity, safety, quality, industry 4.0 are themes on which we can offer you our expertise and our solutions. Whether in the field of assembly technology, machining or welding, our dedicated and specialized teams accompany your progress and recommend solutions and equipment to reach performance levels in line with your industrial strategy. Expertise Our Field experts propose solutions adapted to your environment and specific needs.. Innovation By developing the products and the services of tomorrow, we offer you new perspectives...

TORQUE AND ANGLE CONTROL SCREWDRIVERS MD Series

Models overview A WIDE RANGE OF ELECTRIC TOOLS WITH TORQUE AND ANGLE CONTROL Among this wide range, you will find the screwdriver model and ergonomics that will allow you to optimize your workstation. Straight screwdrivers MD series • • From 0.01 to 49 Nm Lever start or push to start Pistol screwdrivers MDP series • • • Self-learning mode determines the best parameters to provide the best torque accuracy with the highest possible speed. Highest MTBF thanks to its high quality DC motor. From 0.1 to 49 Nm Trigger start Bottom or top exit cable Angle head screwdrivers MDH series • Spindles for automation...

Models specifications - A / P Options (P: push to start, C or TBC: telescopic cushion, U: top exit cable, D: bottom exit cable) Bit socket (A: Hex 1/4’’, E: half-moon 4 mm, Q: square) Gear ratio (1/16) – 1, 2, 4, 8, 16, 36, 64 Current - 22, 26, 32 Body type ( X: Straight P: Pistol grip, A: Spindle, H: Angle head) Torque and angle current control serie

PRECISE AND ROBUST, THEY ARE DESIGNED FOR HIGH-SPEED VERTICAL TIGHTENING OPERATIONS REQUIRING ACCURACY AND TRACEABILITY. Mini straight screwdrivers - Lever start Designation Delivered without tool cable, M18 diameter for accessories,

Standard straight screwdrivers - Lever start Designation Standard straight screwdrivers - Push to start Designation Delivered without tool cable.

Digital Diror, IDEAL FOR HORIZONTAL TIGHTENING OPERATIONS, TO MEET YOUR PRODUCTION RATES MDP 32.. -. D Bottom exit cable Top exit cable Designation Delivered without tool cable. Square drive with pin socket retainer, square drive with ball available on request for quick change socket.

Bottom exit cable Designation Delivered without tool cable. Square drive with pin socket retainer, square drive with ball available on request for quick change socket.

mini angle head screwdriver A RELIABLE AND COMPACT SOLUTION FOR YOUR HARD-TO-REACH MICROTORQUE APPLICATIONS From 0.15 to 1 Nm All mini angle screwdrivers are equipped with integrated LEDs to illuminate the assembly area. The angle head can be rotated 360° (4 positions: 0°, 90°, 180°, or 270°). The screwdrivers are available with either a quick-release chuck (E6.3) or a quick-change bit (C6.3) connection. You can also choose between a 90° or 120° angle nutrunners. Delivered without tool cable.

Delivered without tool cable. Square drive with pin socket retainer, square drive with ball available on request for quick change socket.

INTEGRATED INTO YOUR AUTOMATED INSTALLATIONS, THEY MEET YOUR PRODUCTION RATES without telescopic with telescopic cushion cushion mini spindles With built-in telescoping cushion Delivered without tool cable. Square drive with pin socket retainer, square drive with ball available on request for quick change socket.

Standard spindlesWithout telescopic cushion Designation Delivered without tool cable. Square drive with pin socket retainer, square drive with ball available on request for quick change socket. Delivered without tool cable. Square drive with pin socket retainer, square drive with ball available on request for quick change socket.

Support foot (optional, not supplied with the controller) Functionalities of the MDC V2 associated controllers • Multilingual menus: German, English, Spanish, French, Czech. • 15 tightening programs (torque and angle control). • Choice of screwing direction of rotation for each program. • Advanced functions with independent settings for each preset : reverse rotation, engaging torque detection, thread tapping, angle after torque-up. • 2 multi-sequences programs, for several presets run with one cycle start. • 15 models for multi-programs counting up to 20 customisable steps. • Color LCD touch...

FeaturesSpecificationsVoltageFuse Input: AC 230 V, 50/60Hz, 2.5 A / Output: DC 38 V 3.5 A Operating environment Front panel 0 ~ 40°C / 15 ~ 80% RH (without dew) 5" LCD color 800 x 480 dots - touch & multilingual menus Inputs/Outputs 8 inputs and 8 outputs assignable + 7 free inputs assigned to models via SUB-D25 port SD card Included one 8 GB SD card - industrial grade SoftwareManagement of firmware update Firmwares Via SD card Controller main board / LCD display French, English, German, Spanish, Czech Via controller front LCD / Web Server / ParaMon software Models Tightening presets Advanced...

Controller communication and display Modbus Protocol RS232 or Ethernet ParaMon Pro X PC - free software - ParaMon Menu Program - Preset (1 to 15) Fastening result OK/NOK Monitoring torque Date and time Torque target Speed target/Monitoring Time Monitoring angle Count target/Monitoring Snug angle

Torque and angle tightening strategies 15 different tightening programs can be set in each MDC controller. Each program can be set with 15 customizable parameters. Tightening direction may be different for each preset. Each preset program has the following customized parameters Tightening mode • Torque control + angle monitoring TC / AM Angle control + torque monitoring AC / TM Torque Target torque, min/max torque, snug torque, seating torque, torque compensation Angle Target angle, min/max angle, free speed angle Speed Target speed, free speed Time Soft start time, torque rising time, torque...
