CORDLESS IMPULSE TOOLS D P TC- 2 s e r i e

PRODUCTIVE SOLUTIONS As an industrial process expert, we help you meet your challenges. 5 reasons to trust us Expertise Productivity, safety, quality, industry 4.0 are themes on which we can offer you our expertise and our solutions. Whether in the field of assembly technology, machining or welding, our dedicated and specialized teams accompany your progress and recommend solutions and equipment to reach performance levels in line with your industrial strategy. Our Field experts propose solutions adapted to your environment and specific needs.. Innovation By developing the products and the services...

CORDLESS IMPULSE TOOLS D P TC- 2 s e r i e

POWER, PRECISION AND COMFORT AWAIT YOU! NEXT-GENERATION TECHNOLOGY This generation of DPTC-2 series hydrostatic screwdrivers is designed around a new motor and a new impulse unit for: A wider torque range up to 210 Nm Less vibration in operator's hand The DPTC-2 cordless impulse screwdrivers are ideal for intensive industrial tightening applications with strict torque tolerances in the range of 19 to 210 Nm! The impulse technology allows quick and precise assemblies while minimizing jerking. Equipped with an automatic shut-off mechanism, they stop immediately once the tightening torque is reached...

Overview Brushless motor with fan (longer service life) Audible (beep) and visual (colored LED) informations on the tightening status (more clearly) Automatic shut-off and engine stop (more precision) Impulses setting according to the assembly type (more precision) Extended shaft for sleeve sockets installation (less vibration) Programmable LED lighting of the workstation (more comfort) Mini USB programming port (more convenience) Programmable reversibility button (more ergonomics) Soft start trigger for better control (more quality) Ergonomic handle to reduce vibrations (more comfort) Powerful...

DPTC-2 impulse screwdrivers - 18 volts From 7 to 60 Nm L Screwdrivers with 1/4'' Hex drive and quick-release chuck Designation Weight without battery (kg) Supplied with a torque adjustment key. The charger and battery are sold separately. HELP CHOOSING Screwdrivers are designed for use with hard and soft joints (up to 180° after the screw is tightened). When using on soft or highly soft joints (> 180° after tightening), choose a screwdriver model that will operate at the bottom of its torque range (e.g., for an soft joint at 30 Nm, DPTC-2-60 model is more suitable than DPTC-2-45 model). The recommended...

DPTC-2 impulse screwdrivers - 36 volts From 39 to 160 Nm L Screwdrivers with 1/2'' square drive Supplied with a torque adjustment key. Charger and battery are sold separately. HELP CHOOSING Screwdrivers are designed for use with hard and soft joints (up to 180° after the screw is tightened). When using on soft or highly soft joints (> 180° after tightening), choose a screwdriver model that will operate at the bottom of its torque range (e.g., for an soft joint at 50 Nm, DPTC-2-90 model is more suitable than DPTC-2-80 model). The recommended use is 6 tightenings per minute, to be balanced with...

Batteries Li-ion battery BB200LI-25 Chargers Dimensions in mm Holster Code Holster GM + adjustable support

Protections and ring Compatibility Screwdriver protection NEW Automatic consecutive tightening and loosening mode: • Step 1 - tightening to torque • Step 2 - loosening by the number of turns set Ideal for installing studs. ► Reading of maintenance cycle counter (resettable) ► Reading of total cycle counter ► Setting of maintenance alarm (number of pulses) ► Setting of buzzer volume (off, low, medium, or high) ► Setting the LED lighting delay (0 to 60 s) in tightening and loosening mode ► Setting the retightening detection with NOK LED display on the back of the screwdriver ► Setting automatic...

Sleeve sockets Our sleeve sockets have been developed to improve ergonomy and quality of our assemblies with impulse screwdrivers. Reduction of vibrations transmitted to the screwdriver, improving operator comfort. Reduction of play between the socket and the screwdriver, thereby limiting oscillation and stabilizing the tightening torque. Reduction of noise generated by the tool. Optimization of the tool’s lifecycle by preventing wear. Drawings of sleeve sockets models

3/8'' sleeve drive socketssleeve drive - 6 point Designation 3/8 '' sleeve drive - 6 point magnetic Designation On request On request On request On request P113218 On request On request P107067 On request P113819 P113486 On request P113821 P112980 On request P172986 On request P172987 On request On request P172988

On request P113191 P108794 On request P107009 On request On request P173004 P173005 On request On request P108937 On request P109067 On request On request P173006 P173007 On request On request On request On request P104912 On request On request P108829 P173008 On request

3/8 '' sleeve drive - 6 point long magnetic A / F (mm) 3/8 '' sleeve drive - 6 point deep magnetic n ■ . ■ A / F D1 D2 L L2 Designation , , Schema , , , , , , , ,

3/8 '' sleeve drive Torx® external n - ^ a / F D1 D2 L L2 Designation , , Schema , , , , , , , , 3/8 '' sleeve drive - Hex driver (Inbus) Designation P172740 P172741 P113738 P103212 P172742 P107030 On request P172743 On request P172744 On request P113752 On request On request

3/8 '' sleeve drive - Stud bolt setters Designation Size Schema , D1 , , D2 , , L , 1/2'' sleeve drive sockets 1/2 '' sleeve drive - 6 point

1/2 ‘‘ sleeve drive - 6 point magnetic A/F (mm) 1/2 ‘‘ sleeve drive - 6 point long A/F (mm)

1/2 ‘‘ sleeve drive - 6 point A/F (mm) 1/2 ‘‘ sleeve drive - 6 point magnetic A/F (mm)

o 1/2 '' sleeve drive - Torx® internal Designation P172860 P172861 P172862 P113687 On request On request P113420 P172863 P172864 On request On request On request On request 1/2 '' sleeve drive - Torx® external Designation On request On request On request On request On request On request On request On request On request
