TDR900

Product catalog summary

Overview: The TDR900 is a sophisticated Circuit Breaker Test System designed for testing various types of circuit breakers. It offers precise performance measurements and supports both simple and complex testing scenarios using a portable, durable instrument.

Benefits:

Rugged and Reliable: Combines laboratory accuracy with field durability.
Comprehensive Test Reports: Outputs in MS Excel™ format.
User-friendly Interface: The T-Doble Software provides an intuitive control panel for efficient testing.
High Accuracy Motion Recording: Utilizes patented transducers for early mechanical problem diagnosis.
Interference Immunity: Maintains accuracy in harsh substation environments.

Features:

Controls trip and close commands for various operations including Trip (O), Close (C), Reclose (O-0.3s-C), and more.
Includes self-diagnostics and supports data management with T-Doble software.
Data can be plotted, analyzed, and printed, with compatibility for importing previous test data.

Accessories:

Doble Current Probes with 20 A / 200 A ranges.
Optional test cables and safety equipment.
External USB Thermal Printer and Mechanical Adapter Clamp Set.

Technical Specifications:

Main Contact and Resistor Switch Timing: Supports up to 4 breaks per phase with a resolution of 100 ms.
Trip/Close Initiation Control: Maximum input current of ± 25 A and voltage of ± 300 V.
Motion Channels: 3 channels with 15-pin connectors and 1.0 kV voltage isolation.
Analog Measurement Channels: 3 channels with various voltage ranges and 12-bit resolution.
Digital Linear/Rotary Motion Transducer: High accuracy and resolution for both linear and rotary measurements.

General Specifications:

Recording capabilities up to 25 seconds at max resolution.
Communication via USB or Ethernet.
Safety features include ground, switch, and audible indications.
Physical dimensions: 24.0 x 15.5 x 8.5 inches, weighing 22 lbs.
Operating temperature range from 0° to 50° C, with storage from -25° to +70° C.

Contact Information: For more details, email [email protected].

Catalog excerpts

Microsoft Word - 4_Tan Delta Measuring_Instruments_TD-Smart.doc table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:13.00pt "Arial", sans-serif; } .font2 { font:17.00pt "Palatino Linotype", serif; } .font3 { font:7.00pt "Verdana", sans-serif; } .font4 { font:7.50pt "Verdana", sans-serif; } .font5 { font:11.00pt "Verdana", sans-serif; } .font6 { font:17.00pt "Verdana", sans-serif; } .font7 { font:141.00pt "Verdana", sans-serif; } mm CIRCUIT BREAKER TEST SYSTEM Performs timing functions for up to 4 breaks per phase with motion measurements for any circuit breaker. The TDR900 is a state-of-the-art Circuit Breaker Test System engineered to test all types of circuit breakers. The TDR900 provides efficient and accurate performance measurements for circuit breakers. It allows simple to complex testing of circuit breakers using a single, rugged, field-portable instrument. TDR900 Benefits: Rugged and Reliable - the TDR900 is a single box solution, providing the accuracy of a laboratory instrument with durability for field use.  Complete Test Reports - provided in MS Excel format. ٕ User-friendly PC interface - the new T-Doble Software with its intuitive control panel provides quick, efficient and simple testing of circuit breakers. High Accuracy Motion Recording - a patented digital rotary and linear transducer proխvide early diagnosis of mechanical problems. Detects main contact and resistor switch timing errors. Օ Other analog transducers supported. Immune to Interference - accuracy of test results is unaffected by the severe conditions of electrostatic and electromagnetic interference, normally present in harsh substation environments. ͕ Controlled by user supplied PC. TDR900 Features: TDR900 controls circuit breaker trip and close commands, allowing the user to perform the following operations: Trip (O) Օ Close (C) Reclose (O-0.3s-C) Օ Tripfree (CO) O-CO Օ O-0.3s-CO First Trip (O) Օ Slow Close (C) Self Diagnostics The TDR900 comes with New T-Doble Software for improved data management capability. Օ Intuitive and clear: easy-to-use test plans and test results Data can be plotted, overlaid, analyzed, and printed Օ Will import all TR3100 and TDR9000 test result data and test plans T-Doble Software (included with the TDR900) allows simple configurable display of results and user configurable reports \ ^ * 1 m

Open the catalog to page 1

Microsoft Word - 4_Tan Delta Measuring_Instruments_TD-Smart.doc table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:13.00pt "Arial", sans-serif; } .font5 { font:5.00pt "Tahoma", sans-serif; } .font6 { font:5.00pt "Verdana", sans-serif; } .font7 { font:6.00pt "Verdana", sans-serif; } .font8 { font:7.00pt "Verdana", sans-serif; } .font9 { font:9.00pt "Verdana", sans-serif; } Motion Channels Number...

Open the catalog to page 2
