Diodes Incorporated
BIPOLAR TRANSISTORS

BIPOLAR TRANSISTORS

Product catalog summary

Company Overview: Diodes Incorporated is a leading global provider of discrete and analog semiconductors, with significant operations in China, Europe, and the USA. The company emphasizes product innovation, cost efficiency, strategic acquisitions, and superior customer service. Its extensive product range includes Bipolar Transistors, MOSFETs, and Schottky diodes.

Bipolar Transistor Portfolio: Diodes Incorporated is a market leader in Bipolar transistors, bolstered by the acquisition of Zetex Semiconductors in 2008. The portfolio features innovative matrix emitter processes, offering transistors with ultra-low saturation, fast switching, and reduced power dissipation, providing cost-effective alternatives to MOSFETs.

Performance and Applications: The transistors are designed for low saturation voltage and reduced die area, enhancing switching performance and enabling smaller surface mount packages. They are robust against ESD and have low specific on-resistance, suitable for various circuit topologies. Specific applications include Avalanche transistors, Gate drivers, and H-bridge devices.

Quality and Standards: Most products comply with the Automotive Electronic Council specification AECQ101, and all packages are available with environmentally friendly 'green' mold compounds.

Product Features: The latest generation of Bipolar transistors offers lower specific on-resistance than MOSFETs, with industry-leading low saturation voltage and high current handling capability. They also feature reduced switching losses and high minimum gains to minimize base drive requirements.

Product Index: The document provides detailed specifications for various transistors, including NPN and PNP transistors across different voltage ranges, dual transistors, gate driver transistors, avalanche transistors, and more, with specific part numbers and technical parameters.

Specifications: Each transistor is detailed with part number, collector-emitter voltage (VCEO), collector current (IC), peak collector current (ICM), power dissipation (PD), current gain (hFE), collector-emitter saturation voltage (VCE(sat)), transition frequency (fT), and package type. These specifications are essential for selecting the appropriate transistor for specific applications.

Applications: The transistors are suitable for a wide range of applications, including high-temperature environments, due to their robust design and high power ratings. They can replace popular industry parts, offering competitive performance.

Data Interpretation: Tables provide detailed electrical characteristics for each transistor model, allowing engineers to compare and select components based on specific needs such as voltage, current capacity, and thermal performance. Notes on package types indicate their suitability for surface mount applications and high-temperature operations.

Conclusion: This brochure serves as a comprehensive guide for selecting NPN and PNP transistors within the specified voltage range, offering detailed specifications and highlighting the benefits of various package types for different applications.

Key Features:

PowerDI®5 package offers a smaller footprint and high power rating.
Gate driver transistors feature low propagation delays and high current capabilities.
Transistor-Schottky combinations provide compact solutions for DC-DC converters.

Catalog excerpts

www. LEADING EDGE TECHNOLOGY SUPPORTED BY EXTENSIVE PACKAGING CAPABILITY BIPOLAR TRANSISTORS

Open the catalog to page 1

Page 2 Semiconductors in 2008, the company has enhanced its cost competitive small signal transistor portfolio with “best in class” transistor technology from Zetex. By utilizing its wide line up of in-house packaging and superior silicon technology, Diodes is ideally positioned to meet your application needs for Bipolar transistors. Continued Innovation The Bipolar transistor portfolio is built on successive generations of our innovative matrix emitter process. Years of know-how, leading edge designs and process innovation have extended our leadership in building ultra-low saturation, fast switching...

Open the catalog to page 2

PNP Transistors up to 25V 6 Dual PNP Transistors up to 25V 7 NPN Transistors 30V to 50V 7 Dual NPN Transistors 30V to 50V 9 NPN & PNP Transistors 30V to 50V 9 PNP Transistors 30V to 50V 9 NPN Transistors 55V to 100V 11 NPN & PNP Transistors 55V to 100V 12 PNP Transistors 55V to 100V 13 Dual PNP Transistors 55V to 100V 14 NPN Transistors >100V 14 PNP Transistors >100V 15 Gate Driver Transistors 16 Avalanche Transistors 16 H-bridge Transistors 17 Darlington Transistors 17 Transistor & Schottky Combinations 18 Industry Standard Transistors NPN Transistors 19 PNP Transistors 20 NPN & PNP Transistor...

Open the catalog to page 3

Page 16 VIN=12.5V, RS= Part Number Product Type VCBO V VCEO V ICM A PD W ISA @ VC @ CCE A V pF hFE Min. @ IC mA Avalanche Transistors FMMT413 NPN 150 50 50 0.33 25 130 4700 50 10 ZTX415 NPN 260 100 60 0.68 25 250 620 25 10 FMMT415 NPN 260 100 60 0.33 25 250 620 25 10 FMMT417 NPN 320 100 60 0.33 25 250 620 25 10 Product features THE DIODES ADVANTAGE Gate driver transistors Did you know? The ZXGD3000 series Gate driver transistors are characterized under true operating conditions. Compact SOT23-6 package. Emitter follower configuration. Propagation delays <2ns. No latch up. Up to 1.85A source and...

Open the catalog to page 16

Page 18 Product features THE DIODES ADVANTAGE Did you know? Our Transistor and Schottky Diodes combined in the DFN package offer a compact solution for DC-DC converter applications. Package footprint just 3 x 2mm. Offers excellent power density. NPN and PNP options with Schottky diode. Low saturation and fast switching transistor for improved efficiency.

Open the catalog to page 18

BTB 1 | Apr 2010 www. CORPORATE HEADQUARTERS AND AMERICAS SALES OFFICE 15660 N. Dallas Parkway, Suite 850, Dallas, TX 75248 USA Tel: 972-385-2810 E-mail: [email protected] EUROPE SALES OFFICE Kustermann-Park Balanstrasse 59, 8th Floor D-81541 Munchen, Germany Tel: (+49) 89 45 49 49 0 Fax: 89 45 49 49 49 E-mail: [email protected] ASIA SALES OFFICES Email: [email protected] DIODES-TAIWAN 7F, No. 50, Min Chuan Road, Hsin-Tien, Taipei, Taiwan, R.O.C. Tel: 886-2-8914-6000 Fax: 886-2-8914-6639 SHANGHAI OFFICE Rm. 606, No.1158, Changning Road Shanghai, China Tel: 86 21-5241-4882...

Open the catalog to page 24
