EH TRuck Drives
EH TRuck Drives
The document provides specifications for a series of models: EH 5000 SC, EH 6000 SC, EH 8000 SC, EH 11000 SC, EH 16000 SC, EH 22000 SC, EH 26000 SC, and EH 33000 SC. Key specifications include:
- Maximum Output Torque: Ranges from 50,000 Nm to 330,000 Nm.
- Preferable Ratio (i): Varies from 125.7 to 252, with different ratios available on demand.
- Weight: Ranges from 220 kg to 1250 kg.
- Capacity of Bearings: Dynamic capacity (C) ranges from 212 kN to 1120 kN, and static capacity (C0) ranges from 425 kN to 2550 kN.
Static braking torque ranges from 720 Nm to 2500 Nm.
Available motor connections include models such as A2FE and A6VE, with various configurations like 80/61W-NAL and 107/63W-VZL.
Dimensions are provided for various parts of the models, including:
- Diameter (ØA to ØF): Measurements range from 270 mm to 785 mm.
- Other Dimensions (G to T): Measurements include G (39.5 mm to 150 mm), H (82 mm to 170 mm), I (281.5 mm to 430 mm), L (403 mm to 705 mm), and others.
Alternative configurations and different ratios are available on demand for the SC version.
Catalog excerpts
Alternative configurations available on demand (*) Preferable ratio (i) Weight (Approx.) Capacity of bearings C dynamic C0 - static Multi-disc brake Static braking torque Maximum output torque Hydraulic motor Available motor connection: Available motor connection: Dimensions ØA [mm] 270 h8 350 h8 ØB [mm] 310 400 ØC [mm] 350 445 ØD [mm] 350 h8 400 h8 ØE [mm] 400 450 ØF [mm] 430 490 G [mm] 39.5 25 H [mm] 82 90 I [mm] 281.5 294 L [mm] 403 409 M [mm] 25 30 N [mm] 25 33 O [mm] 30 31 P N°20-M20x1.5 N°24-M24x2 R N°16-M20x1.5 N°20-M20x1.5 S [mm] 54 48 T [mm] 111 117 (*) Different ratios available on...
Open the catalog to page 3
Mail: [email protected] - www.dinamicoil.com
