Excavator Digga

Catalog excerpts

Excavator Attachment Range Volume 9 Australia’s Leading Award Winning Attachment Manufacturer

 Open the catalog to page 1

About Digga™ 100% Australian owned, Digga are Australia’s largest manufacturer and exporter of gearboxes and attachments for the earthmoving machinery industry. Formed in 1981 by founder, Chairman & Director of Research & Development, Stewart Wright, Digga pioneered Pendulum Drilling in Australia and today produce the largest range of compact high torque planetary drives for the Pendulum drilling & attachment industry. Digga are a Multi-award winning company both for product design and business practices, recognised for their Innovative approach to leading edge design and manufacturing...

 Open the catalog to page 2

Contents Digga Premium Drives 4 Excavator Auger Drive Units 5 Swing Control System 6 Augers, Extensions and Adaptors 7 Wear Parts - Padloc® 7 Wear Parts - Teeth and Pilots 7 I-Drive - World First Technology 8 Supa Drives, Mega Drives & Ultra Drives 9 Swoosh Valve - Screw Anchor Bypass Valve 11 Diggalign - Drilling Alignment System 11 Rhino Hitch 11 Bigfoot Trencher Range 12 Hydrive Trencher Range 13 Australia’s Leading Award Winning Attachment Manufacturer Digga’s 12,500m2 (130,000 sq ft) state of the art manufacturing facility, Brisbane Australia.

 Open the catalog to page 3

4 | Char-Lyn Extreme duty shaft locking system - Lifetime Warranty* * Subject to dealer warranty specifications. Features: Compact high torque gearboxes for machines f >> rom 750kg up to 50 Tonne >> In built Pressure Relief standard on models PDPHF, D8HF, PD10HF, PD12 - PD50. >> Powered by high quality Eaton hydraulic motors - high torque, high efficiency performance. >> 3 year gearbox & hydraulic motor warranty. >> Full range of output shafts available upon request. Ideal Use: Augering, drilling, tree planting, fencing, foundations, sound barriers and more. Digga Premium Drives Digga’s New...

 Open the catalog to page 4

6 Features Unique independant dampening c >> ylinders control forward/aft and side to side movement. >> Compact, low maintenance. >> Adjustable levels of dampening. >> Increase efficiency. >> Increase productivity. >> Increase safety. Swing Control can be retrofitted to existing auger drives. Whilst it dampens the swing it still allows the movement required for excavator mounted pendulum drilling both forward/aft and side to side. Its unique design means the faster you move the quicker the drive unit stops. SCS controls the pendulum action of your auger making your auger easier to operate...

 Open the catalog to page 6

7 PS-1 PS-2 PS-3 PM-1 PM-2 PM-3 PM-SQ-1 PM-SQ-2 PM-HX-1 PH-3 Teeth and Pilots: Earth - standard, durable and c >> ost effective for light to moderate ground conditions. >> TC - flat tungsten carbide braised to your wear parts ensures longer life. >> MFT - multi faced tungsten carbide, for difficult medium to heavy solid ground conditions, compacted soils, heavy clay, asphalt, concrete, frozen ground. Padloc: >> Bonded friction pads already fitted to your auger teeth ensures you’re locked in tight. >> 1 step process - knock in knock out. >> No special tools required. >> Fits most types of...

 Open the catalog to page 7

8 High capacity compact hydraulic drive system for screw anchor/core barrelling and foundation drilling. Features >> No Case Drain required >> No complex hose, valving or filtration >> No de-tuning of machine required >> In built Pressure Relief Valve standard >> 1-2 and 3 speeds available up to 1,000 lpm Patent Pending Fully Australian designed and manufactured, the world first Digga ‘I-Drives’ are high capacity, compact, hydraulic drive systems fitted to Digga hi torque planetary gearboxes. Designed to fit 12 – 50 tonne excavators for the installation of ground screw anchors, core...

 Open the catalog to page 8

9 Supa Drives 25,000Nm - 95,000Nm Mega Drives 100,000Nm - 200,000Nm Ultra Drives 200,000Nm - 300,000Nm Features Heavy duty Australian made Digga p >> lanetary gearboxes. >> Extreme duty shaft locking system (lifetime warranty*). >> Engineered hood & linkage design for maximum strength & durability. >> The most compact high powered drive on the market today. Eg. Total size of a complete 300,000nm power head is just 670mm in diameter and 1.8mtrs tall. SUPA DRIVES, MEGA DRIVES & ULTRA DRIVES Fitted with the world first I-Drive hydraulic motor system these units are able to utilise the total...

 Open the catalog to page 9

11 How it works: If the drilling attachment moves off centre the Diggalign system will alert the operator by illuminating the yellow LED lights, allowing the operator to return the auger to a vertical and plumb position. Once the operator corrects this condition, the green centre LED will illuminate again. Digital display units are available in: Standard definition - 2° Increments “ >> suitable for drives and piles under 5-6mtrs” >> High definition - 0.5° Increments “suitable for drives and piles over 5-6mtrs” Features: >> Easy read LED display. >> Micro Chip inclometer. >> Quality Deutz...

 Open the catalog to page 11

12 Bigfoot Trencher Range A compact, yet powerful planetary drive trencher fitted with an adjustable skid foot to maintain consistent digging depths and a single spoil removal auger for efficient spoil removal to one side of the trench. Features: Quality Digga New Generation g >> earbox & motor. >> High quality bearings and components. >> Full range of chain options available. >> Frame can be side shifted for digging close to permanent structures ie; buildings, trees etc. Ideal Use: Pipe laying for irrigation, underground power and communications, road repairs, removal of trees and general...

 Open the catalog to page 12

13 Hydrive Trencher Range The Hydrive trencher range are fitted with twin spoil removal augers for efficient spoil removal to both sides of the trench. Spoil Augers can be removed for close up trenching. Hydrive XD Trencher Excavators 4.5T - 8T Hydrive XD for the serious operator performing heavy duty trenching up to 1200mm digging depth and 350mm digging width. Fitted with a 2” chain and a heavy duty steel crumber bar. Model Chain Length Cutting Depth Cutting Width Max Flow (LPM) Max Pressure (BAR) Hydrive 900mm up to 900mm 100 - 300mm 45-75 240 1200mm up to 1200mm 100 - 300mm 50-80 240...

 Open the catalog to page 13
