SAE 100 R4 Hose
Product catalog summary
Product Overview:
TrAle Hydraulic hoses are designed according to SAE 100 R4 standards. They are composed of a special NBR rubber inner tube resistant to hydraulic oil, reinforced with two textile braids and one steel wire helix, and covered with black rubber resistant to oil, abrasion, and weather conditions. The working temperature range is from -40º C to +100º C.
TrAle Hydraulic hoses are designed according to SAE 100 R4 standards. They are composed of a special NBR rubber inner tube resistant to hydraulic oil, reinforced with two textile braids and one steel wire helix, and covered with black rubber resistant to oil, abrasion, and weather conditions. The working temperature range is from -40º C to +100º C.
Specifications:
- Inner Tube: Special NBR rubber
- Reinforcement: Two textile braids with one steel wire helix
- Cover: Black rubber resistant to oil, abrasion, and weather
- Working Temperature: -40º C to +100º C
Technical Data:
| Part Number | DN | Ø in | Ø out | Working Pressure (bar/psi) | Burst Pressure (bar/psi) | Vacuum (bar) | Bending Radius (mm) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|
| ML701019 | 3/4" | 19 | 32 | 21/305 | 84/1218 | -0.8 | 127 | 0.725 |
| ML701025 | 1" | 25.4 | 37.4 | 17/247 | 68/986 | -0.8 | 152 | 0.847 |
| ML701032 | 1''1/4 | 31.8 | 45 | 14/203 | 56/812 | -0.8 | 203 | 1.118 |
| ML701038 | 1''1/2 | 38.1 | 52 | 10/145 | 40/580 | -0.8 | 254 | 1.454 |
| ML701050 | 2" | 50.8 | 64 | 7/102 | 28/406 | -0.8 | 305 | 1.837 |
| ML701063 | 2''1/2 | 63.5 | 77 | 4/58 | 16/232 | -0.8 | 356 | 2.310 |
Important Notes:
The information provided in this catalogue is for informational purposes and may be modified without prior notice. DICSA is not responsible for any misuse of the product, except for manufacturing defects.
The information provided in this catalogue is for informational purposes and may be modified without prior notice. DICSA is not responsible for any misuse of the product, except for manufacturing defects.
Document Date: Printed on 02/08/2014 at 00:16
See more
Catalog excerpts
Hydraulic hoses TrAle TrAle Hydraulic hoses Working temperature ·Inner tube: special NBR rubber resistant to hydraulic oil. ·Reinforcement: two textile braids with one steel wire helix. ·Cover: black rubber resistant to oil, abrasion and weather. From -40º C to +100º C. The information gathered in this technical documentation (Catalogue) has an informative character and can be modified without previous notice. DICSA will not accept any type of responsibility resulting from an inappropriate use of the product, except the ones related to manufacturing defects.
