Product catalog summary

Introduction
Diamond Systems is a prominent provider of rugged PC/104 I/O modules, CPUs, and system solutions for embedded applications, emphasizing quality and customer-centric services.

ETX Solutions
Diamond Systems offers cost-effective ETX solutions like the Chameleon ETX baseboard, integrating multiple PC/104 I/O modules for rapid market deployment.

CPU-Plus
The company provides unique SBCs combining low-power CPUs with data acquisition technology, featuring Gigabit Ethernet and USB 2.0 for enhanced reliability and performance.

Advanced Rugged PC/104 I/O Modules
Diamond Systems offers PC/104 I/O modules with autocalibrating A/D technology and FPGA-based GPIO-MM digital I/O modules for high I/O density.

Customization and Integration Services
Customization services range from minor adjustments to full custom designs, with integration into custom or off-the-shelf enclosures.

Rugged and Reliable Design
Products are designed for harsh environments, featuring extended temperature operation, soldered-on memory, fanless operation, and solid-state flash disk storage.

AutoCalibration
Autocalibration reduces analog I/O errors, with auto-autocalibration automating the process using a built-in temperature sensor and microcontroller.

Integrated Solutions
Diamond Systems provides complete system solutions from concept to manufacturing, including hardware sub-assemblies and system enclosures.

Hardware Solutions
Offers board-level and system-level solutions with rugged enclosures, custom front panels, and I/O connector boards to enhance durability and reduce cable usage.

Software Solutions
Universal Driver Software and Development Kits for Linux and Windows CE facilitate quick application development and compatibility across I/O boards.

Single Board Computers (SBCs)
Diamond Systems' SBCs integrate CPU, PC I/O, and data acquisition circuitry, supporting various form factors and offering features like USB 2.0 and Gigabit Ethernet.

Product Features
Includes models like Hercules II, Poseidon, and Athena II, each with specific CPU, RAM, and I/O configurations, designed for extreme conditions.

Data Acquisition Capabilities
SBCs offer high accuracy data acquisition with features like auto-calibration and programmable gain, suitable for industrial and military applications.

Enclosure Systems
Rugged enclosures like Pandora and Triton provide cable-free designs for easy assembly and expansion, supporting multiple CPU boards.

Mass Storage Options
Includes IDE FlashDisk modules and CompactFlash Adapter Kits for rugged and flexible storage solutions.

PC/104 I/O Modules
Offers a range of modules with analog and digital I/O, serial communications, and networking options for high performance and reliability.

Networking and Serial Communications
Modules like JANUS-MM and Emerald-MM offer dual CAN ports, wireless communication, and high baud rate serial communication capabilities.

USB and Ethernet Interfaces
Modules like TMM-USB4P and Mercator provide USB 2.0 ports and dual Ethernet ports for high-speed data transfer and flexibility.

Power Supplies
Jupiter-MM series offers rugged power supply modules with various output configurations, designed for stability and protection.

Battery Packs and Accessories
PC/104 form factor rechargeable battery packs and accessories provide reliable UPS solutions, with various configurations and capacities.

Catalog excerpts

FeatureGPIO-MM /GPIO-MM-21 Onyx-MM / Onyx-MM-DIOGPIO-MM-12 Digital I/O Lines 48 programmable direction,96 programmable 48 programmable direction 8 inputs,8 outputs direction (48 buffered) DIO Input Voltage Logic 0:-0.5V min,0.8V maxLogic 0:-0.5V min,0.8V maxLogic 0:-0.5V min,0.8V maxLogic 1:2.0V min,5.5V maxLogic 1:2.0V min,5.5V maxLogic 1:2.0V min,5.5V max DIO Output Voltage Logic 0:0.0V min,0.2V maxLogic 0:0.0V min,0.2V maxLogic 0:0.0V min,0.4V max Logic 1:3.1V min,3.3V maxLogic 1:3.1V min,3.3V maxLogic 1:3.0V min,Vcc-0.4V max Program.I/O Output Logic 0:64mA Logic 0:64mA 2.5mA per line Current...

Open the catalog to page 23

CAN CIRCUIT CAN Channels 2,2.0B Controller Philips SJA1000T Transceiver Philips 82C251 Isolation 500V channel to channel Transceiver Power 5V,on-board or loop Clock Rate 16MHz Data Rate 1Mbps Bus Interface Memory or I/O WIRELESS MODULES Manufacturer MultiTech SocketModem Type GSM/GPRS or CDMA Interface TTL serial GPS MODULES > Manufacturer Trimble Navigation Model Lassen SKII 8 channel Lassen IQ 12-channel Interface 1 or 2 channel TTL serial GENERAL Dimensions 3.55" x 3.775" (90mm x 96mm) PC/104 Bus 16-bit stackthrough ISA bus Power Supply +5VDCձ5%@77mA (w/o modules) Operating Temp -40 to +85C...

Open the catalog to page 25
