DETAS Catalogue 2009
164Pages

{{requestButtons}}

Catalog excerpts

DETAS Catalogue 2009 - 2

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 2 La storia I l marchio Detas è relativamente giovane, ma l’esperienza e la professionalità è stata tramandata di generazione in generazione fin dal 1896 quando a Pola (Istria) nacque la prima azienda che produceva materiali e sistemi elettrici. Le commesse per la Marina Italiana consentirono una notevole evoluzione tecnologica dell’azienda, determinando la specializzazione dei nostri prodotti e servizi. Lo sviluppo del settore industriale, ci ha spinto...

Open the catalog to page 2
DETAS Catalogue 2009 - 3

02-2009-SD-VER 1.0 I N D E X I N D I C E © 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 3 ALIMENTATORI - Power supplies FILTRI ANTIDISTURBO - Transient suppressors FILTRI DI RETE - Line filters MODULI A RELÈ - Relays modules DISPOSITIVI LUMINOSI - Lighting devices RISCALDATORI DI QUADRO ELETTRONICA DI POTENZA E DI CONSUMO HAAKE / SISTEMI DI SICUREZZA REO / ELETTROTECNICA INDUSTRIALE ICOTEK / SITEMI DI PASSAGGIO CAVO ICOTEK / SITEMI DI FISSAGGIO CAVO ICOTEK / SITEMI EMC Pag. 4 Pag. 44 Pag. 59 Pag. 74...

Open the catalog to page 3
DETAS Catalogue 2009 - 4

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 02-2009-SD-VER 1.0 4 P O W E R S U P P L I E S A L I M E N T A T O R I Terminali d’uscita Output Terminals Doppio morsetto per ogni polarità Per una connessione in parallelo facilitata o per utilizzare cavi di sezione minore Double connection for each pole for easy parallel connection or to use smaller coductors Terminali d’uscita Rdy Output “Rdy” Terminals Contatto pulito per monitorare l'uscita Ralay contact for output monitor Griglia di raffreddamento...

Open the catalog to page 4
DETAS Catalogue 2009 - 5

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 02-2009-SD-VER 1.0 5 P O W E R S U P P L I E S A L I M E N T A T O R I ALIMENTATORI STABILIZZATI SWITCHING GSA SWD SWITCH MODE POWER SUPPLIES GSA SWD 0.2 GSA SWD 0.75 GSA SWD 01 GSA SWD 02 GSA SWD 05 GSA SWD 10 GSA SWD 20 GSA SWD 305 GSA SWD 310 GSA SWD 320 GSA SWD 340 VOUTDC [V] 5 W 18 W 30 W 60 W 120 W 240 W 480 W 120 W 240 W 480 W 960 W 5 1 A * * 10 A - - - - - - - 12 * 1.5 A * 5 A 10 A - - * - - - 15 * * - - - - - - - - - 24 * * 1.3 A 2.5 A 5 A 10 A...

Open the catalog to page 5
DETAS Catalogue 2009 - 6

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 02-2009-SD-VER 1.0 6 P O W E R S U P P L I E S A L I M E N T A T O R I Specifiche tecniche Specifications Modulo convertitore AC/DC, montaggio su guida DIN 5 Watt Ingresso universale 90÷265 Vac Efficienza fino a 72% Protezione per il corto circuito Protezione sovratensione (125%...145%) Protezione sovraccarico (110%...135%) Ingresso filtrato GSA SWD0.2 stabilizzati switching classe 2 (UL1310) monofase single phase class 2 switch mode (UL1310) Specifiche...

Open the catalog to page 6
DETAS Catalogue 2009 - 7

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 02-2009-SD-VER 1.0 7 P O W E R S U P P L I E S A L I M E N T A T O R I Configurazione PIN PIN assignment Come ordinare How to order Schema di principio Circuit schematic 115 V- V+ DC Output LO ON Vout ADJ. 2 1 3 4 5 N 22.5 90 L Vo - L Vo + N Fuse Control Switching Device Line Filter Inrush Current Limiter and Rectifier Rectifier Current Detection Opto - Isolation Opto - Isolation Output Level Detection Reference & Error Amp. Over Voltage Detection Y Vout...

Open the catalog to page 7
DETAS Catalogue 2009 - 8

Specifiche generali - General specifications Frequenza di switching - Switching frequency 100 kHz Tensione di isolamento - Withstand voltage 3000 Vac (In/Out) Resistenza di isolamento - Isolation resistance 100 MÙ (@ 500 Vdc) Temperatura d’esercizio - Temperature rating -25 ... +71°C Umidità relativa - Relative humidity 20% ... 95% RH Dimensioni e peso - Dimension and weight L90 x W22.5 x D115; 0.150 kg Tipo di raffreddamento - Cooling type Convezione naturale - Free air convection Derating Da +61 a +71°C 3%/°C - From +61 to +71°C 3%/°C Efficienza tipica - Efficiency (typical) 72% Tipo di...

Open the catalog to page 8
DETAS Catalogue 2009 - 9

Configurazione PIN PIN assignment Come ordinare How to order Schema di principio Circuit schematic Vo - L Vo + N Fuse Control Switching Device Line Filter Inrush Current Limiter and Rectifier Rectifier Current Detection Opto - Isolation Opto - Isolation Output Level Detection Reference & Error Amp. Over Voltage Detection Y Vout ADJ. DC ON (Green LED) DC LOW (Red LED) GSA SWD0.75 stabilizzati switching classe 2 (UL1310) monofase single phase class 2 switch mode (UL1310) Modello Model Codice prodotto Code VIN AC [V] VOUT DC [V] IOUT [A] Peso [kg] Weight [kg] GSA SWD0.75/12 002332 90÷265 12...

Open the catalog to page 9
DETAS Catalogue 2009 - 10

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 02-2009-SD-VER 1.0 10 P O W E R S U P P L I E S A L I M E N T A T O R I Specifiche tecniche Specifications Modulo convertitore AC/DC, montaggio su guida DIN 30 Watt, uscita in Classe 2 Ingresso universale 90÷265 Vac Alta efficienza (fino a 84%) Protezione per il corto circuito Protezione sovraccarico (105%...125%) Ingresso filtrato GSA SWD01 stabilizzati switching classe 2 (UL1310) monofase single phase class 2 switch mode (UL1310) Specifiche generali -...

Open the catalog to page 10
DETAS Catalogue 2009 - 11

© 2009 DETAS SpA - Via Treponti, 29 - 25086 Rezzato (BS) ITALY Tel. +39 030 2594120 - Fax +39 030 2792864 - info@detas.com - www.detas.com 02-2009-SD-VER 1.0 11 P O W E R S U P P L I E S A L I M E N T A T O R I Dimensioni [mm] Dimensions [mm] Configurazione PIN PIN assignment Come ordinare How to order Schema di principio Circuit schematic GSA SWD01 stabilizzati switching classe 2 (UL1310) monofase single phase class 2 switch mode (UL1310) Curva di derating Derating curve Modello Model Codice prodotto Code VIN AC [V] VOUT DC [V] IOUT [A] Peso [kg] Weight [kg] GSA SWD01/24 002301 90÷265 24...

Open the catalog to page 11
