DESBOER (Jiangsu) Robotics Technology Co., Ltd. A: No. 8 Chenyang Road, Lljla Town Industry zone, Wujin District, Changzhou T: +86-519 85268111,89187111 F: +86-519 85269111,89188111 E: [email protected] Export: [email protected] [email protected] http://www.desboer.com Professional Supplier For Transmision Equipments And Solution EXTREME AND WIN Strain wave gearbox DESB0ER* Comprehensive Catalogue - 2025 Edition

Harmonic gear reducer core product DESBOER (Jiangsu) Robotics Technology Co., Ltd. was officially established in Changzhou, Jiangsu Province in 2024. Since its establishment, the company has been dedicated to the field of DESBOER high-precision strain wave gearbox, committed to providing customers with a one-stop product service experience covering R&D, production and sales. The company has always prioritized the applicability and reliability of its products and established a strict quality control system. The factory is equipped with top-notch processing equipment from Japan and Germany, and...

Corporate Philosophy In the future, DESBOER will continue to commit itself in exploration and innovation, and always uphold these philosophies. What you need is just what we specialize in ! Our products will benefit you Our professional support ensures a better beginning for you Our customized repair service makes fast repair with reliable quality available to you As one of the few mechanical drive system manufacturers in the world, we always stand by our core enterorise value of providing customers with products of the highest quality, and firmly believe that quality is key toan enterprise's...

Quality Contro We implement 5S management mode on site. The planetary gears and sun gears we provide are made of super-hard processing by Japanese precision hobbing machines and have the characteristics of high operating accuracy, good stability, high efficiency, high input speed, high output torque, low backlash and low noise. High precision of our products effectively guarantees the stability even in long-time operation.

Solutions Listening, understanding, calculation, optimization and formulating customized solutions for customers-for DESBOER, professional and meticulous engineeringdesign is indispensable from the very beginning to thevery end. Utilizing Japan's and Germany's sophisticatedgear manufacturing techniques and experience andbased on customers' special requirements on products,DESBOER's R&D department gratifies each cus-tomer'sindividual needs by offering customized products withoutstanding cost performance. Following this principle,we analyze key parameters including operating conditions, operation...

Committed to becoming a strain wave gearbox that continuously provides first-class products EnterpriseMission Keep on researching core technologies and make contributions to the society. Create corporate culture as respecting each other and making progressby learning from each other. We customize high-precision, high rigidity, and high torque strain wave gearbox for our customers. Put customer value in our first place, to provide high-quality products andservices.

Related Fields > Currently, our products have been widely used in various industries, such as machine tools, robotic arms, printing equipment, textile machinery, packaging machinery, non-standard automation, medical equipment, inspection equipment, laser cutting, welding, automobile manufacturing, satellite communication, metal processing, pharmaceutical industry, etc.

DESB0ER* DESBOER Qiangsu) Robotics Technology Co.# Ltd. DESBOER Qiangsu) Robotics Technology Co., Ltd. • DESB0ER Table of Contents Naming Rules------------------------------------------------------P14 Strain Wave Gearbox Series Product Catalog----------------------------PI 5-PI 7 Strain Wave Transmission Principle---------------------------------------PI 8 Technical Data Explanation of Common Terms for Strain Wave Gearboxes---------------------PI 9 Common Connection and Fixing Methods of Wave Generators------------------P21 Installation Notes for Wave Generators------------------------------------P22...

DESBOER Qiangsu) Robotics Technology Co., Ltd. " DESBOER • Regular Products O Consult Our Company x Vacant —Under Development Strain Wave Transmission Principle ■ Composition of Strain Wave Transmission Device The Strain Wave transmission device is mainly composed of three basic components: wave generator, flexspline and circular spline Wave Generator: Composed of a flexible bearing and a cam, it is the input end of the Strain Wave Gearbox. The inner ring of the flexible bearing is mounted on the cam, and the outer ring forms a wave curve through elastic deformation Flexspline: An elastic part...

DESBOER Qiangsu) Robotics Technology Co., Ltd. " DESBOER Explanation of Common Terms for Strain Wave Gearboxes Selection Process ■ Rated Torque: The rated torque refers to the allowable continuous load torque when the input speed is 2000r/min ■ Allowable Maximum Torque During Start/Stop The allowable maximum torque during start/stop refers to the maximum torque allowed by the Strain Wave Gearbox when starting or stopping ■ Allowable Maximum Average Load Torque The allowable maximum average load torque refers to the maximum torque at which the Gearbox can maintain normal operation. Exceeding this...

Installation Notes for Wave Generators Common Connection and Fixing Methods for Wave Generator 3. Fixing to Wave Generator with Connection Gasket, then Connecting to Input Shaft The input shaft has no shoulder. A connection gasket must first be fixed to the wave generator before connecting and fixing to the input shaft. • Wave Generator Installation Direction NCGS/NCGD Series Installation Wave Generator Wave Generator ♦ Install the circular spline and flexspline to the device first, then insert the wave generator. Installing out of order may cause gear meshing idling or tooth surface damage....

The diameter of the mounting flange shown in Figure 2202-1 must not exceed the boss diameter of the elastic toothed cup, and the flange part closely attached to the diaphragm should have an "R" surface. If the diameter is too large or lacks an "R" surface, it may cause diaphragm damage. Please strictly observe this. Dimensions of Mounting Flange: u^2201'1 Flexspline Installation PrecautionsMaterial and Hardness of Mounting Flange To avoid bolt sinking or loosening caused by surface pressure between the bolt bearing surface and the flange, please use the following material and hardness. Material:...
