Overview: The document provides comprehensive information on Demmeler's 3D clamping systems and welding tables, emphasizing their modularity, precision, and adaptability for industrial applications. It highlights the benefits for both small and large-scale projects.

High-Precision Measurement: Demmeler ensures high precision in product requirements using 3D coordinate measuring machines, laser measuring systems, and optical test equipment.

Modularity and Expansion: The 3D clamping system is modular, allowing for expansion and connection with other tables to form larger work surfaces.

Clamping System Benefits: Features include a non-slip handle, a hexagonal spindle for perfect clamping, and a modular design for various clamping options. The system includes interchangeable pressure plates.

Patented Quality: Demmeler's systems are patented and awarded for their high clamping force, ergonomic design, and quality materials.

System Sizes: Two system sizes, D28 and D16, cater to different applications, with D28 for large weldments and D16 for delicate tasks.

Product Lines: Demmeler offers Profi Line, Expert Line, and EcoLine welding tables, each with precision scaling and modular expandability.

Product Specifications: Detailed specifications include dimensions, weight, and load capacity, with various leg options available.

3D Welding Table Okto: Designed for use with manipulators in robot cells, offering multiple clamping options and optional high-strength materials.

Base Rails and End Caps: Ideal for large part fixtures, with options for floor installation and protective end caps.

Assembly and Installation: Instructions for rail system assembly and installation, including leveling screws and hold-down bolts.

Spacer Angles and Connection Components: Used for modular upgrades and table extensions, available in various sizes.

Consoles and Corner Modules: Offer multiple clamping sides and allow for diagonal table extensions.

Clamping and Adapter Plates: Provide quick clamping capabilities and compatibility with various flange standards.

Segment Grid Plates and Base Bridges: Offer flexible clamping options for laser machines.

Specifications: Details on clamping and locating systems, including universal stops and adapter plates compatible with DIN and ANSI standards.

Procedures: Instructions for using clamping systems, emphasizing adjustability and minimal space requirements.

Norms and Standards: Compatibility with DIN and ANSI standards, with emphasis on precision scaling.

Recommendations: Suggests ordering components in pairs and using high-strength alloys for reduced weight.

Key Features: Includes universal stops, bilateral precision scaling, and hydro-mechanical locking mechanisms.

Critical Information: Highlights the importance of selecting appropriate systems for efficiency and safety.

Hydro-Mechanical Locking Mechanism: Features precision scaling and a maintenance-free locking mechanism.

Spacer Sets and Support Components: Allow for precise height adjustments with self-locking components.

V-Block Locations: Designed for precision intake of pipe elements with adjustable height.

PC Bolts: Provide high clamping force and self-centering capabilities.

Compensating Swing Clamps: Offer adjustment range for profiles that tend to tilt.

EcoLine and HobbyLine Welding Tables: Offer versatile and economical solutions with detailed specifications and accessories.

Welding Processes: Includes diagrams and descriptions of MIG/MAG and TIG welding processes.

Standards and Recommendations: References standards for tungsten electrodes and emphasizes safety guidelines.

Conclusion: Demmeler's systems are designed for flexibility, precision, and efficiency, suitable for a wide range of industrial applications.
