SERIESLOADTRAVELLENGTHACCURACYCAPACITY, LB. MINI RD30-900.5-2.01.06-3.060.0001 ″ / ″ RE-RS348-7790.5-12.01.06-15.000.0001 ″ / ″ (47 MODELS) > (LOW PROFILE & FLANGE BASE) SERIESLOADTRAVELLENGTHACCURACYCAPACITY, LB. HPM-HPS58-2250.5-10.01.00-15.000.000040 ″ / ″ (42 MODELS) > (LOW PROFILE & FLANGE BASE) SERIESLOADTRAVELLENGTHACCURACYCAPACITY, LB. HPRS2-HPRS590-4501.0-10.02.00-15.000.000040 ″ / ″ (34 MODELS) 4 >

LPT-1025-320550-8250.473-5.1180.984-8.0700.0001 ″ / ″ (21 MODELS) Stainless steel available. > SERIESLOAD TRAVELLENGTHACCURACYCAPACITY, LB. MINI NB144-1840.473-1.9690.788-3.1500.000080 ″ / ″ NB2-NB666-28160.709-11.6141.181-15.7480.000080 ″ / ″ to(49 MODELS)0.000200 ″ / ″ Stainless steel available. > (ALUMINUM) SERIESLOAD TRAVELLENGTHACCURACYCAPACITY, LB. SERIESLOAD TRAVELLENGTHACCURACYCAPACITY, LB. MINI NBT-1A96-1981.0-3.0 1.969-4.9210.0001 ″ / ″ NBT-2A-NBT-6A66-20320.71-91.378-14.170.0001 ″ / ″ (72 MODELS) Stainless steel available. > (STEEL) SERIESLOAD TRAVELLENGTHACCURACYCAPACITY, LB. MINI...

Load Ratings and Life Estimates ή > The rated load capacity of Del-Tron ball slidesmay be a mass load on a horizontal slide,or a force load normal to the mounting surface in any position. The rated load must be centered and distributed over the slide, andthe base must be fully supported on a flatmounting surface so that the ball slide does not act as a beam subject to concentrated or distributed bending forces. Loads supported by protruding arms reduce accuracy and load capacity by acting as levers or ratio arms, and should be avoided even when load forces are small.When used at the rated load...

In certain applications, uneven loads, improperpreload, vertical mounting, or offset forces may cause the ball retainers to become misaligned relative to each other. The misalignment (creepӔ) can ultimately cause a reduction in overall travel, the need for increased force to achieve full travel and even failure of the assembly.Del-Trons > Ү Anti-Creep >  retainer design preventsthese problems. The single piece retainer and integral positive end stops prevent ball retainer misalignment and help keep the rolling elements centered in the assembly. The retainer is molded of engineering plastic and...

″ /inch of travel, and repeatability,0.0001 ″ , exceeding our precision ball slides.Although crossed roller slides cost more thanequivalent size ball slides, their overallperformance, especially in applications where heavy loads must be moved in compact assemblies, often justifies selection. Del-Trons new series of crossed roller slides,offer designers additional flexibility in their choice of ready to install components for precision linear transfer.Our crossed roller slides, when compared toour ball slide products of equal size, offerhigher load carrying capacity and, when operating at high...

1. Corrosion resistant hardened 400 series stainless steel internal components2. Up to 5 > ΢3 wide cross section.3. Interchangeable with other manufacturer s products.4. Low friction straight line design. 5. Adjustable preload. 6. Straight line design with 0.000050 > Del-Trons Precision Series Ball and Roller Slidesoffer the designer an aluminum base and carriage with hardened stainless components for superior corrosion resistance and less chance of particulate contamination. Available in standard low profile mounting, the designer can choose a style of bearing and type of rolling element specifically...

Del-TronΒs High Precision Series Ball andCrossed Roller Slides offer the designer highly accurate travel characteristics. 0.000040 ″ . The base and carriage innersurfaces are ground to submicron toleranceswhile the mounting surfaces are flat to within 0.0001 ″ perinch of travel with superior repeatability of 0.000020 ″ per inch.The standard low profile style incorporates abase which is surrounded by the carriage leaving little surface to attract and hold contaminants. A flanged base style is offered to allow robust mounting at 4 points to assure stability in high impact or rough duty environments.These...

Compact Posi-Driveٙseries LS1 and LRS1stages have a height of only 1.250 inch and a width of only 1.380 inch. These stages provide the same outstanding 0.0001 inch straight line accuracy per inch of travel and 0.0001 inch repeatability as the larger LS3 series Posi-Driveline. The new smaller stages also offer a compact, flexibleconfiguration and are adaptable to standardNema configurations.The LS1 Posi-Driveٙstages offer a .168 inchdiameter .125 lead screw, an anti-backlash nut and a flexible zero backlash coupling that accepts a Nema 14 motor. They provide a load-carrying capacity of up to 40...

SpecificationsDrive: .168 diameter .125 lead screw with anti-backlash nut. Coupling: Flexible zero backlash coupling. Motor Mount: Accepts Nema 14 motor Travel: 1 ″ - 4 ″ Anti-Friction Slide: Linear ball or crossedroller slide. Load Capacity: Up to 40lbs. Configuration: 1, 2 or 3 axis. Accuracy: Straight line, up to 0.0001 ″ per inch oftravel. Repeatability: 0.0001 ″ Finish: Black Anodize. Other finishes on requestAlso available are special configurations, motormounts, hand crank actuation, and a variety of leads and diameters . > Lead screw pitch024=.024 X singleXY double XYZ triple Lead screw...

Designed for NEMA 14 motor frame, other motor adaptors available. Supplied with coupling for .1968 > ″ (5mm) motor shaft.Couplings with inch and metric bore available. Uses .168 > ″ diameter leadscrew with anti-backlash nut. Standard lead is .125 ″ .Leads available at no additional cost .024 > ″ , .050 > ″ , .096 > ″ , .188 > ″ , .250 > ″ , and .375 ″ .Standard travels of 1, 2, 3, and 4 ″ > ABD C1.380 1.000 .500 1.380 1.024.690 1.3801.024.690 1.250 .030.250 .866 Dia. Pilot for 14 Frame Motor.125 Dia. Thru - 4 plcs .197 Dia. Bore in Coupling.500 Dia. O.D. of Coupling H C'Bore for #6 Screw - 4...
