Delta ClubStar 8-FB4

Delta ClubStar 8-FB4

Delta ClubStar 8-FB4

Product catalog summary
Overview: The Delta ClubStar 8-FB4 is a compact and versatile laser projector designed for clubbing laser shows, as well as outdoor and indoor events. It features a robust design suitable for permanent installations, touring, or hire.
Specifications:
  • Optical Laser Power: 7500mW
  • Wavelengths: 638nm (Red), 530nm (Green), 445nm (Blue)
  • Beam Divergence: 1.0 mrad
  • Control Signals: Ethernet, ArtNet, DMX, ILDA, PC
  • Integrated Hardware: FB-4 Standart, FB-4 ILDA, FB-4 MAX
  • Scanning System: DT-50, 42-45 kpps @ 8° ILDA, EMS-9000 DIGI (optional)
  • Optical Scanning Angle: 85° Max
  • Cooling: Diode TEC, Silent Fans
  • Safety: Remote Control IN/OUT, KeyLock, Aperture Mask
  • Protection Class: IP44
  • Operating Temperature: 10°C to +40°C
  • Power Supply: 100-230VAC/50-60Hz
  • Weight: 13.5kg
  • Size: 336mm (W) x 320mm (D) x 170mm (H)
Features:
  • High-quality laser beam with low divergence for bright colors and balanced white
  • Robust housing with IP44 protection
  • Integrated FB-4 hardware for powerful performance
  • Easy installation and compact size
  • Overheating protection and Neutrik connectors
Applications:
  • Laser shows
  • Club shows
  • Outdoor and indoor events
  • Touring or hire
See more

Catalog excerpts

Delta ClubStar 8-FB4-1

Ethernet ArtNet DMX512 ILDA The perfect solution for clubbing laser shows, outdoor and indoor events. It has a small and compact size for easy installation. The precision optical system delivers a high-quality laser beam of low divergence, which guarantees bright colors and perfect white balance. The Delta ClubStar 8 laser projector guarantees 7,500mW optical output laser power. The optical components are fully isolated from dust. The housing and the internal design are robust, making ClubStar an ideal laser system for permanent installations, touring, or hire. The laser has a high-quality DT-50, 42-45 kpps @ 8° scanning system with 8mm mirrors, which is the best solution for this class of scanners. We also offer the ClubStar series with the precise and more powerful scanning systems Eye Magic EMS-9000 Digi. Beginners, as well as professionals, use our laser systems, as they are easy to operate, and offer many functions in a very compact size. The Delta ClubStar lasers are available in the range from 3W to 10W, with integrated FB-4 Standart or FB-4 Max. Guarantee laser power 7500mW Balanced White Color Integrated powerful hardware FB-4 Ethernet, ArtNet Overheating Protection Neutrik Connectors Compact size Delta Lasers Technology Ltd.  Club shows  Outdoor and outdoor events  Touring or h

 Open the catalog to page 1
Delta ClubStar 8-FB4-2

Technical specifications Optical laser power (mW) Laser source RGB power (mW) Beam divergence (mrad) Control signal Ethernet, ArtNet, DMX, ILDA, PC, Lighting Console or Autoplay Integrated hardware Scanning system Optical scanning angle Laser cooling Diode TEC, Silent Fans Temperature protection Safety function Remote control IN/OUT KeyLock, Aperture mask Laser class Protection class 1.5M power lead, Stainless steel mount Flight case Operating temperature Power connectors Power supply Delta Lasers Technology Ltd.

 Open the catalog to page 2
Delta ClubStar 8-FB4-3

Delta 8-FB4 Physical Size Delta Lasers Technology Ltd.

 Open the catalog to page 3
