Delta Electronics, Inc.
DC/DC Converter Catalogue 2009

DC/DC Converter Catalogue 2009

Product catalog summary

Overview
Delta Group, founded in 1971, is a leader in power systems technologies, with 2007 revenues over $4.8 billion USD. The company provides high-quality, cost-effective power supply solutions to Fortune 500 companies, maintaining strong customer partnerships and continuous quality improvements.

Financial Strength
Delta's financial stability and growth ensure its ability to handle market fluctuations and sustain future growth, providing a stable supply chain for customers.

Manufacturing
Delta operates large, automated manufacturing facilities in China and Thailand, with a production capacity of over 10 million power supplies per month, ensuring the ability to meet increasing demands while maintaining cost advantages.

Quality
Delta exceeds quality and reliability standards, with strict quality reviews and testing at each product design stage. Facilities are certified to ISO9001, ISO14001, TL9000, QS9000, and OHSAS18001 standards, earning numerous vendor awards.

Product Selection Guide
The document provides a guide for Delta's DC/DC converters, including isolated and non-isolated options, with specifications like input voltage range, output power, and efficiency. It includes various product series for industrial and telecommunication applications.

Key Features of DC/DC Converters
Delta's converters offer high efficiency, compact size, and industry-standard pinouts, with a wide input voltage range and output voltage trim, certified to multiple international standards.

Conclusion
Delta Group leads in power systems technology by providing innovative, reliable, and cost-effective solutions, supported by robust manufacturing capabilities and a strong commitment to quality.

Specifications

S36SA / S48SA Series: Up to 36 Watts, 2:1 input voltage range, high efficiency, low profile, 1500V isolation.
L36SA / L48DB Series: Up to 50 Watts, 4:1 input voltage range, bipolar dual output, 2250V isolation.
V36SE / V48SR Series: Up to 66 Watts, wide input voltage range, high power density.
E24SR / E48SC / E48SR Series: Up to 84 Watts, eighth brick form factor, high efficiency, 2250V isolation.
E36SR / E48SH Series: Up to 120 Watts, wide input voltage range, high output power.
Q36SA / Q48SP / Q48SH Series: Up to 400 Watts, quarter brick form factor, fixed frequency operation.
Q48DR / Q48DM Series: Dual output, up to 100W or 75W, two independent output channels.

Key Features

High efficiency, industry-standard form factors.
Fixed frequency operation, no minimum load required.
Protection features: UVLO, OVP, OCP, OTP.
Certified manufacturing facilities ensuring quality and reliability.

Mechanical Drawings
Includes detailed mechanical drawings for each series, illustrating dimensions and pin configurations.

Certifications
Products are manufactured in certified facilities (ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001) and are UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE marked.

Applications
Modules are suitable for high-frequency board-mounted DC/DC converters, providing efficient power solutions for telecommunications and IT infrastructure.

Catalog excerpts

Delta Group, founded in 1971, with 2007 group revenue over $4.8 billion US dollars, is a world leader in power systems technologies and manufacturing. For the past 15 years, we have been assisting Fortune 500 companies achieve their business objectives by providing state-of-the art, quality and cost efficient power supply solutions to meet their ever demanding applications.Our vision of supplying high quality, cost effective products has earned Delta the respect and trust of our worldwide customer base. Through strong partnerships with our customers, our on-going commitment to quality improvement,...

Open the catalog to page 2

Model Name Vin Vout Iout Eff@100%load S36SE3R305NRFB 18V~75V 3.3V 5A 86.5% S36SE05003NRFB 18V~75V 5.0V 3A 83.0% S36SE07002ERFF 18V~75V 7.0V 2.14A 84.0% S36SE12001NRFB 18V~75V 12V 1.3A 87.0% S36SE12002PRFZ 36V~75V 12V 2A 87.0% Model Name Vin Vout Iout Eff@100%load S48SP3R310NRFB 36V~75V 3.3V 10A 90.0% S48SP05007NRFB 36V~75V 5.0V 7A 90.0% S48SP12003NRFB 36V~75V 12V 3A 90.0% N On/Off logic N*=Negative, P=Positive, E=No remote on/off control pinR Pin Type / Length R*=0.170Ҕ, N=0.145, K=0.110Ԕ, M=SMDF RoHs code F=RoHs 6/6 (lead free)B Option code A=No trim pin, B*=With trim pin R=With trim pin & OCP140%...

Open the catalog to page 8

N On/Off logic N*=Negative, P=PositiveR Pin Type R*=SMD, T=Through Hole (S36SA has R type only)F RoHs code F=RoHs 6/6 (lead free)B Option code S36SA A*=Standard functions, B=6 pins, no sense S24SA A*=6 pins, no sense, B=8 pins, with sense S48SA A*=9 pins, no sense, B=6 pins, no sense, C=9 pins, with sense(12V has options B only) >

Open the catalog to page 10

TYP. +Vout-Vout (OPTION)+SENSE-SENSETRIM (OPTION) > 1.7 (0.07")29.5 (1.16")26.16 (1.030") +Vin-Vin N/C(OPTION) ON/OFF 12118125469 >

Open the catalog to page 11

N On/Off logic N*=Negative, P=PositiveR Pin Length R*=0.170F RoHs code F=RoHs 6/6 (lead free) B Option code A=Standard functions >

Open the catalog to page 12

? High efficiency? Size: 33.0mm x 22.9mm x 9.5mm (1.30ה x 0.90 x 0.37Ԕ)? Industry standard 1/16th brick form factor and pinout? SMD or through-hole pins? Fixed frequency operation? Wide input voltage range: 1"1"UP to Watts 18~75Vin for V36SE, 36~75Vin for V48SR ? Input UVLO, OVP? Output OTP, OCP, and OVP (default is auto-restart)? Output voltage trim -20%, +10% ? Monotonic startup into normal and pre-bias loads? No minimum load required? 2250V Isolation and basic Insulation? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility ? UL/cUL 60950-1 Recognized, TUV (EN60950-1)...

Open the catalog to page 14

Features > ? High efficiency? Size: 58.4mm x 22.8mm x 9.5mm (2.30 x 0.90Ԕ x 0.37) (E48SH)? Industry standard 1/8 brick form factor and pinout ? SMD or through-hole pins ? Fixed frequency operation ? Wide input voltage range: 18~75Vin for E36SR, 36~75Vin for E48SH ? Input UVLO, output OCP, OVP and OTP ? Monotonic startup into normal and pre-bias loads ? No minimum load required ? 2250V Isolation and basic Insulation ? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility? UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE mark he E36SR / E48SH product family...

Open the catalog to page 18

SOLDER-PLATED COPPER1.50(0.057) DIA WITH 2.5 (0.10")SHOULDERWITH 2.0 (0.08")SHOULDERCUSTOMER BOARD >

Open the catalog to page 19

Features > ? Industry standard form factor and footprint? Fixed frequency operation? Input UVLO, output OCP, OVP and OTP ? Monotonic startup into normal and pre-bias loads? No minimum load required? 2250V Isolation and basic Insulation ? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility? UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE mark heDelphi single board eighth and quarter brick product families provide 12V and 100W to 400W of output power in an industry standard footprint and pinout. Optional heat spreader versions are available. Model List...

Open the catalog to page 20

Features > ? Industry standard quarter brick footprint and pinout? Size: 57.9mm x 36.8mm x 8.5mm (2.28 x 1.45Ԕ x 0.33)? Fixed frequency operation ? Two power train and two independent output channels ? Input UVLO, output OCP, OVP and OTP ? No minimum load required ? Basic insulation ? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility? UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE mark he Delphi quarter brick Q48DR and Q48DM dual output product family provide up to 100W (Q48DR) or 75W (Q48DM) of power in an industry standard footprint and pinout....

Open the catalog to page 22

Features > ? Industry standard quarter brick footprint and pinout? Size: 57.9mm x 36.8mm x 8.5mm (2.28 x 1.45Ԕ x 0.33)? Fixed frequency operation? Flexible output current allocation on each output? Low voltage output (O/P1) starts up fi rst (Q48DE)? Bipolar (positive and negative) dual output (Q48DC)? Input UVLO, output OCP, OVP and OTP? Basic insulation? No minimum load required ? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility? UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE mark he Delphi Q48DE quarter brick dual output product family provides...

Open the catalog to page 24

? High efficiency? Industry standard footprint and pinout ? 2:1 input voltage range? Fixed frequency operation ? Metal baseplate? Input UVLO, output OCP, OVP and OTP? No minimum load required? 2250V isolation and basic insulation? Auxiliary basic power (F48SA) ? Paralleling (current sharing) (F48SA)? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility? UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE mark > heDelphi H24SN / H48SN / F24SA / F48SA series provides up to 700 watts of power in full brick and up to 350 watts an half brick size power modules...

Open the catalog to page 26

N On/Off logic N*=Negative, P=PositiveR Pin Length R=0.170F RoHs code F=RoHs 6/6 (lead free)A Option code A*=Standard functions >

Open the catalog to page 28

Features > ? High efficiency? Small size and low profile ? Industry standard footprint and pinout ? Pre-bias startup? Output voltage tracking (Except DNT)? No minimum load required ? Voltage and resistor-based trim ? Output voltage programmable from 0.75V to 3.3V and from 0.75V to 5V via external resistors? Input UVLO, output OCP, OVP and OTP? Remote ON/OFF ? Remote sense (DNM, DNL & DNK series)? ISO 9001, TL9000, ISO 14001, QS9000, OHSAS 18001 certified manufacturing facility? UL/cUL 60950-1 Recognized, TUV (EN60950-1) certified, and CE mark he DNT, DNS, DNM and DNL families of non-isolated...

Open the catalog to page 32
