Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:4.50pt "Arial", sans-serif; } .font2 { font:5.00pt "Arial", sans-serif; } .font3 { font:5.60pt "Arial", sans-serif; } .font4 { font:6.00pt "Arial", sans-serif; } .font5 { font:6.40pt "Arial", sans-serif; } .font6 { font:7.00pt "Arial", sans-serif; } .font7 { font:8.00pt "Arial", sans-serif; } .font8 { font:9.00pt "Arial", sans-serif; } .font9 { font:11.00pt "Arial", sans-serif; } .font10 { font:12.00pt "Arial", sans-serif; } .font11 { font:16.00pt "Arial", sans-serif; } .font12 { font:19.00pt "Arial", sans-serif; } .font13 { font:7.00pt "Arial Black", sans-serif; } .font14 { font:12.00pt "Arial Black", sans-serif; } .font15 { font:23.00pt "Franklin Gothic Medium", sans-serif; } MODELE MODEL OPTIONS / OPTIONS FEATURES P H RE RI T K SD C V M REP 62 Օ p REP 82 REP 112 m tu u z E EXEMPLE DE COMMANDE HOW TO ORDER MODELE DE BASE RESSORTS 4- BOITIER DE DETECTION 4 COURSE ALLONGEE tu u z tu ce ■tu IL -111 ce ALIMENTATION TIGE DE DETECTION SUPPORT DETECTEURS TANDEM > exemple : REP62 P RE C M REP 2 mors parallles 2 jaws parallel ARACTERISTIQUES TECHNIQUES / TECHNICALS FEATURES MODELE MODEL COURSE TOTALE (mm) FULL STROKE (mm) F6+R (N) F0+R (N) 0 x h (mm) 0 x h (mm) MASSE (kg) WEIGHT (kg) REP 62 10 694 176 0 60 x 64 0,550 REP 62 C 16 432 109 0 60 x 68 0,550 REP 82 13 1946 635 0 80 x 65 0,900 REP 82 C 20 1256 410 0 80 x 70 0,900 REP 112 20 3043 965 0 110 x 87 2,200 REP 112 C 30 2030 644 0 110 x 92 2,200 Pinces de puissance pour applications s蕩vres. Nombreuses options (d蕩tection, scurit, 驩nergie, ...). Mթcanisme fiable et protg. OPTIONS & ACCESSOIRES / OPTIONS & ACCESSORIES 驕 Powerful grippers designed for harsh environments. Multipurpose gripper (sensing, safety and power options, Օ Reliable and shielded mechanism. MODELE MODEL OPTIONS / OPTIONS FEATURES ACCESSOIRES ACCESSORIES Page P H RE RI T K SD C V M D SD REP 62 Nous consulter Contact us A A C3 REP 82 A A C5 REP 112 Օ A A C7 PRECISIOI 2 mors parallles 2 jaws parallel ARACTERISTIQUES TECHNIQUES / TECHNICALS FEATURES MODELE MODEL COURSE TOTALE (mm) FULL STROKE (mm) F6+R (N) F0+R (N) 0 x h (mm) 0 x h (mm) MASSE (kg) WEIGHT (kg) 60 02 P 10 694 176 0 60 x 68 0,510 60 02 P C 16 432 109 0 60 x 68 0,510 80 02 P 13 1946 635 0 80 x 69 0,840 80 02 P C 20 1256 410 0 80 x 69 0,840 110 02 P 20 3043 965 0 110 x 94 2,040 110 02 P C 30 2030 644 0 110 x 94 2,040 140 02 P 26 6232 2305 0140x123 4,200 140 02 P C 40 4031 1490 0140x 123 4,200 165 02 P 30 11475 3825 0165x154 8,740 165 02 P C 50 6878 2292 0165x154 8,740 Pinces de puissance pour applications s蕩vres. Nombreuses options (d蕩tection, scurit, 驩nergie, protection...). Grandes p rթcision et rptabilit驩. OPTIONS & ACCESSOIRES / OPTIONS & ACCESSORIES Powerful grippers designed for harsh environments Multipurpose gripper (sensing, safety, power andbootoptions,...) High accuracy and repeatability MODELE MODEL OPTIONS / OPTIONS FEATURES ACCESSOIRES ACCESSORIES Page P H RE RI T K SD C E V M SD E 60 02 P Nous consulter Contact us Օ A A C15 80 02 P Օ A A C17 110 02 P Օ A A C19 140 02 P Օ A A C21 165 02 P Օ A A C23 Fonction intgre au mod驨le de base Feature integral with basic model Option tenue en stock, monte en usine ( pr頩ciser la commande) Optional feature in stock, factory fitted (specify with order) A Accessoires en kit monts par le client (੠ commander sparment) Accessories in kit form for fitting by the client (to be ordered separately) X Fonction impossible Incompatible feature Optionsetaccessoires驕Optionalfeaturesandaccessories P - Alimentation pneumatique / Pneumatic operation. H - Alimentation Hydraulique / Hydraulic operation. RE - Scurit par ressorts pour serrage sur arbre Safety springs for arbor clamping. RI - S驩curit par ressorts pour serrage dans alsage Safety springs for bore clamping. T - Tige de d驩tection / Sensor probe. K - Botier de dtection / Integral transmitter. SD - Support de dtecteurs inductifs / Inductive sensor holders. C - Course allonge / Extended stroke. E - Enveloppe de protection / Sealing cover. V - Joint viton / Viton seal. M - Tandem / Tandem. D - Dtecteurs magn驩tiques / Magnetic sensors. Incompatibilits /Incompatible pairs : P avec / with H - RE avec / with RI - E avec / with SD - M avec / with H - T avec / with K - SD avec / with D B1
