WIRE & CABLE EXTRUSION SYSTEMS

WIRE & CABLE EXTRUSION SYSTEMS
8Pages

Catalog excerpts

The combined technologies of Davis-Standard and Merritt Davis Electric have created a powerful force in the wire and cable marketplace. We manufacture complete wire and cable systems for building and communication wire, construction wire, coaxial cable, automotive wire, high temperature wire, and specialty wire applications. Systems are available with a wide range of extruders, payoffs and tension brakes, take-ups, and auxiliary equipment including cooling troughs, capstans, caterpillars, and accumulator systems. Laboratory equipment, customized feedscrews, and control systems are also...

Open the catalog to page 2

Power Cable Systems RADIANT HEAT GAS CURE SYSTEM This system provides a fast and economical dry cure for thermoset insulations, particularly XLPE. By utilizing nitrogen as the curing media, the presence of moisture is eliminated during the critical curing process. A patented by-product removal system that removes contaminates and increases the efficiency of the radiant curing system by circulating the nitrogen continuously is optionally available. Cure system components are manufactured to quality specifications for pressure vessels and fabricated stainless steel. Օ Complete system...

Open the catalog to page 3

Specialty Wire Systems BUILDING WIRE High output lines are engineered for insulating single cores and jacketing multi-conductor insulated constructions. These lines provide continuous operation with packaging of the product in coils, on reels, or on stem packs. Building wire lines can extrude PVC from powder or pellets, and can co-extrude multi-layer constructions such as nylon over PVC. They use fixed or adjustable center crossheads. A continuous supply of either solid or stranded conductor may be fed into the line. AUTOMOTIVE WIRE Davis-Standard lines are used for primary automotive wire...

Open the catalog to page 4

Extruders, Feedscrews, and Controls EXTRUDERS Davis-Standard is recognized worldwide for quality extruders. Single screw extruders are available in sizes from 3/4-inch to 15-inch (19mm to 380mm) diameters with L/D ratios from 10:1 to 42:1. This includes grooved feed throats, vented barrel, tiltable, and tandem specialty single screw machines. Vertical extruders are available in 3/4-inch to 3-inch (19mm to 76mm) diameters. Davis-Standard also offers twin screw conical and parallel extruders for RPVC processing and compounding applications. FEEDSCREWS Our DSB®, DSBM, and DSBM-Tٙ feedscrews...

Open the catalog to page 5

Wire Handling Equipment CAPSTANS We custom engineer multi-pass, linear, and belt wrap type capstans for the full range of wire and cable applications. Capstans include single wheel belt wrap type from 24 to 84 inches (610 to 2134mm) in diameter. Linear CatTrak capstans with gripping lengths to 80 inches (2032mm) are available with 2,500 pounds (1134 kg) of traction force. Dual wheel multi-pass wet capstans are available from 12 to 32 inches (305 to 812mm) in diameter with lengths up to 60 feet (18 meters) for increased cooling capacity in both flood and spray configurations. Over/under...

Open the catalog to page 6

24/7 Customer Service/Aftermarket Services We have service technicians available 24 hours a day, seven days a week, to handle parts inquiries and emergency service needs. Parts shipments, if in stock, can be shipped within one day. We maintain complte mechanical and spare parts inventories ranging from feedscrews and barrels to thermocouples and motors. On-site service by a technician is also available. For parts and service call +800-480-8105. Inventoried electrical and mechanical spare parts. Get to Know Us RT-24 Dual Take-up Davis-Standard has set the standard in wire and cable equipment...

Open the catalog to page 7

Davis-Standard Business Areas Aftermarket Services Blow Molding Systems Blown Film Systems Cast Film Systems Compounding Systems Elastomer Systems Extrusion Coating and Laminating Systems Fiber Systems Foam Systems Laboratory Equipment and Specialty Systems Liquid Coating and Laminating Systems Pelletizing Systems Pipe, Profile and Tubing Systems Process Control Systems Recycle/Reclaim Systems Sheet Systems Twin Screw Systems Unwinding and Winding Systems Wire and Cable Systems 46 North First Street Fulton, NY 13069-1297 USA Tel: +315-598-7121 Fax: +315-593-0396 www.bc-egan.com Room 1007,...
