Davis-Standard - Sheet extrusion systems

Davis-Standard - Sheet extrusion systems
12Pages

Catalog excerpts

SHEET EXTRUSION SYSTEMS >

Davis-Standards sheet systems are recognized around the world for reliability, accuracy, high outputs, and processing efficiency. Our process knowledge and experience is unsurpassed. We manufacture equipment for foam, flexible and rigid sheet extrusion, and single and multi-layer coextrusion applications utilizing the latest feed block technologies available. Processing capabilities include common packaging resins such as APET, CPET, PETG, high-density PE, PS, PP, PA, and any other extrudable thermoplastic materials. We supply integrated systems and solutions incorporating single screw or...

Open the catalog to page 2

Davis-Standard - Sheet extrusion systems - 3

Our customers produce a broad range of products for many different markets. Examples include: Packaging Cups, plates, tubs, domes, frozen food, blister/point of purchase, extrusion for roll feed thermoforming applications, high output capacity extrusion for end user inline thermoforming Automotive Fender liners, splash guards, truck bed liners, interior sound absorption Dunnage Slip sheets, thermoformed pallets, waste containers Building Wall partitions, interior/exterior lighting, drainage, pail liners Medical Saline solution bags, instrument packaging Custom Circuit breakers,...

Open the catalog to page 3

Davis-Standard - Sheet extrusion systems - 4

For over 50 years, the Davis-Standard name has been synonymous with quality extruders and feedscrews. We view the extruder and feedscrew as the foundation of your sheet system. Our Thermatic > extruders are built for high outputs, efficiency and years of trouble-free operation. The advanced technology and track record of our feedscrews is unsurpassed. Our goal is to provide you with the best extruder and feedscrew combination for your process(es). > 6-inch (150mm) 30:1 Thermatic ή extruder Ε All Thermatic models are built with rugged HӔ beam steel construction to provide maximum stability...

Open the catalog to page 4

Davis-Standard - Sheet extrusion systems - 5

Sheet extrusion often calls for complex systems capable of handling a range of processing requirements and resins. This is where controls, dies, and coextrusion technology can lead to improved processes, greater efficiency, and processing versatility. We are well equipped in these areas to help you fine-tune your system. > Windows > ծ -based plant management and extension process control capabilities with adaptable and expandable touch screen displays. Supervisory features including event logging, customized reports, SQC, historical trending, maintenance/troubleshooting, pressure set-up and...

Open the catalog to page 5

Davis-Standard - Sheet extrusion systems - 6

Our XP Express > and EX-M-PLAR > ή series roll stands are engineered to simplify and improve sheet processes across the board. These models are available in standard or customized versions in upstack, downstack, vertical, horizontal, offset top roll or offset bottom roll J configurations. Roll stands can include three or more cooling rolls, as well as automatic drive controls and hands-free nip gap adjustment. > Standard features include: ֕Individual roll drive for precise web tension control and optimized sheet polish Web cooling train sized for application with matched roll diameter and...

Open the catalog to page 6

Davis-Standard - Sheet extrusion systems - 7

XP EXPRESS > CS MODEL Ζ CUSTOM SHEET APPLICATIONS > Same standard features as the PS model except the CS model utilizes an individual roll gear drive train system to facilitate quick embossing roll removal without disturbing the AC drive train mechanics and electronics.ՕBoth models are competitively priced and pre-engineered for a fast delivery. Capabilities include production of polished or embossed roll stock and cut-to-length sheet or inline extrusion to thermoforming applications. Each unit is supplemented with optional ancillaries such as laminating unwinds, solution applicators,...

Open the catalog to page 7

Davis-Standard - Sheet extrusion systems - 8

Intergrated Ancilliary Equipment Details are important to us and our customers. From the design of our roll stand rolls, to cooling and polishing units, to auxiliary equipment, we want to ensure that every square inch of your system is ready to meet or exceed your expectations. > Available with pneumatic or hydraulic roll actuation. Օ Automatic roll force control system minimizes roll deflection allowing processors to polish thinner gauge sheets than previously possible. A manually actuated worm-wheel, jack-screw device at the nip outlet provides consistent roll gap position. Օ Rolls are...

Open the catalog to page 8

Davis-Standard - Sheet extrusion systems - 9

A standard high-pressure design utilizes shrunk fit outer shells to improve strength and minimize deflection.ՕOptional rolls are available for embossing and other high-quality surface requirements.AC roll drive system corrects speed differentials and eliminates need for four-speed transmission. > Օ Features a modular design with side supports consisting of blanchard-ground side plates that are drilled and bored in pairs to align roll mounting and support girts for improved web guiding. Precise roll stand height adjustment by means of cross-shafted jacks to precisely position the melt...

Open the catalog to page 9

Davis-Standard - Sheet extrusion systems - 10

We are always working to expand our processing technology to accommodate the changing needs of the marketplace and the world. A significant example of is the demand for PET processing technology, reflecting environmental concerns and the importance of recycling. Our PET capabilities include technology to process multiple materials such as recyclable PET in flake form, and low bulk density PET ranging from 100 percent post consumer waste to virgin APET. This includes sheet structures for running monolayer, coextrusion and side-by-side sheet. Our customers have experienced ongoing business...

Open the catalog to page 10

Davis-Standard - Sheet extrusion systems - 11

There is a reason why our equipment is recognized as being among the best in the world our service and expertise is focused on supporting our customers֒ investment. > We have fully staffed Technology Centers in the United States and Europe, making our screw design and technical capabilities among the best in the world. Production scale and laboratory equipment is available to analyze various processes. A team of experienced and knowledgeable process engineers and screw design specialists collaborate with customers to evaluate process parameters and implement feedscrew technology best suited...

Open the catalog to page 11
