DANOBATGROUP
HIGH PRODUCTION GRINDING SOLUTIONS

HIGH PRODUCTION GRINDING SOLUTIONS

Product catalog summary

Overview: The document introduces the CG range of high-performance external grinding machines designed for complex and demanding manufacturing challenges. These machines prioritize productivity, precision, and quality, ensuring long-lasting solutions under continuous 24/7 operation.

Key Features:

Near 100% machine availability and lowest cost per part.
Short changeover time and reduced footprint.
Eco-friendly design with increased productivity and automated solutions.
Capable of operating at speeds of 80 m/s with conventional abrasives.

Technological Innovations:

Optidress technology for efficient dressing processes.
Workhead with built-in motor for enhanced performance.
Customizable wheelhead and a wide range of tailstock options (80 – 600 mm strokes).

Core Technology:

Critical components are manufactured in-house to ensure reliability.
An exchange program is available to minimize downtime.
Integrated loading options to enhance productivity.
Cross-slide architecture and B-axis grinding spindle revolver to reduce machine footprint.

Technical Specifications:

Models: CG-600 and CG-1000.
Max. distance between centers: 600 mm/1000 mm.
Max. diameter to be ground: 440 mm.
Max. weight between centers: 500 kg.
Max. grinding wheel size: Ø 610 mm x 160 mm.
Max. wheel peripheral speed: 80 m/s.

Contact Information: Danobat, Arriaga kalea 21, E-20870, Elgoibar, Gipuzkoa, Spain. Phone: +34 943 748 044. Website: www.danobatgrinding.com

Catalog excerpts

Your grinding solution is ready! CG High performance grinding machine with short delivery time. GO FAST! 80 m/s with conventional abrasive. HIGH PRODUCTION EXTERNAL GRINDING SOLUTION The CG range of external grinding machine is the answer to your most complex and demanding challenges. A family of solutions designed for maximum productivity, without compromising precision or quality. CG machines guarantee long-life grinding solutions under the most demanding 24/7 manufacturing conditions. Near 100% availability Lowest cost per part Short changeover time Reduced footprint ECO machine Increased productivity Automated solutions 24/7 machine

Open the catalog to page 1

HIGH-PRODUCTION GRINDING MACHINE. BEST PART/COST RATIO CORE TECHNOLOGY • 80 m/s with conventional abrasive. A winning combination: speed and an in-depth understanding of grinding. Optidress: the new way of dressing. Ask for details. Workhead with built-in motor. Much more than a workhead. Wide range of tailstock with 80 – 600 mm strokes. Customisable wheelhead. Cross-slide architecture to reduce footprint AUTOMATED SOLUTIONS We work to ensure that our grinding machines provide near 100% availability. • Critical components built in-house • Exchange program To ensure shorter production times and...

Open the catalog to page 2
