VLT® Micro Drive

VLT® Micro Drive
1 / 8Pages

Catalog excerpts

Well protected IP 20 enclosure No forced air ow through electronics Hot pluggable LCP High quality capacitors RFI Filter RS 485 pluggable LCD display Customer relayscrew terminals Wire inlet from the bottom DC-link access I/O terminals Mains screw terminals IP 20 even without terminal coverPotentiometer Safety earth min. 4 mm > 2 accessible from front Motor screw terminals > RoHS compliant The VLT֮ Micro Drive does not contain lead, cadmium, hexavalent chrome, mercury, or ame retardant PBB and PBDE. >

Open the catalog to page 2

Ε Plug-and-play Minimum e ort ֖ minimum time Minimum commissioningՖ Save time > Copy settings via local control panelՖ Easy set up of multiple drives > Intuitive parameter structureՖ Minimal manual reading > Complies with VLTծ software Save commissioning time > Optimum heat dissipationՖ Longer lifetime High quality electronics/capasitorsՖ Low lifetime cost > Ε All drives full load tested from factory High reliability ֕ Earth fault, temperature and short circuit protection Lean operation ֕ Circuit boards well protected and coated Increased robustness > Ε Process PI-controller No need for...

Open the catalog to page 3

Built-in brake functions With built in DC and AC brake func- tions, VLT Micro Drive can transform kinetic energy in the application into braking power to slow down the motor. A brake chopper is built-in the drives from 1.5 kW upwards. > Real space saving side-by-side A compact book style design allows real side by side mounting without derating. Minimum penetration of dust Built-in RFI VLTή Micro Drive is designed to keep the forced ventilation away from the electronics. Printed circuit boards are well protected inside the drive. Radio disturbance from motor cables is limited with the...

Open the catalog to page 4

For EMC optimized installation. The VLT Motion Control Tool MCT 10 Setup Software exploits the full functionality of your PC, providing a general overview and control of even large systems. A dedicated mounting kit is available for mounting the local control panel (LCP) in the cabinet door. Dedicated external lters are available on request. > 6 size="-1">

Open the catalog to page 6

Local backup globally VLT֮ motor controllers are operating in applications all over the world and Danfoss Drives experts located in more than 100 countries are ready to support our customers with applica- tion advice and service wherever they may be.Danfoss Drives experts donҒt stop until the customers drive challenges are solved. Rely on the experts We take responsibility for every element in our products. The fact that we develop and produce our own features, hardware, software, power modules, printed circuit boards, and accessories is your guarantee for reliable products. > Danfoss...
