Carbide circular sawing machine - RCA100

Product catalog summary

Overview: The document provides technical specifications and features of the RCA series circular sawing machines, specifically models RCA70 and RCA100, designed for high-speed and high-precision cutting of carbon steel bars.

Specifications:

Cutting Capacity: RCA70 can handle round bars from 5/8” to 2 3/4”, while RCA100 can handle from 3/4” to 4”.
Motor Output: Not specified in the document.
Saw Blade Size: RCA70 uses a 285×40×2 mm blade, and RCA100 uses a 360×40×2.5 mm blade.
Blade Peripheral Speed: RCA70 ranges from 102 to 518 sfpm, and RCA100 ranges from 131 to 666 sfpm.
Indexible Length: Single stroke ranges from 0.24 to 23.6 inches, and multiple strokes range from 23.6 to 393.6 inches.
Machine Weight: RCA70 weighs 4,370 lbs, and RCA100 weighs 6,350 lbs.

Features:

High-Speed Cutting: Capable of cutting a 2” diameter piece of 1045 steel in only 5 seconds, which is four times faster than conventional blades.
Ease of Operation: Equipped with a touch-type screen for easy operation and I/O diagnostics for troubleshooting.
Adjustable Blade Speed: The inverter allows for easy adjustment of blade speed during cuts.
Automatic Sorting: Initial trim cuts and remnants are automatically separated from production material.
Chip Removal: A steel belt conveyor efficiently removes chips and supports a 55-gallon drum.
Large Magazine Capacity: Can hold various diameters and lengths up to 19 feet.
Vibration-Free Cuts: The blade is mounted to a rigid saw head and supported by guide pads, with a vertical vise working in conjunction with the main vise for smoother cuts and longer blade life.

Additional Information: The document includes contact information for Daito USA, the manufacturer, and highlights the inclusion of a magazine and chip conveyor with the machines.
