Product catalog summary
Company Overview: Dagu S.r.l., located in Vicenza, Italy, specializes in manufacturing standard and custom electric motors. The company holds ISO 9001 and ISO 14001 certifications, highlighting its commitment to quality and environmental management.
Product Offerings: Dagu produces DC and AC motors with power outputs ranging from 30 to 2000 W. These motors are available for both intermittent and continuous duty, with options for waterproof and open designs. Additional features such as EMI suppression filters, sensors, electromagnetic brakes, reduction gears, and electronic controls can be added upon request.
Technical Capabilities: Dagu excels in creating custom motors tailored to client needs, supported by a research department and a test lab for lifetime and mechanical stress testing. They offer product certifications like UL and CSA upon request.
Power Supply Considerations: The document stresses the importance of the power supply unit's form factor, as a higher form factor can cause overheating and shorten motor lifespan. Specifying the power supply type is crucial when purchasing a motor.
Duty Types: Various duty types (S1 to S9) are outlined according to EN 60034-1, including continuous running duty (S1), short-time duty (S2), and intermittent periodic duty (S3), each with distinct operational characteristics.
Motor Selection: Choosing between permanent magnet DC motors and asynchronous AC motors depends on factors such as required speed, power supply type, torque needs, and speed variation requirements.
Design and Protection: New motor designs are documented with datasheets detailing torque, speed, current, power, efficiency, and protection levels. Protection degrees (IP) are specified, indicating protection against solid objects and water ingress.
Motor Series and Characteristics: Detailed specifications for various motor series (ME 45, ME 56, ME 63, etc.) are provided, including dimensions, characteristics, and protection levels. Motors are available in both ventilated and non-ventilated versions, with protection levels up to IP68.
See more
Catalog excerpts
DIMENSIONS febdfebdll febdl febdl Type.Form 56B14 (fig.1) Form 56B5(fig.2) k l d b e f k l d b ef > 56 2377.81282095065801282098010012056 4077.815020950658015020980100120 56 75831902095065801902098010012056 105832202095065802202098010012056 1308324520950658024520980100120 kk k k TypeForm 63B14 (fig.3) Form 63B5 (fig.4) k l d b e f k l d b ef > 踸 56 2377.8130231160759013023119511514056 4077.81502311607590150231195115140 56 7583190231160759019023119511514056 105832202311607590220231195115140 56 130832452311607590245231195115140 踸 TypeForm 63B14 (fig.1) Form 63B5 (fig.2) k l d b e f k l d b ef (fig.1)...
