General purpose Load display resolution: 0.1N High performance Load display resolution: 0.01N \ High performance, low capacity model Load display resolution: 0.001N (When using 50N load cell) No hassle start up Automatic calibration on start up means no waiting around. (Load cell calibration unnecessary) High precision load cell included Use jigs from companies other than A&D as well. * When using the M6 male screw adapter MSAT-Lite [Data processing software] Displays operation and processing results. Performs data analysis and graphing. Or enter curve data in CSV format.

Cycle test settings Counts of Cycles 3 [cts] Cycle Limit 100.0 [mm] Load cell selection screen (MCT-2150W only) 1. Turn the power switch off. 3. Turn the power switch on.

Optional jigs Screw action jaws Maximum load 500N Price for one piece.An upper and lower jaw are necessary for tensile strength tests. (Not sold as a bottom/top pair) Face dimensions 19 (w) x 19 (h) mm, opening width 10 mm. The face side is knurled. Load sensitive plates for STA/STB For lkN/500N/50N 060 mm Maximum load 500N Price for one piece.An upper and lower jaw are necessary for compression tests. Maximum load 500N Lower fulcrum R2 Upper fulcrum R5. Bottom span between 10 and 110 mm. Maximum load 500 N Lower fulcrum R5 Upper fulcrum R5. Bottom span between 10 and 110 mm. Attachment set (Items...

*1 When using standard screw action jaws *2 Unladen *3 For MCT-2150, a 50N capacity load cell is also included. A&D Company, Ltd. A Attention to • For proper use, read the instruction Safety! manuals cafully before use •Appearance and/or specifications subject to change for improvement without notice. •Contents of this catalog last updated March 2022.
