OCTOPUS 100 CNC tool grinding machine
10Pages

Octopus100 7-axes cnc tool & cutter grinder Octopus 100 offers the flexibility and ergonomic features required for the grinding process of cutting tools. Suitable for regrinding or production of small and medium size cutting tools such end mills with square end, corner chamfer, corner radius and ball nose straight flutes, drills, special drill points, step drills and single-point cutting tools. It has been designed to save space, easy use and quick maintenance.

Efficiency, dynamism, technique, high-tech Efficiency, dynamism, technique, high-tech The kinematics of Octopus 100 is composed of 4 linear and 3 rotary axes assembled in two clearly defined areas of the machine base. Linear axes X, Y, Z and rotary axis B are assembled on a solid cast iron tower on the back of the machine base, while workhead unit A is assembled on rotary axis W, which contains linear positioning axis U. Linear axis U has been designed to make ball nose or corner radius grinding: U axis positions the center of the tool radius in the center of rotation of W axis.

THE DOUBLE END SPINDLE ASSEMBLED ON Z AXIS SWINGS 255° RH AND LH HAND TO □ LS CAN BE MADE □ R RE"SHARPENED WITH □ UT VARIOUS PACKS OF GRINDING WHEELS CAN BE VERY QUICKLY ASSEMBLED □ N THE TWD COUPLING CONES, IT MAKES A VERY FAST SWITCH FROM ONE TYPE OF TOOL TO THE OTHER ONE.

To be as interchangeable as possible, the workhead is equipped with an ISO 40 taper and clamping collar, which can set various types of toolholder, such as manual or automatic hydraulic spindles, clamp holders, chucks with 6 jaws, both types DIN 69871 and BT40 type.

OCTOPUS100 Octopus 100 is equipped with a 3D electronic touch probe with probing tip made according to protection pin. The probing software includes axial and radial tool positioning and lead calculation.

The positionable console contains a modern and efficient SIEMENS SINUMERIK 840Di numeric control that integrates our OCTOSOFT programming software. OCTOSOFT allows the most different geometric tool sharpening or construction shapes to be obtained. Our team of programmers has developed simple, fast and intuitive software for the operators, who do not need any particular experience in programming CNCs. OCTOPUS 100 comes with two software packages as part of the standard supply: OCTOSOFT MILLS for making and sharpening straight end mills with square end, corner chamfer, corner radius and ball...

coolant oil filtration system OCTOPUS 100 is ready to be connected to a central coolant system or to a dedicated filtration system for the machine. The cartridge filtering system includes a 300 liter tank, pump to re-circulate the oil and the high pressure delivery pump. The high pressure pump provides a 60 l/min flow rate at a pressure of 6/8 bar. The filtering system only functions with pure coolant oil and guarantees a 100 l/min filtering capacity at 5 microns.

TECHNICAL SPECIFICATIONS Workhead A axis Tool clamping option Manual, pneumatic or hydraulic Double ended wheel spindle Wheel diameter Wheel bore Number of wheels per side Spindle power Wheel spindle range, variable speed OCTOPUS100 CNC control unit Control Siemens digital servomotors Measuring system Digital encoders Dimensions and Weights Dimensions Total weight Power input Total power input Power supply voltage Electronic touch probe 3 D touch probe

AXES TRAVEL Linear axes travel X Axis, wheel head longitudinal stroke Z Axis, wheel head vertical stroke Y Axis, wheel head cross stroke U Axis, workhead longitudinal stroke V Axis, workhead cross stroke Rotary Axes B Axis, wheel spindle swivel A Axis, tool rotation W Axis, rotary table Axes resolution Linear axes resolution Rotary axes resolution Linear axes maximum feedrate Maximum speed of rotary axes
