High precision sharpening machines
8Pages

High prcision sharpening machines for twist drills and taps

Sharpening machine for twist drills MICRA 10 - MICRA10 intgral Cuoghi MICRA 10 and MICRA 10 INTEGRAL sharpening machines are specifically designed and built for sharpening systems of the self-centering type. They are able to eliminate intermediate centering operations and ensure an adequate level of accuracy, both for HSS and carbide drills. The quality and accuracy of the MICRA 10 and MICRA 10 INTEGRAL sharpening systems are achieved thanks to highly advanced constructional technologies and by a more modern design, able to comply with the most modern ergonomic and functional dictates. With...

Sharpening machine Mod. MICRA 10 Sharpening machine Mod. MICRA 10 Integral Technical spcifications: Sharpening diameter Right and left cutting edges Web thinning Drill angle Cutting angle adjustment Spindle motor power Motor rotation Grinding wheel spindle speed Approximate weight Machine dimensions from 0.5 to 20 mm 2-3 negative 80°-180° 0°-18° 0.18 kW clockwise and anticlockwise 7100 rpm 40 kg 570 x 500 x 520 mm Technical specifications: Sharpening diameter Right and left cutting edges Web thinning Drill angle Cutting angle adjustment Spindle motor power Motor rotation Grinding wheel...

Sharpening machines for twist drills and taps APE 25 APE 40 APE 40 AUTOMATIC APE 60 Using simple machine fixtures, Cuoghi sharpening machines sharpen twist drills with 40° to 180° tip angles, multi step drills, pilot bits, diamond drills,prismatic and self-centering drills, flat bits, center drills, countersinks, expanders and taps with 1 to 12 right and left cutting edges, as illustrated in a few examples. Thanks to perfect tool sharpening, Cuoghi sharpening machines speed up drilling processes, increasing drill performance as well as achieving a more rational use of the drills and using...

Sharpening machine mod.APE 25 Technical spcifications: Sharpening diameter from 1.5 to 25 mm Right and left cutting edges from 1 to 12 Drill angle 40°-180° Horizontal wheel center electric spindle power 0.38 kW Vertical wheel center electric spindle power 0.18 kW Approximate weight 105 kg Machine dimensions 740 x 680 x 1170 mm Supplied Accessories: Base, vertical electric spindle, halogen lamp, chuck, set of 4 cams for right hand tools with 1-2-3-4-6 cutting edges, grinding wheels. Optional equipment: diamond and CBN grinding wheels, water-cooling system . Sharpening machine mod.APE 40...

Automatic sharpening machine for twist drills APE 60 A - APE 80 A Cuoghi mod. APE 60 A and APE 80 A automatic sharpening machines sharpen right and left twist drills of the spiral type, the characteristic of which is to notably reduce penetration stress during drilling operations. Cuoghi automatic sharpening machines guarantee symmetrical cutting edges with point and rake angles that can vary to suit the material and feed range available, as outlined in an indicative table. The amount of material to be removed from the drills is preselected on the control panel. The end of the machining...

bhh ■■■ mam ai a m mam mam CUOGHI AFFILATRICI s.r.l. Via S. Allendel 117-119 41100 Modena - Italia Tel. +39 059 251206 - Fax +39 059 252791 E-mail: cuoghi-srl@cuoghi.it www.cuoghi.it
