Power Transmission Solutions Cross+Morse, operating from a 5000m Our range of products is extensive and includes:-Roller Chain from 6mm to 2 > 1 / > 2 " . Single and multistrand British Standard and ANSI sizesՕSpecial and Attachment Chains > 2 fully integrated factory inBirmingham, have a depthof technical expertise andengineering experience,specialising in the design,manufacture and supply of high performancemechanical powertransmission systems andcomponents. With our teamof applications and designengineers at your disposal,Cross+Morse is able toprovide bespoke technicalsolutions to your powertransmission...

Power Transmission Solutions Power Transmission Solutions Our expertise is based on over 100 years ofexperience and covers awide range of industriesincluding: Index to contents - Original equipment manufacture such as packaging machinery, conveyor systems and materials handlingՕProcess Industries including Food and PharmaceuticalAgricultural Equipment and MachineryՕSpecial Purpose MachineryBrick, Tile and Quarrying IndustriesՕEnvironmental and Energy IndustriesAt Cross+Morse, customer focused support, with in-house design andmanufacture does not carry a premium and is considered an essential...

ROLLER CHAINS Precision Roller Chains to both British Standard (B.S.) and American Standard (A.N.S.I.) from > 1 / > 4 " to 2 > 1 / > 2 " in simplex and multistrand forms.Drives suitable for powers from fractional to 2500 kW with operating speeds up to 25 metres per second. Cross+Morse produce only high performance Roller Chain of consistent quality, using modern manufacturing technology combined with long established proven specifications. Simplex chains have easy dis-assemblypins produced by the copper plating process originated by the company. For conveying and transportation a large range...

STOCK PILOT BORE SPROCKETSAND PLATEWHEELS An extensive stock range of low cost pilot bored Sprockets and Platewheelsto suit B. S. simplex and multi-strand chains from 8mm to 2" pitch, and ANSI simplex chains from > Power Transmission Solutions Power Transmission Solutions 3 / > 8 " to 1" pitch. Tooth sizes range from 8 to 150 teeth,with all Platewheels, and Sprockets up to 40 teeth manufactured in medium carbon steel. Larger sprockets are either welded fabrication, or high grade iron castings. For powered roller conveyors, a range of Double Simplex sprockets withfrom 12 to 25 teeth for 3/8" to...

TORQUE LIMITERS & COUPLINGS The Morse Torque Limiter is a protection device that limits torque transmittedin a drive, by slipping when the torque exceeds a preset value, due to shock loads, overloads, or machine jams. It automatically re-engages when the overload has passed. Torque Limiters prevent machine damage and costly breakdown time.The Torque Limiter uses spring loaded friction surfaces for its operation; slip torque obtained by adjusting the spring force.With a torque range of 3 to 10,000Nm our standard Torque Limiters can be used with a sprocket, gear, pulley or flange, including our...

CHAIN COUPLINGS LRC DUPLEX ROLLER CHAIN COUPLINGS > Power Transmission Solutions Low to medium speed drives (to 2000 rpm) > Power Transmission Solutions High starting or reversal torques > Easy connection of shafts > Available plain bore or with taper bushLNC DELRIN CHAIN COUPLINGS > Medium speed drives (to 5,000 rpm) > Corrosion proof chain > Suitable textile/food processing machinesKE SERIES ELASTOMERIC COUPLINGS > Totally interchangeable Industry Standard > Medium speed drives (to 6,000 rpm) > Easy quick shaft alignment > Available plain bore or with taper bushL SERIES ELASTOMERIC COUPLINGS...

High Torque, Compact, Robust Clutches with Metric or Imperial Bores from Stock for:- Indexing - Overrunning - Backstopping Power Transmission Solutions SPRAG CLUTCHES - "M" SERIESDUO-CAM CLUTCHES Duo-cam Sprag Clutches use high chrome alloy steels precision cams,hardened and honed for accurate shape, to provide uniform contact with both races for even load distribution and prolonged clutch life. High capacity bearings accommodate radial and axial loads. The clutches mount directly onthrough shafts; torque being transmitted by a key provided with each stockbore. The outer race is precision ground...

Timing Belts provide a low cost, low weight, positive drive connection of shafts; with ability to operate at highrotational speeds and transmit up to 500kW. Power Transmission Solutions Power Transmission Solutions Millions of successful drives in Industries from Office Equipment to Heavy Mechanical Handling Plant bear testimony to the versatility Timing Belts,providing minimal maintenance, and when correctly selected virtual life. The light compact drives, combined with high efficiency, reduced bearing loads, and elimination of tensioners, provide minimum cost designs. Cross+Morse offerthree...

Cross+Morse can provide the solution to most open gearing drives through a standard stock range of Bevelgears, Spur Gears and Racks; or custom made straight or helical gears selected with support of our specialist technical engineering team. Power Transmission Solutions STANDARD STOCK STEEL BEVEL AND MITRE GEARS Straight Cut Bevel and Mitre Gears manufactured to the Gleason system inmedium carbon steel enable simple right angle transfer of drive for with reduction ratios of up to 4:1. Two standard series of gears are offered, gears to imperial dimensionsfrom 16DP to 5DP, and metric gears ranging...

SHAFT CLAMPING ELEMENTS The modern way to connect driving hubs and shafts, providing a totallykeyless connection, so ensuring no backlash in the drive. Easier connection and disassembly with simplified timing of drives and positioning of components are only some of the virtues of these units. Cost savings are often realized through the elimination of keyways, setscrews, circlips andshoulders on shafts.No less than 16 different design variations enable the efficient connection of Shafts from 6mm to 300mm to Sprockets, Pulleys, Gears, and other transmission equipment; also units to connect shafts...
