Catalog excerpts
Made in America Serving the World >
Open the catalog to page 1(Request form #CD01) 2" to 5" bores, clevis mounted Օ Standard and ASAE closed centers > 2" to 4" bores, ASAE, clevis mounted Օ Rod threaded for mechanical depth control on DU Mechanical depth control included on DE > (Request form #CD02) Օ 3" to 5" bore Hardened steel pins and bushings standard on rod clevis Օ Hydraulically controlled variable stroke adjustment > DU & DE Series (Request form #CD02.1, CD04) Designed for series use - cylinders are volumetrically matched and feature a unique bypass system with special piston seals. Cylinders rephase automatically upon full extension. >...
Open the catalog to page 2(Request form #P401, M401) SAE ՓA 2-bolt mount . Rated to 17.5 gpm.ԕ 6 sizes: .5, .75, 1.00, 1.25, 1.50 and 1.80 in. > 3 /rev. > (Request form #P501, M501) SAE Փ B-2 bolt mount. Rated to 44 gpm. ԕ 7 sizes: 1.52, 1.95, 2.32, 2.74, 3.30, 3.80 and 5.2 in. > 3 /rev. > (Request form #P601, M601) > Series 50 SAE Փ C mount. Rated to 90 gpm. ԕ 6 sizes: 4.05, 5.15, 6.15, 7.15, 8.15 and 9.25 in. > 3 /rev. > (Request form #P502) > Series 40 Series 50T Dual (tandem) body pump in single rotation only. Օ Available in SAE BӔ mount - displacements same as Series 50. Operate as two separate sections,...
Open the catalog to page 3(Request form #VSS) Up to 9 gpm, 3000 psi, ductile iron body Օ Series operation Single unit or multi-function operation with stackable capabilites Օ Excellent spool metering, low leakage, manual and float detents available > (Request form #VAD2) > Model AD Converta Model 15 gpm, 3000 psi, 1 or 2 spool model with integral relief and loadchecks Օ Excellent metering, low leakage Variety of spool types and actuator optionsՕ Power beyond and closed center available > (Request form #VBA1) 1, 2 or 3 spool valve, 30 gpm, 2500 psi Օ Excellent metering, integral differential poppet-type relief and...
