MANUFACTURING INC. Made in USA PROVENPERFORMERS High Quality Օ Low Prices Fast Delivery >

In 1949 James H. Cross established CROSS Manufacturing in Lewis, Kansas. The first product was an agricultural tie rod cylinder. CROSS now has subsidiaries and marketing worldwide and produces one of the most extensive product lines on today's market. To provide our customers with the best possible service, all CROSS manufacturing plants are located in Kansas within an eighty mile radius of the main cylinder plant in Lewis. Valves and pumps are manufactured in Hays and adapters and fittings in Pratt. Executive offices are in Overland Park, KS. New products are con- tinuously being developed...

FEATURES: 2500 psi working pressure (4000 psi max shock) Օ 1500 psi on 4" bore, 1000 psi on 5" bore with std. pins Precision skived and burnished barrel for long seal life Օ Hardened chrome plated rods resist damage and rust Double lipped polyurethane rod seal for less leakage Օ Rod wipers clean dirt from rod to give long seal life Clevis mounting with 1" pin holes Օ Ports in line with pins CROSS DB - ORB cylinders provide CROSS proven durability. ORB (SAE) ports assure superior sealing and minimizes port damage due to overtorquing. > * These cylinders are rated for 2500 psi service but the...

HOW DO I HOOK UP THE VALVE? Inlet and outlet are marked on the directional valves. For standard valves hook up diagrams are shown on the bottom of the box . A and B (C, D, E and F if applicable) ports go to the cylinder ports. For VS and SD series see the box or call CROSS. WHAT VALVE SHOULD I USE FOR LIFTING? I HAVE A JOHN DEERE. ( or any other closed center system). For safety, a valve with a load check (Series AD/SA, BA or SS) is necessary in order that the load does not drop before it begins to raise again when you are shifting out of the neutral position. The load check is a spring...

MAINTENANCE: Make sure all bolts are tightened and torqued to the recommended specification. Bent or broken parts should not be used. Replace immediately. Always use exact replacements.Always protect valve spool from paint overspray. Faulty quick disconnects can cause high back pressures and sticking spools. Check quick disconnects peri- odically to make sure they are functioning properly. If valve spool does not center or appears to stick, do not use! DIRTY OIL: Oil must be filtered to a minimum of 25 microns. Filters should be changed regularly - spin-on types after 50 hours of initial...

Gradual or sudden loss of pressure or flow resulting in a loss of power is common in hydraulic system failure. Any one of the systemʼs components may be at fault. These step-by-step procedures should help you locate and remedy the problem quickly. 23 > FINDING AND SOLVING PROBLEMS:Please read and observe the HYDRAULIC PRODUCT SAFETY SHEET before proceeding further. Your safety is important to us! 1. SYSTEM INOPERATIVE Leakage. Excessive load. Check all components, particularly the relief valve for proper settings. Refer to technical manuals. Check unit specifications for load limits.Օ 5....

CROSS Manufacturing Inc. produces one of the most extensive hydraulic component lines on the market to-day. In addition to the wide range of products offered in this Full Line catalog, CROSS also offers numerous and diverse options and configurations to accommodate the needs of the marketplace and our customers. Many non-standard options are already configured within our system and are available within normally short lead times. Special design requirements are reviewed by our Engineering and Technical staff.CROSS was established in 1949 and is still privately owned and operated. CROSS...

Find your contacts for sales, product or technical information. Օ Request pdf product specifications or parts lists. (Pdf files are e-mailed immediately!) Request paper catalogs or handouts. Օ Receive personal assistance with technical, application or replacement inquiries. > From the opening screen of our web site, click on the info request at the bottom left (or at the bottom of the screen). You will be directed to a form where you can fill in your name, address, e-mail address and relevant information. There is also a box for your comments or additional requests. After clicking the...
