Introduction
Corning's InfiniCor® 50 µm optical fibers are designed to meet the growing bandwidth demands in enterprise networks. These fibers are the first laser-optimized 50 µm multimode fibers, offering high performance at data rates up to 10 Gb/s at 850 nm, cost-effective transmission, and compatibility with a wide range of protocols.

Product Specifications

• Optimized Data Rate: Up to 10 Gb/s over varying distances depending on the fiber type.
• Standards Compliance: Complies with ISO/IEC 11801, IEC 60793-2-10, and TIA/EIA standards.
• Optical Specifications: Core diameter of 50.0 ± 2.5 µm, cladding diameter of 125.0 ± 2.0 µm, and a numerical aperture of 0.200 ± 0.015.
• Environmental Specifications: Operating temperature range from -60ºC to +85ºC with induced attenuation limits under various conditions.
• Mechanical Specifications: Proof test tensile stress ≥ 100 kpsi, with fiber lengths available up to 17.6 km/spool.

Performance and Measurement
Corning ensures exceptional bandwidth through advanced measurement techniques, including effective modal bandwidth (EMBc) for predicting system performance. The fibers are thoroughly measured to ensure performance in laser-based systems.

Service and Product Advantages
Corning offers comprehensive customer service and technical support, including worldwide sales support, specialized technical assistance, and extensive fiber delivery capabilities. The fibers feature dual acrylate CPC® coatings for mechanical protection and handleability.

Ordering Information
Customers can order by contacting Corning's Optical Fiber Customer Service Department, specifying fiber type, attenuation, and quantity.

Contact Information
Corning Incorporated, One Riverfront Plaza, Corning, NY 14831, U.S.A. Phone: 607-248-2000, Email: [email protected]
