Catalog excerpts
Selection Guide Servo Drives Stepper Drives Control Software Analogic Motion Control
Open the catalog to page 1Copley Controls About Copley Copley Controls delivers high performance motion solutions to a wide range of industries including automated assembly, test and measurement and COTS military. company, Copley produces RoHS compliant products of the highest quality in a state-ofthe-art US manufacturing facility. With over 25 years of experience in OEM partnerships, combines with R&D to deliver world-class, highly commitment is backed with sales offices and local technical resources in the US, Europe and Asia. As part of Analogic Corporation, Copley Controls has the buying power and resources to...
Open the catalog to page 2Servo & Stepper Drives From networked servo and stepper drives to traditional torque amplifiers, Copley has the solution for your system architecture. Both AC- and DC-powered drives with flexible packaging options are offered in the 100W - 6kW power range. A comprehensive range of motor feedback interfaces is provided. Advanced tuning and commutation algorithms maximize motor performance. Ruggedized versions of select servo drives are available for COTS military applications. Built to withstand extremes of temperature and vibration with conformal coating for humidity tolerance, the Copley...
Open the catalog to page 3System Connectivity CONTROL PC Architecture Copley drives connect seamlessly to both CANopen and EtherCAT - the networks of choice for PC-based systems. Copley drives are also integrated into thirdparty software tools, including LabVIEW and CoDeSys SoftMotion, for complete PC-based multi-axis motion control solutions. Motion Control Cards Both the traditional ±10 V and PWM current/velocity command interfaces are built-in on all drives. For Delta Tau motion cards, MACRO drives enable an optimal motion control system solution. PLC Systems Control via PLCs is facilitated by a step/direction...
Open the catalog to page 4NETWORKS CANopen CANopen is a highly cost-effective implementation of distributed control. In PVT mode, the drive accepts tightly synchronized position/velocity/time points. In profile mode, the drive executes a move based on pretransmitted parameters. CANopen also accomodates velocity and torque modes. Copley provides comprehensive hardware and software tools for CANopen. CAN-PCI-02 is a fully isolated dualchannel PCI card with an on-board micro controller. CAN-IPM-01 I/O Processor Module enables OEMs to design optimal system interfaces and integrate them seamlessly into a CANopen network....
Open the catalog to page 5Software Tools APPLICATION LAYER COPLEY MOTION LIBRARIES ETHERCAT OPERATING SYSTEM Networking Software Copley Network Management • Configuration and startup • Synchronization • Node guarding • Message generation • Heartbeat • Error management commissioning fast and simple. The development of lowlevel code to control a CANopen or EtherCAT network is eliminated. All network management is accomplished with a few simple commands linked into your application program. The application program interacts with amplifier “objects.” Motion Control • Path planning • PVT generation • Profile execution •...
Open the catalog to page 6High Level Language Copley Programming Language (CPL) is a powerful, flexible OEM programming environment for PLUS versions of Copley drives. Combining the best features of BASIC, C, and Java, CPL incorporates a rich set of motion system calls. Data types are extensive and include arrays and structures. The availability of both local and global variables enables well- structured code development. Java based CME 2 configuration software is powerful and intuitive. Comprehensive diagnostics, auto-tuning and advanced oscilloscope tools simplify system Auto-phasing eliminates the time-consuming...
Open the catalog to page 7Digital Drive Overview Copley offers a complete range of high power density digital drives for brushless, brush and stepper motors. Both AC- and DC-powered versions are available. Xenus, Accelnet and Stepnet feature CANopen for distributed control. PLUS versions incorporate EtherCAT as well as CANopen and offer expanded feedback options. Multi-axis PLUS versions deliver the lowest cost per node. PLUS drives feature high resolution A/D converters for optimal current control as well as fast, hardware-based position capture and setpoint trigger output. Feature_Xenus_Accelnet Stepnet Accelus...
Open the catalog to page 8Safe Torque Off The Safe Torque Off capability of PLUS Panel drives eliminates the expensive contactors and complex wiring traditionally used in safety critical applications. Safe Torque Off provides two drive enable inputs facilitating system conformance to SIL 3 (IEC 61800-5-2) & Category 4 PLe (ISO 13849-1). Technology Edge Field Oriented Control • Optimal orientation of magnetic field • Motors run faster and cooler Servo & PWM Performance • High-bandwidth nested loops • Biquad filter for notch or low pass flters • High-efficiency dynamic PWM • Edge filter accessories for low emissions...
Open the catalog to page 9Panel - Servo AC-powered drives are available in both EtherCAT and CANopen versions. Multi-axis models deliver optimal cost per node. A wide range of absolute encoder interfaces are built-in, including EnDat, BiSS and SSI. High resolution A/D converters ensure optimal current loop performance. Isolated I/O, as well as high-speed non-isolated I/O are provided. For safety critical applications, redundant power stage enable inputs can be employed [Safe Torque Off]. Control Modes • Indexer, Point-to-Point, PVT, PT • Camming, Gearing • Position, Velocity, Torque Command & Communications •...
Open the catalog to page 10Xenus Panel - Servo XTL Panel Xenus is available in two AC line operated compact packages delivering power up to 6 kW. A +24Vdc input powers control circuits, ensuring keep-alive operation. Control interfaces include CANopen as well as traditional analog commands. Incremental encoder feedback is standard with optional resolver and analog encoder interfaces. Control Modes • Indexer, Point-to-Point, PVT, PT • Camming, Gearing • Position, Velocity, Torque Command & Communications • CANopen DS-402 • RS-232 ASCII • Step/Direction, Step Up / Step Down • ±10V position/velocity/torque • PWM...
